Coaster 991047 Manuale utente
ASSEMBLY INSTRUCTIONS
COASTER FINE FURNITURE
Fine Furniture for every stage of life
REVISION 0: 04/03/2019
991047
PAGE 1 OF 4 COASTERFURNITURE.COM
REVISION 0: 8/11/2021
FIREPLACE
REVISION 1: 6/6/2022
REVISION 2: 8/9/2022
ITEM :
991047
ASSEMBLY INSTRUCTIONS
ASSEMBLY TIPS:
1.Remove hardware from box and sort by size.
2.Please check to see that all hardware and parts are present prior to start of assembly.
3.Please follow attached instruction in the same sequence as numbered to assure fast & easy assembly.
WARNING!
1.Don't attempt to repair or modify parts that are broken or defective. Please contact the store immediately.
2.This product is for home use only and not intended for commercial establishment.
PARTS IDENTIFICATION
Z HARDWARE IDENTIFICATION
A FIREPLACE 1PC 1 SCREW M3.5*12 MM 6PCS
B
FURNACE CORE 1PC
2 SCREWDRIVER 1PC
COASTERFURNITURE.COM
PAGE 2 OF 4
√
ITEM :
991047
ASSEMBLY INSTRUCTIONS
STEP 1
STEP 2
`
COASTERFURNITURE.COM
PAGE 3 OF 4
1
2
√
ITEM :
991047
COASTERFURNITURE.COM
PAGE 4 OF 4
Note:Dimension tolerance ±5%
√
STEP 3
HEATER BUTTON
FLAME BUTTON
FA18V60L-1
