Clear Power CP50006 Manuale utente

• Remote control allows for programming the timer

from up to 80ft away

• 7 settings: Always On, On at dusk/O at dawn,

On at dusk, - o in 2, 4, 6 or 8 hours, Always O

FEATURES

Item #CP50006

Outdoor Timer

w/Remote Control

Operating Instructions

USING THE REMOTE CONTROL

Press the button beneath the desired setting.

Example: To program the timer to go on

approximately at dusk and o in 4 hours, press

the button on the remote control beneath

"4hrs" (Fig. 1).

The LED indicator illuminates when any button

is pressed.

Fig 1.

PAIRING THE REMOTE TO THE TIMER

MANUALLY CONTROLLING THE TIMER

INSTALLING THE BATTERY

To install A23 (12V) battery: Remove the back cover of the battery

compartment. Align "+" and "-" ends of the battery to those in the

compartment. Fully insert. Close the cover.

Devices

not turn on

approximately

at dusk.

Devices

not turn on

when the

timer is in

the “ON”

position.

Lights are

flashing

(turning on

and off).

Timer power

is not “on”

Timer is located

in an area with

too much

ambient light for

the photocell to

sense darkness.

Connected

devices

are

not in the “ON”

position or are

not functioning.

Light bulbs

need to be

replaced.

Timer is in

Dusk-to-Dawn

mode and light

from connected

lights is affecting

the photocell.

Timer is not fully

plugged into the

outlet.

Circuit breaker

connected to

the outlet has

tripped.

Move the timer to another

location where there is no

ambient light.

Ensure the connected devices

are functional by plugging them

directly into the outlet. Be sure

the connected devices are in the

“ON” position if they have their

own switch. Make sure the outlet

the timer is plugged into is active

- the LED should light up when

plugged into an outlet and in the

“ON” position. Check the bulbs

and replace if necessary.

Move the lights away from the

timer, or reposition the timer

so it does not face the lights

directly.

Make sure the timer is fully

plugged into the outlet.

Check the circuit breaker

connected to the outlet and

reset it if needed.

PROBLEM POSSIBLE

CAUSE

CORRECTIVE

ACTION

TROUBLESHOOTING

NOTE: The timer will turn ON approximately at dusk and the red light

next to the desired setting will be ON. After the timed cycle has been

completed the red light next to the desired setting will remain ON to

show that the program is still active and will repeat at dusk each day until

the operating mode is changed. This timer has a power failure back-up

that will remember the last program setting when the power returns.

OPERATING MODES

OFF - Power is OFF to attached devices

ON - Power is ON to attached devices

Dusk-Dawn - Power will turn on at dusk and remain

on until dawn

2 Hrs - Power will turn on at dusk and remain on for 2 hours

4 Hrs - Power will turn on at dusk and remain on for 4 hours

6 Hrs - Power will turn on at dusk and remain on for 6 hours

8 Hrs - Power will turn on at dusk and remain on for 8 hours

• This timer is weather-resistant and rated for outdoor use. The timer will function

outdoors when installed and operated as outlined in this manual.

• This timer operates using a light-sensitive photocell that senses when the

environment is getting dark (dusk) or light (dawn). The photocell is located above the

“Program” button on the face of the timer.

• Once programming activates at dusk in the 2hr, 4hr, 6hr or 8hr mode, the program

cycle will complete before the timer resets. Headlights, porch lights, street lamps and

other external lighting sources will not interfere with the active timer program.

• In the dusk-to-dawn mode, temporary light sources like headlights, porch lights and

other external light sources will not interfere with the photocell function unless the

external light source is on for more than 15 minutes. In that case, the timer will shut o

until darkness is restored.

• When set to “ON”, the timer will provide continual power to attached devices until the

timer is switched to “OFF”, or to any of the other operating modes.

• Do not place the timer hidden in bushes where it won’t sense daylight.

• It may take until complete darkness for the photocell to turn on power to the timer.

• The “Operating Mode” indicator light will turn on when the timer programming is

activated and power is being provided to attached devices.

• Do not use extension cords to connect the timer to the power source.

HELPFUL TIPS

Press the "Program" button repeatedly until

the red indicator light beneath the

operating modes is aligned with the desired

mode.The red light will blink rapidly 3 times to

conrm your selection. The red light next to the

selection will remain on to show that the

program has been set. (Fig. 4)

Fig. 4

The remote control transmitter has already been

paired to the timer. However, if the pairing is lost:

1. Press the "Program" button until the ON indicator

illuminates, then hold the "Program" button for 3-4

seconds until the OFF indicator illuminates and the ON

indicator ashes.

2. Press and hold any button on the remote control

until the ON indicator light on the timer ashes quickly

then turns o. This indicates the pairing is successful.

3. Press any time mode on the remote transmitter.The

indicator light for the corresponding mode on the

timer should illuminate.

To unpair the remote control:

1. Press the "Program" button until the OFF indicator

illuminates and hold the "Program" button for 10

seconds or until all the other indicator lights ash for

one second and then turn o.

(The OFF indicator remains illuminated.)

The remote transmitter is unpaired.To re-pair the

remote transmitter to the timer, follow the pairing

instructions above.

Fig. 3

Fig. 2

SAFETY INFORMATION & SPECIFICATIONS FCC REGULATORY STATEMENT

WARNING: CHOKING HAZARD – Small Parts. Not for

children under 3 years.

FOR USE OUTDOORS. MUST BE PLUGGED

INTO A GFCI PROTECTED (GROUND

FAULT CIRCUIT INTERRUPTER)

PROTECTED OUTLET.

This is a“GROUNDED”device. The male plug contains a ground pin

and is only intended for use with a three-pronged grounded

outlet.

This device is for use with a 125VAC power source.

DO NOT LAY TIMER ON THE GROUND. This timer has an eye-hole in

the cord strain relief from which to securely hang it close to the

outdoor electrical outlet.

1. INSTALL TIMER to a vertical at

surface close to a properly installed

outdoor-rated grounded receptacle

a. Using a screw or hook (not included),

secure the MOUNTINGTAB at the top

of the timer to a wall or post.

Dispose the old battery in compliance with all applicable laws.

Contact your local solid waste authority for detailed information.

WARNING: DO NOT DISPOSE OF BATTERIES IN FIRE. BATTERIES

MAY EXPLODE OR LEAK.

• Non-rechargeable batteries are not to be recharged.

• Batteries are to be inserted with the correct polarity.

• Exhausted batteries are to be removed from the product.

• Regularly change the battery in remote control for the best

performance. If you nd the timer programs are not responding,

the battery should be replaced. Always dispose of old batteries

properly with consideration of environment.

• * Make sure the battery and connected devices plugged into the

outlets are installed rmly and correctly for safe operation.

Under Industry Canada regulations, this radio transmitter may

only operate using an antenna of a type and maximum (or

lesser) gain approved for the transmitter by Industry Canada.

To reduce potential radio interference to other users, the

antenna type and its gain should be so chosen that the

equivalent isotropically radiated power (e.i.r.p.) is not more

than that necessary for successful communication.

This device complies with Industry Canada licence-exempt RSS

standard(s). Operation is subject to the following two

conditions: (1) this device may not cause interference, and (2)

this device must accept any interference, including interference

that may cause undesired operation of the device.

Under Industry Canada regulations, this radio transmitter may

only operate using an antenna of a type and maximum (or

lesser) gain approved for the transmitter by Industry Canada.

To reduce potential radio interference to other users, the

antenna type and its gain should be so chosen that the

equivalent isotropically radiated power (e.i.r.p.) is not more

than that necessary for successful communication.

This device complies with Industry Canada licence-exempt RSS

standard(s). Operation is subject to the following two

conditions: (1) this device may not cause interference, and (2)

this device must accept any interference, including interference

that may cause undesired operation of the device.

WARNING

Changes or modications not expressly approved by the

party responsible for compliance could void the user's authority to

operate the equipment.This device complies with part 15 of the FCC

rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received,

including interference that may cause undesired

operation.

Note:This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the FCC

Rules.These limits are designed to provide reasonable protection

against harmful interference in a residential installation.This

equipment generates, uses and can radiate radio frequency energy

and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to

radio or television reception, which can be determined by turning

the equipment o and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

1. Reorient or relocate the receiving antenna.

2. Increase the separation between the equipment and

receiver.

3. Connect the equipment into an outlet on a circuit

dierent from that to which the receiver is connected.

4. Consult the dealer or an experienced radio/TV

technician for help.

IC REGULATORY STATEMENT

Works with CFL, LED

& Incandescent light sources

WARNING: This product can expose you to chemicals including

Di(2-ethylhexyl)phthalate (DEHP), which is known to the State of

California to cause cancer and birth defects or other reproductive

harm. For more information go to www.P65Warnings.ca.gov.

AVERTISSEMENT : Ce produit peut exposer l'utilisateur à des

produits chimiques, notamment le Di(2-ethylhexyl)phthalate (DEHP)

qui est reconnu dans l’état de Californie comme étant à l'origine de

cancers, anomalies congénitales ou autres problèmes de reproduction.

Pour plus de renseignements, aller sur www.P65Warnings.ca.gov.

ADVERTENCIA: Este producto puede exponerlo a sustancias

químicas incluido el Di(2-ethylhexyl) phthalate (DEHP) que en el

Estado de California se ha determinado que producen cáncer,

defectos de nacimiento u otros daños en el sistema reproductor. Para

obtener más información vaya a www.P65Warnings.ca.gov.

Risque de choc électrique

• Gardez les enfants à l’écart.

• Débranchez la minuterie avant de procéder au nettoyage.

• Insérez complètement la fiche.

• N’utilisez pas l’article dans des endroits humides.

Risque d’incendie

• N’utilisez pas cet article pour commander des appareils

qui contiennent des éléments chauffants (appareils de

cuisson, radiateurs, fers, etc.).

• Ne dépassez pas les capacités électriques. Pour usage à

l’intérieur seulement.

AVERTISSEMENT

Peligro de descarga eléctrica

• Mantenga a los niños alejados.

• Desenchufe el temporizador antes de limpiarlo.

• Introduzca plenamente el enchufe.

• No lo use en áreas mojadas.

Peligro de incendio

• No lo use para controlar artefactos que contengan

elementos calefactores (artefactos de cocción,

calentadores, planchas, etc.).

• No exceda las capacidades nominales. Para uso en

interiores solamente.

Risk of Electric Shock

• Keep children away

• Unplug timer before cleaning

• Fully insert plug

• Do not use near standing water.

Risk of Fire

• Do not use to control appliances that contain heating

elements (cooking appliances, heaters, irons, etc.)

• Do not exceed electrical ratings.

ADVERTENCIA

WARNING

Electrical Ratings

125VAC/60Hz

15A 1875W Resistive

8A 1000W Tungsten

and Ballast

1/2 HP

Transmission frequency: 434Mhz

Signal reception range: 80Ft in

line-of-sight

Do not exceed the maximum load

of 8A (approximately 1,000W)

Manuali Timer popolari di altre marche

Intermatic

Intermatic P1131 Manuale utente

Learning Resources

Learning Resources Time Tracker mini Manuale utente

CEBEK

CEBEK I-215 Manuale utente

Somogyi

Somogyi home TS MD 5 Manuale utente

Profile

Profile 010200280 Manuale utente

Gizmo

Gizmo T4 Manuale utente

Tekmar

Tekmar Timer 031 Manuale utente

Daikin

Daikin DST301B61 Manuale utente

sisel

sisel ENDA ETM2432 Manuale utente

B&Q

B&Q TE103 Manuale operativo e di manutenzione

Hozelock

Hozelock AC Plus 2700 Manuale utente

GIC

GIC Eliro V7DDSS3Eliro V7DFTS3 Manuale utente

Tork

Tork TU40 Manuale utente

Emos

Emos EMT400F Manuale utente

FarmTek

FarmTek Polaris Manuale utente

Maximum

Maximum CRONUS Manuale utente

Uberhaus

Uberhaus TD133B Manuale utente

Clas Ohlson

Clas Ohlson 31-3766 Manuale utente
