1. This appliance must be installed in a suitably
ventilated room to prevent dangerous build up
of combustion products.
2. Installation must allow for a sufficient flow of fresh
air for the combustion air supply.
3. Installation must include adequate ventilation
means, to prevent dangerous build up of
combustion products.
4. Never directly connect a ventilation system to
the appliance flue outlet.
5. Position the appliance in its approximate
working position.
6. All air for burner combustion is supplied from
underneath the appliance. The legs must
always be fitted and no obstructions placed on
the underside or around the base of the
appliance, as obstructions will cause incorrect
operation and / or failure of the appliance.
7. Components having adjustments protected
(e.g. paint sealed) by manufacturer are only
allowed to be adjusted by a qualified service
agent. They are not to be adjusted by the
installation person.
NOTE:
Do not obstruct or block the appliance flue. Never
directly connect a ventilation system to the
appliance flue outlet.
NOTE:
Only non-combustible materials can be used in
close proximity to this appliance.
Any gas burning appliance requires adequate
clearance and ventilation for optimum and trouble-
free operation. The following minimum installation
clearances are to be adhered to:
* Side clearances can be 50mm when adjacent
surface is at least 100mm below cooking surface.
LH / RH
Side 250mm (*) 0mm
Rear 100mm 0mm
NOTE:
ALL GAS FITTING MUST ONLY BE CARRIED OUT BY A
QUALIFIED SERVICE PERSON.
1. Cobra Series Cooktops do not require an
electrical connection, they function totally on
the gas supply only.
2. It is essential that the gas supply is correct for the
appliance to be installed and that adequate
supply pressure and volume are available. The
following checks should be made before
installation:-
a. The Gas Type the appliance has been
supplied for is shown on coloured stickers
located above the gas entry point and next
to the rating plate. Check that this is correct
for the gas supply the appliance is being
installed for. The gas conversion procedure is
detailed in the Gas Conversion Instruction
Sheet for this appliance.
b. Supply Pressure required for this appliance is
shown in the 'Specifications' section of this
manual. Check the gas supply to ensure that
adequate supply pressure exists.
c. Input Rate of this appliance is also shown on
the Rating Plate located on front upper right
hand corner of cooktop cabinet and in the
'Specifications' section of this manual. The
input rate should be checked against the
available gas supply line capacity. Particular
note should be taken if the appliance is be-
ing added to an existing installation.
NOTE:
It is important that adequately sized piping runs
directly to the connection joint on the appliance,
with as few tees and elbows as possible to give
maximum supply volume.
3. Fit the gas regulator supplied, into the gas supply
line as close to the appliance as possible.
NOTE:
For Natural Gas, LPG Gas and Butane, the pressure
regulator provided with this appliance is convertible
between these gasses as per the ‘Gas Conversion
Section’ in this manual.
Ensure the regulator is converted to the correct gas
type that the appliance will operate on.
The regulator outlet pressure is fixed ex-factory for
the gas type that the regulator is converted to and it
is NOT to be adjusted.
TOWN GAS Only - Burner operating pressure is to be
adjusted using the adjustable gas regulator
supplied.
The regulator connections are 3/4” BSP female.
The connection to the appliance is 3/4” BSP male.
(Refer to the 'Specifications' Section for the gas
supply location dimensions).
C6 Cooktop C9 Cooktop
Natural Gas 23 m3/hr minimum 34 m3/hr minimum
LPG / Propane 24 m3/hr minimum 36 m3/hr minimum
Town Gas 23 m3/hr minimum 34 m3/hr minimum
