IN THE BOX
What accessories are included with
your HEIMDALL purchase?
65
1 x HEIMDALL |Danish designed streaming adaptor
1 x AUX cable |Analogue
1 x Optical Cable with Adaptor |Digital
1 x AC/DC power supply |With EU & UK plugs
1 x HEIMDALL User Guide |To learn every detail
SETUP
1. Connect HEIMDALL to a power outlet using the
included AC-DC adaptor.
2. HEIMDALL will automatically power on when
connected. If it does not - please press the “PLAY/
PAUSE” button.
Get started: Power On:
Note: If a Wi-Fi connection cannot be established, then HEIMDALL will say:
“No device connected” and then: “Please reconnect your device”.Note: Only use the included AC-DC adaptor.
1. Press “PLAY/PAUSE“ and HEIMDALL will power on.
2. Four white LED’s will ash rapidly, which indicates
HEIMDALL is booting up.
How to get started with HEIMDALL
SETUP
How to get started with HEIMDALL
87
CONNECTING TO NETWORK
You have a few options to connect
HEIMDALL to your network
You have a few options to connect
HEIMDALL to your network
Many modern routers support Wi-Fi
setup feature. If yours does, locate the
Wi-Fi setup button and then continue
this guide.
1. Start by pressing the “Wi-Fi setup”
button on the rear of HEIMDALL.
HEIMDALL will say: “Waiting for
connection” and purple LED will
ash rapidly.
2. Quickly press your routers Wi-
Fi setup button and wait until
HEIMDALL says: “Your device is
now connected”. All ve LED will
start breathing slowly.
Wi-Fi Setup (Push button):
Back side of HEIMDALL.
Standard Wi-Fi setup symbols.
CONNECTING TO NETWORK
109
Note: If you do not press Wi-Fi setup button within 2 mins. or a Wi-Fi connection
cannot be established – HEIMDALL will return to the previous state.
By using Music Direct you are able
to setup the network connection for
HEIMDALL, by using either a Web
browser or the Clint App.
1. Press and hold the ”Wi-Fi Setup”
button on the rear of HEIMDALL for
4-5 seconds until the purple LED
ashes rapidly and the four white
LED’s are solid.
2. On your selected music device (ex.
iPhone or computer) search for a Wi-
Fi connection.
3. When you see: “Clint | HEIMDALL“,
connect with it.
4. You have now made a direct
connection to your HEIMDALL. Read
the next few pages to learn two
methods for connecting HEIMDALL
to your home network.
Enable connection via Music Direct:
Back side of HEIMDALL.
CONNECTING TO NETWORK CONNECTING TO NETWORK
1211
Via Clint App (Music Direct)
Clint also developed an application, which
can be downloaded on the App Store or
Google Play. Please download our app
before going through below steps:
1. Make sure your music device and
HEIMDALL is connected via Music Direct
(See page 10).
2. Open the Clint App and choose the
“Speaker Settings” option.
3. Choose the “Network setting” option for
your HEIMDALL.
4. Choose your Wi-Fi network on the list
and enter password (If applicable).
5. HEIMDALL will now reboot and try to
connect to your Wi-Fi network.
Method 1 - Clint App:
Note: If a Wi-Fi connection cannot be established
HEIMDALL will return to the previous state.
Choose speaker
settings here.
Press the network
settings button
and then “Network
Settings”
Via Clint App (Music Direct) - Continued
2.
3.
CONNECTING TO NETWORK CONNECTING TO NETWORK
1413
1. Open the internet browser on your
device and write 192.168.1.1 in the
address bar. Press “ENTER” to go to
the web interface of HEIMDALL.
2. Here you can connect HEIMDALL to
your Wi-Fi network.
3. Choose your network (SSID) on
the list and enter your password (if
applicable).
4. Click Apply to accept. HEIMDALL
will now reboot and try to connect to
your Wi-Fi network.
5. HEIMDALL will say ”Waiting for
connection” and then ”Your device
is now connected”. This is indicated
by all ve LED’s slowly breathing.
Method 2 - Web browser:
Via Web browser (Music Direct)
Note: If a Wi-Fi connection cannot be established
HEIMDALL will return to the previous state.
Choose
your Wi-Fi.
Type in your
password for
the Wi-Fi.
Via Clint App (Music Direct) - Continued
4.
4.
BUTTONS ON HEIMDALL
These are the different buttons
located on the top of HEIMDALL
Play / Pause
Power on / off
MultiRoom
(WHA)
Mute the music
Volume up
Volume down
Wi-Fi Setup
USB Port
Headphone Out Power In / DC In
BUTTONS ON HEIMDALL
These are the different buttons and connectors
located on the rear of the HEIMDALL
1615
AUX-Out
Analogue & Digital
BUTTONS ON HEIMDALL
Their functions
BUTTONS ON HEIMDALL
Their functions
It is always possible to reset HEIMDALL if any issues occur.
1. Press and hold Volume “+” and Volume “-” down
simultaneously for 3-4 seconds to perform a system reset.
2. When the LED’s turns off release the buttons. Wait until
HEIMDALL has rebooted. HEIMDALL will say: “No device
connected” and then – “Please reconnect your device”
(See page 9 for connecting to network).
Pressing the “ ” button will switch HEIMDALL between
single speaker mode and MultiRoom (WHA) mode.
The rst speaker is set as MASTER and the rest will be set
as SLAVES.
Note: Read more about MultiRoom (WHA) on page 22.
1. Press the “+“ to turn the volume up.
2. Press the “-” to turn the volume down.
Volume Up / Down:
Reset:
MultiRoom (WHA):
1. Press the “ “ to mute the music.
2. Press the “ “ again to un-mute the music.
Mute:
1. Press “ “ to power on HEIMDALL.
2. Press and hold “ ” to power off HEIMDALL.
Power On / Off:
1. Press ” “ button to pause music.
2. Press “ “ again to play music.
Play / Pause:
1817
Warning: When performing a RESET all settings will be deleted and
HEIMDALL will return to the factory default settings.
