#Reference: LAN-V2x1x3x4x3x3x4ACDBEFACEBDFAnchor BodyFix screw.DIN 933 M10x40 Thin nut.DIN 936 M10 Anchor Screw.DIN 912 M8x35 Self-Locking nut.DIN 985 M8 Fastening partThe Anchor installation and maintenance requires the use of a calibrated torque wrench.The installation of the Anchor on the Anchor Wedge or in the Artculated arm is carried out using the components D and F according to the assembly procedure of this manual.Anchor allows a continuous movement for CLiC-iT Rider Pulley along the entire game course. Its function is to guide the IMN&CliC-iT Safety Line cable and keeping it fixed at a certain point. To do this, 3 gripping pieces press the cable and prevent any movement.2Required tools:
Manual or Digital Torque Wrench
Ex: Irimo
Supported safety cable diameter
12 mm
17mm Hexagonal head or 17mm Hexagonal socket
! The use of an impact wrench is not allowed.! Never exceed the indicated torque.! Ignoring these indications can lead to anchor fracture.To fix the safety cable, you must exert a torque of 40 N / m on each M10 screw.A torque wrench must be used to not exceed this value.Finally, manually tighten the nuts of each screw.ŸDon´t clean Anchor with soap or water.ŸTo remove dirt from Anchor use air or a damp cloth.ŸAvoid long exposure of the product in saline environments.40 N/m40 N/m40 N/m Anchorx4G*G*Flat washer DIN 125 M8. *Only to be used when assembled on articulated arms. Anchor and Anchor Wedge assemblyAnchor and Articulated arm assembly2.5 Assemblies2.4 Cleaning recommendations2.3 Essential instructions2.1 Description2.2 Anchor components
