Setting up your Cololight PLUS
User Guide V1.0
LifeSmart Cololight PLUS is an ambient light
supporting split joint and color changing. It can be
placed on the table or installed as background
wall, suspended ceiling.
Cololight PLUS is HomeKit-enabled, you can use
Siri and Home app on iOS devices to control it.
Its unique functions like changing color with music,
voice control bring intelligent playing into lighting
system, providing dining, living and so many other
scenes with various experiences.
PRODUCT INTRODUCTION
Reset method: Press and hold the reset hole until
the green indicator light on the controller flashes.
Release the button and the device will reboot. Wait
about 10 seconds for the device to reboot success-
fully and complete the reset.
INSTALLATION INSTRUCTION
Mic
Control button
Reset
Creative Shape
Hexagon design, seamless connection and no
dark area on the surface.
FUN of DIY
various shapes with gorgeous effects to
creates joyful atmosphere.
16 Million Colors
3 color selection modes (Selected, Dynamic &
Customized).
Color Changing with Music
Dynamic effects & Sound activated.
FEATURES
Voice Control
support Siri & Amazon Alexa & Google Assistant.
App Control
Various playing methods, Dimmable function,
Auto ON/OFF.
Intelligent Scene Linkage
Auto lighting up when opening door (Should
be used with sensor).
No Hub Required
Directly controlled through App on mobile
device.
FEATURES
Light size
Light weight
Controller Size
Controller weight
Power cable length
Communication protocol
Operating frequency
Input
Operating temperature
Operating humidity
Material
Power consumption
Control mode
86x74.5x30.5mm
52.5g
46.5x30.5x28mm
54g
1m
Wi-Fi
2.4GHz (5GHz not supported)
5V DC, 2A
-5~45°C
5~90%
ABS/ABS+PC
Static 0.3W Maximal 5W
App/Voice/Control button
SPECIFICATIONS
Scan QR code or input following URL in your mobile
browser to download App.
http://www.ilifesmart.com/getapp_qlgp.html
Visit the iOS App Store or Google Play and search
for Cololight.
Pair up COLOLIGHT with your mobile device
according to the instruction on App.
Please check the FAQ in the
Cololight App if you have any
problems.
APP INSTRUCTION
NOTE
Use the CONNECTOR to fix the Controller unit PLUS
and the Cololight
INSTALLATION INSTRUCTION
Cololight
Controller unit PLUS CONNECTOR
The first Jack
The second Jack
Use the CONNECTOR to connect the COLOLIGHTs
together. One end of the CONNECTOR must
connect to the outer slot while other end must
connect to the inner slot.
CONNECTOR
Inner slot
INSTALLATION INSTRUCTION
FIXATOR
CONNECTOR
INSTALLATION INSTRUCTION
Use FIXATORs to strengthen stability. Notice that
FIXATOR must connect to single hole slots
between two COLOLIGHTs. It only strengthens the
structure without communication function.
FIXATOR
