BLACK TIE

USER MANUAL

WMH-88L

COASTAL Amusements lnc.

1950 Swarthmore Ave.

Lakewood, NJ 08701

Tel: (732) 905-6662 Fax: (732) 905-6815

http://www.coastalamusements.com

CONTENT

OPERATION .............................................................................................................................................2

⚫How to Play.............................................................................................................................2

⚫Game Rules.............................................................................................................................2

⚫DEMO.....................................................................................................................................2

Coin In..................................................................................................................................................2

Shocking Machine...............................................................................................................................2

⚫DIPSW Setting.......................................................................................................................3

⚫DIPSW1..................................................................................................................................3

⚫DIPSW2..................................................................................................................................4

⚫Ability to change the Inner-Values.......................................................................................4

MAINTENANCE.......................................................................................................................................5

⚫TEST.......................................................................................................................................5

Bonus Play Table....................................................................................................................6

⚫ERROR CODE ......................................................................................................................8

⚫TROUBLE SHOOTING.......................................................................................................9

WIRING DIAGRAM ..............................................................................................................................11

⚫MAIN BOARD W150104....................................................................................................11

⚫DISPLAY W991907 .............................................................................................................15

OPERATION

How to Play

1. Insert coins/tokens into coin slot, the display shows credits and the crane plays game

music.

2. Use joystick to move claws above your selected object. When you move the joystick, the

game time is countdown, and【DESCEND】button light is flashing.

3. At pressing【DESCEND】button or time’s up (game’s playing time is adjustable), the

gantry drives motor to lower down claws and then catch object.

4. If ‘Catch in air’ function is available, press【DESCEND】button before claw reaches in

filed, the claws will catch item in the air.

5. After movement of catching (claws closes), the claws rise up till it touches Stop-Up SW.

Then the claws move to exit area and releases.

Game Rules

DEMO

Play Demo music for 2 minutes every 3 minutes.

Coin In

1. Coins v.s. plays: By Dip SW setting

2. If COIN pulse speed was lower than 10msec, the machine does not recognize the signal.

3. If coin speed is over 200 msec, the machine shows error code.

Shocking Machine

1. When a tilt is mounted at machines, and players shock the machines, it plays “Don’t

Shock the Machine”.

2. When the claw arms close and someone shocks the machines, the arms open and move

back to the home position.

DIP SW Setting

DIPSW1

The claw

strength voltage

VR1Adj. of Power

+48V

OFF

Position where

claws open at the

exit

Claws lower down

then release object

Claws release

object at the top

position

OFF

Coin 1 & Coin 2

Linked Together

Yes

OFF

Adjustment of

Credit Value

Inner Value

DIP SW

OFF

Bonus Plays

(see bonus table)

(4 pluses=$1 )

YES

OFF

Claw moving to

playfield when

game begins

YES

OFF

Reserved

OFF

When the program

sends strongest

strength on the

basis of the setup

winning

percentage, the

system will keep

sending strongest

strength to the

claw until win

With

(Prize Sensor must

be installed)

Without

OFF

DIPSW2

Coin1 of method

(Coin Selector of

Coin Pulse vs.

Play)

8 coins 1 play

6 coins 1 play

OFF

4 coins 1 play

OFF

2 coins 1 play

OFF

Coin2 of method

(Bill Acceptor of

Coin Pulse vs.

Play)

4 coins 1 play

3 coins 1 play

OFF

2 coins 1 play

OFF

1 coins 1 play

OFF

Free Play

YES

OFF

Play till you win

function

(Prize Sensor must

be installed)

With:

Will deduct 1 credit

when win.

Without:

Will deduct 1 credit

for each game

OFF

Ability to change

the Inner-Values

YES

OFF

Auto Test

With

YES

OFF

MAINTENANCE

TEST

System Test:

COIN1 NC +COIN2 NC+POWER ON (or Service NC+POWER ON)

Enter the system Test, DISPLAY shows 0~3, then press button to confirm.

0 EXIT

1 Claw Setting (COIN1 NC +POWER ON can have Claw Setting)

2 Gantry Test (COIN2 NC +POWER ON can have Gantry TEST)

3 System Test F0 EXIT

;; F 1 DISPLAY and Light Test

;; F 2 DIPSW Test

;; F 3 Demo Sound

;; F 4 Auto Demo

;; F 5 REVESED

;; F 6 BACK TO DEFAUTL

;; F 7 Length of String adjustment (Default value: 24)

AUTO PERCENTAGING SETTING

SET Play VS Coin Value: ($0.01~9.99)

Set Prize Value: ($00.01~99.99)

Set Win Percentage (Range: 01~99 %)

How to Setup:

1. Tilt (NC) +Button (NC) + Turn Power ON

Display shows "P5" for setup auto percentage function.

2. Tilt (NO) + Button (NO)

Display “00” in flashing:

Use Joystick and button to adjust

Function Code:

00 Exit

01 SET Play VS Coin Value

02 Set Prize Value

03 Win Percentages

04Automatic calculate the times of super power (Qty of wins)

Bonus Play Table

CREDIT

PLAYS

$10

$11

$12

$13

$14

$15

$16

$17

$18

$19

$20

$21

$22

$23

$24

$25

$26

$27

$28

$29

$30

◼Internal setting：

DIPSW2-7 ON+ POWER ON➔Enter the Inner Values setting menu. Display shows 00.

Use joystick to select and press button to enter the setting

Number

contents

Explanation

Value

COIN1- quantity of pay-out tickets

after inserting coins

0~9

COIN2- quantity of pay-out tickets

after inserting coins

0~9

COIN1- quantity of Inserted coins

1~99

COIN1- quantity of game’s credits

1~99

COIN2-quantity of Inserted coins

1~99

COIN2- quantity of game’s credits

1~99

Quantity of pay-out tickets won

0~9

Quantity of pay-out tickets without

winning

0~9

Reserved

Game’s play time (unit: seconds）

0~5＝5, 5~99（seconds）

Reserved

Catching on Air

0~1 0=NO 1=YES

Super Power Frequency

0~1 0=FIXED 1=Random

If Sensor is out of service

0~1, 0=machine is not operating,

1: machine is still operating.

Reserved

DEMO MUSIC

0~1 0=YES 1=NO

Speech/Noise for Shaking machine

0~1 0=YES 1=NO

⚫If Sensor is out of service, you can set “0”for machine Not Operating or set “1”for

machine Still Operating. If sent “1”, the claw power will be always supplied VR2 power

only, no any super power, and the Play until win function will not work. Once sensor is

back to Normal, then the machine will be back to normal again.

ERROR CODE

Error Code

Description

Checking timing

Trouble shooting

Er 00

CPU Error

When switch on

the machine

1. Change U1 CPU

2. PCB is out of service.

Er 01

Error while

up the

winding cord

1. When switch on

the machine

2. When play the

game

3. Auto Demo

1. Check if the up-stop SW is loose?

2. Check if up-stop SW is out of work?

3. Check if the air-plug of the gantry set

connects well?

4. PCB is fault.

Er 03

Error while

down the

winding cord

When auto demo

1. Check if the string at the winding wheel is

smooth?

2. Check if up-stop SW is out of work?

3. Check if the air-plug of the gantry set

connects well?

4. PCB is fault.

Er 0E

SENSOR is

out of service

1. Check whether sensitivity of sensor is too high?

Please adjust the sensitivity-VR to make sure the

LED of Sensor is in Dark status.

2. Check J5 sensor harness is connected well?

3. Sensor is fault.

4. PCB is fault

Er 05

Stop-Forward

SW or

Stop-back SW

Error

1. When switch on

the machine

2. When play the

game

3. Auto Demo

1. Check if the stop-forward SW or stop-back SW is

out of work?

2. Check if the air-plug of the gantry set connects

well?

3. PCB is fault.

Er 06

Stop-Left SW

Error

1. When switch on

the machine

2. When play the

game

3. Auto Demo

1. Check if the Stop-Left SW is out of work?

2. Check if the air-plug of the gantry set connects

well?

3. PCB is fault

Er 07

Coin1 Meter

disconnectio

1. Check if the J5 PIN connects well?

2. Check if the Meter is out of work? Check if the

Pin connects well?

3. PCB is fault.

Er 08

Coin2 Meter

disconnectio

Er 09

Er 10

Prize Mater

dis connection

Er 22

Cabinet size

check Error

when power

1. Check if the stop-front SW or stop-back SW is

out of work?

2. Check if the air-plug of the gantry set connects

well?

3. Check the J4 Pin on the board connect well?

4. PCB is fault
