Genesis Large Water-to-Water (GLW) Series Page 3
GENERAL INFORMATION
Inspection
Upon receipt of the equipment, carefully check the
shipment against the bill of lading. Make sure all units
have been received. Inspect the carton or crating of each
unit, and inspect each unit for damage. Assure the carrier
makes proper notation of any shortages or damage on all
copies of the freight bill and completes a common carrier
inspection report. Concealed damage not discovered
during unloading must be reported to the carrier within
15 days of receipt of shipment. If not filed within 15
days, the freight company can deny the claim without
recourse. Note: It is the responsibility of the purchaser
to file all necessary claims with the carrier. Notify the
ClimateMaster Traffic Department of all damage within
fifteen (15) days of shipment.
Storage
Equipment should be stored in its original packaging in
a clean, dry area. Store units in an upright position at all
times. Stack units a maximum of 2 units high.
Unit Protection
Cover units on the job site with either shipping packaging,
vinyl film, or an equivalent protective covering. Cap
the open ends of pipes stored on the job site. In areas
where painting, plastering, and/or spraying has not been
completed, all due precautions must be taken to avoid
physical damage to the units and contamination by
foreign material. Physical damage and contamination
may prevent proper start-up and may result in costly
equipment clean-up.
Examine all pipes, fittings, and valves before installing
any of the system components. Remove any dirt or trash
found in or on these components.
Pre-Installation
Installation, Operation, and Maintenance instructions
are provided with each unit.. The installation site chosen
should include adequate service clearance around the unit.
Before unit start-up, read all manuals and become familiar
with the unit and its operation
. Thoroughly check the
system before operation.
Prepare units for installation as follows:
1. Compare the electrical data on the unit nameplate
with ordering and shipping information to verify that
the correct unit has been shipped.
2. Keep the cabinet covered with the shipping
packaging until installation is complete and all
plastering, painting, etc. is finished.
DO NOT store or install units in corrosive environments
or in locations subject to temperature or humidity
extremes (e.g., attics, garages, rooftops, etc.) Corrosive
conditions and high temperature or humidity can
significantly reduce performance, reliability, and service
life. Always move units in an upright position. Tilting
units on their sides may cause equipment damage.
▲WARNING!
!
3. Verify refrigerant tubing is free of kinks or dents and
that it does not touch other unit components.
4. Inspect all electrical connections. Connections must
be clean and tight at the terminals.
GLW Physical Data
To avoid the release of refrigerant into the atmosphere,
the refrigerant circuit of this unit must be serviced
only by technicians who meet local, state, and federal
proficiency requirements.
All refrigerant discharged from this unit must be
recovered WITHOUT EXCEPTION. Technicians
must follow industry accepted guidelines and all
local, state, and federal statutes for the recovery and
disposal of refrigerants.
If a compressor is removed from this unit, system
refrigerant circuit oil will remain in the compressor. To
avoid leakage of compressor oil, the refrigerant lines
of the compressor must be sealed after it is removed.
▲WARNING!
!
Model 360
Compressor/qty Scroll/2
Factory Charge R22: each circuit - (lbs.) [kg 9 [4.1
Indoor/Load Water Connection Size
FPT - All Other 2"
Outdoor/Source Water Connection Size
FPT - All Other 2"
Weight - Operating - lbs. [kg 955 [434
Weight - Packaged - lbs. [kg 1005 [457
Grommet mounted compressor.
Rev.: 8/26/02B
Dedicated heating and cooling expansion valves with filter drier.
Insulated Indoor and Outdoor brazed plate heat exchangers.
Check serial plate for refrigerant type.
Insulated refrigerant and water piping.
