Assemble Frame

– Start with the Main Tent Pole and

gradually apply pressure to the pole,

forming an arch, until you are able to

insert the pole tip into the grommet on

the corner web. (illus. 2, illus. 3)

– Repeat for Side pole. (illus. 2, illus. 3)

Avior

™

part number 2000000452

Layout & Positioning

of Rainfly, Pole Assembly

– Layout and position Rainfly with doors facing

desired direction. (illus. 1) Unzip doors.

– For best results in windy conditions, position

back of tent into the wind.

– Insert the cap end of the Main Pole into front

sleeve. (illus. 1)

– Insert the cap end of the Side Pole into

back sleeve. (illus. 1)

Main Tent Pole (Red)

Part No. 9830-1111

Side Pole (Silver)

Part No. 9830-1211

Rainfly

Part No. 9830-1311

illus. 1

illus. 2

Insert Pole Tip

into grommet.

illus. 3

Tent frame up

POLE ASSEMBLY PARTS

Main Tent Pole

Side Pole

Things You Should Know

• Under certain conditions (cold weather, high humidity, etc.) condensation will form on the inside surfaces of your tent. Condensation

is caused by water vapor from your breath, perspiration, or any wet clothing inside your tent. It is NOT LEAKAGE through the tent

fabric. It can be minimized by removing wet clothing from your tent and by providing good ventilation through the tent.

• Never store tent, even for a short period of time, without

drying it thoroughly and brushing off caked dirt. Do not pack

stakes or poles inside your tent. Use separate storage bag.

• STAKES SHOULD BE REMOVED BY PULLING ON THE STAKE

ITSELF. NEVER PULL ON THE TENT FABRIC OR TENT STAKE

LOOP TO REMOVE STAKE.

• TENT POLES SHOULD NOT BE LEFT TELESCOPED TOGETHER

DURING STORAGE.

3600 N. Hydraulic • Wichita, Kansas 67219

1-800-835-3278 • www.coleman.com

3Attach Tent

– Layout the tent. (illus. 4)

– Position the tent in under the Rainfly

– Starting at the back of the tent, clip the tent to the

Rainfly in the corners and then the side. (illus. 6)

– Attach the top of the tent to underside of the

Rainfly with toggle and loops.

– Optional ground cloth in vestibule can be removed

or attached and clipped to the webbing at front of

the Rainfly. (illus. 6)

– Stake out rainfly doors, keep rainfly taut. (illus. 6)

– Attach Guy Lines to Guy Wings on back and sides

of the Rainfly and stake out. (illus.6).

illus. 4

Tent positions

in under Rainfly

illus. 6

Completed tent

with Rainfly.

Tent toggles to loops

on underside of Rainfly

illus. 5

Tent clips onto

pole stake loop

PRINTED IN CHINA Rev. 11/07
