Coleman 2000001653 Manuale utente

STITCH LINE

2-POLE SUN SHADE MODEL 2000001653

Before you begin

Read all instructions before set up.

• Select a level site clear of rocks, branches, and other hard or sharp objects, to install your sun shade.

WARNING: Keep clear of overhead power lines.

• Do not set up your sun shade under trees because of potential lightning strikes or falling tree limbs in inclement weather.

• Secure with all stakes and guylines provided to prevent property damage or personal injury.

• For best results in windy conditions, position narrow end of sun shade into the wind.

• Enlist the help of at least one other person to assist you when it is time to assemble the sun shade.

• Under no circumstance should this product be used to cover automobiles, marine products or similar.

Metal Poles (2) – Part No. 5010000658

ASSEMBLY PARTS

Sun Shade Assembly

1. Assemble the two shock-corded support poles. (Fig. 1)

2. Insert narrow metal tip on pole into metal grommet located on the

web strap of the long end of the sun shade. (Fig. 2)

3. Lift pole to upright position; then extend out the guylines tied onto

theweb strap. (Fig. 2)

4. Slip loop on each guyline over plastic stake and drive in at a slight

angle to secure. (Fig. 3)

5. Repeat steps 3 & 4 above for the remaining support pole and guylines.

6. Extend out remaining guylines and each corner of the sun shade until

taut and secure with plastic stakes. (Fig. 2)

(continued on other side)

Sun Shade (1)

Grommet

Guyline

Pole Tip

Fig. 1

Fig. 2

Fig. 3

Grommet

Guylines

Metal Pole

MODEL 2000002626

STITCH LINE

The Coleman Company, Inc. • 3600 N. Hydraulic • Wichita, Kansas 67219

1-800-835-3278 • www.coleman.com

MADE IN CHINA • PRINTED IN CHINA

Coleman®, , and are registered trademarks of The Coleman Company, Inc.

4010004157 (20081125)

Things You Should Know:

• Tree limbs, tree sap, bird droppings, or moisture steadily dripping off tree limbs can cause damage to the sun shade fabric and its coating resulting in leaks or

loss of flame-resistant properties.

• Never store this product, even for a short period of time, without drying it thoroughly and brushing off caked dirt. Do not pack stakes or poles inside your this

product. Use a separate storage bag.

• Stakes should be removed by pulling on the stake itself. NEVER PULL ON THE SUN SHADE TO REMOVE STAKES AS THIS COULD RESULT IN PROPERTY

DAMAGE OR PERSONAL INJURY.

• Metal poles should not be left telescoped together during storage.

• Do not leave this product set-up for weeks at a time. Be aware that exposure to ultraviolet rays from the sun can seriously damage material and/or cause it to

become discolored.

• This product is intended to provide protection from sunlight. It is not intended to be used during heavy rain, wind, hail, snow or other inclement weather.

Excess water build up can cause the frame system to become unstable, and possibly collapse, causing injury.

WARNING: Keep all flame and heat sources away from this tent fabric.

This tent meets the flammability requirements of CPAI-84. The fabric may burn if left in continuous contact with any flame source. The

application of any foreign substance to the tent fabric will render the flame-resistant properties ineffective.
