AIR-CONDITIONERS
Page www.YHFRQDFRP
3.4- FASTENING
The Compact unit should be secured by the clips.
.
3.5- CONDENSATE DRAIN
The Climma Compact unit will extract a significant quantity
of moisture from the air, and this must be disposed of by
means of a gravity condensate drain. This drain can either
be to the bilge or to a sump with float-switch and pump.
The condensate drain
fittings provided are for
5/8" ID hose.
Do not use smaller diametermm on the
hose.
.
Each unit is equipped with two out-
lets, as you can see in the picture
above.Either one or both drains may be used.
Condensate drains should ideally make a vertical
orientation as soon as possible after the pan fitting.
If both drains are to be used, they should be joined
together at a point lower than the drain pan.
Do not make more than one "U" trap in the condensatebe
drain as this can lead to a pneumatic lock that will
prevent the drain from functioning.
DO NOT lead condensate drain directly overboard.
This can lead to the ingress of potentially lethal fumes
from exhaust emissions, etc.
5efer to the safety regulations UHOHYDQWWR\RXU
JHRJUDSKLFDODUHD
NEOPRENE
3 INSTALLATION OF THE COMPONENTS
Figure 1.8
Dis 2.8
Figure 2.8
