Comedes Demecto 70 Manuale utente
Dehumidifier
Demecto 70
ENG-1 www.comedes.com
Table of contents
Foreword ........................................................................................................2
Safety information ...............................................................................3-4
Intended use .........................................................................................5
Operating instructions ......................................................................................5
Technical data .................................................................................................6
Layout ...........................................................................................................7
Setting up instructions .....................................................................................8
Before starting up ............................................................................................8
Starting up ................................................................................................8-10
Hose drainage ...............................................................................................10
Recommendations for drying with the Comedes Demecto 70 ...........................11-12
Maintenance ..................................................................................................13
Frequently asked questions .............................................................................14
EN
ENG-2 www.comedes.com
Dear customer,
Thank you for buying the Demecto 70 from Comedes GmbH.
You have purchased a powerful dehumidifier, which has been developed in
accordance with the latest technical standards. To ensure that your device
offers you faithful service for a long time, please study these operating instructions in
detail, especially the safety information.
If you still have any questions about the device after you have read the operating
instructions, please do not hesitate to contact us:
E-mail address: [email protected]
If you give us your telephone number, we shall call you back free of charge.
We look forward to all customer feedback and would be delighted to hear from you.
Yours sincerely,
Philipp Thannhuber
Managing Director
Comedes GmbH
ENG-3 www.comedes.com
WARNING:
Be sure to read the instructions before using for the first time. Any errors made in
following the safety information and instructions may result in an electric shock, fire
and/or serious injury. Keep all the safety information and instructions in a safe place
for future use.
Important:
Make sure that the power plug is removed from the socket outlet before opening
the device. Electric shock can cause fatal injury. Have repairs carried out only by an
authorized workshop.
Safety information
•Please note that the operating voltage is 230V 50Hz.
•Use the ON/OFF switch to switch the device “ON and OFF”. Do
not under any circumstances use the plug to switch the device
“ON and OFF”.
•Do not insert any objects (screwdrivers, etc.) into the inside
of the device.
•Place the machine on a stable, horizontal and dry surface.
•Do not clean the dehumidifier with water. Never spray the
device with water.
•Do not clean the device with inflammable liquids or cleaning
agents.
•Keep children away from the device.
•Never place any objects on the device and don‘t sit on the
device.
•Do not touch the air vents.
•Never cover the air inlet or outlet vents. Make sure that
sufficient clearance to surrounding walls or objects (minimum
50 cm to the sides and rear, and 50 cm to the top and front)
is maintained.
•Do not use the device if the power cable is damaged.
•Do not use the device in a washing room.
•Do not use the device in hermetically sealed spaces.
•Do not use the device in enclosed spaces smaller than 15m².
•Do not use the device outside the operating temperature
range of 5°C – 35°C.
•Always run the device for at least 35 minutes (risk of
damage to the compressor). The fact that the device
ENG-4 www.comedes.com
switches automatically in automatic mode is perfectly normal.
•Before you move the device, switch it off with the Off/On
switch first, then pull out the power plug and empty the
condensate collector.
•Cable extensions used must have a wire cross-section of at
least 1 mm2.
•Clean the air filter before it becomes heavily soiled. The
device works most effectively with a clean filter.
•Keep the water tank free of foreign bodies.
•Set up the device well clear of heaters or other heat-
generating units.
•The device must not be used in environments containing lots
of dust or chlorine.
•Use the device only if your socket outlet is fitted with a
residual current protective device (earth-leakage circuit-
breaker) circuit-breaker.
•The device is allowed to be used only by persons who are
physically and mentally capable of operating it in accordance
with these operating instructions, or by persons who have
been given training on the use of the device by a responsible
person.
•Never switch the device on or off with wet hands.
•Never attempt to carry out any repairs or modifications, either
of an electrical or a mechanical nature, on the device yourself.
•Do not allow children to play with any of the packaging such
as sheets of plastic.
•Keep a sufficient distance to the air outlet of the device.
•Do not operate the appliance near explosive, flammable or
corrosive materials.
•Plug the power cord firmly and securely into the socket.
•Operate the unit only to a grounded socket.
•Do not operate the dehumidifier on a power strip or extenion
cable.
•If the device switches off, also wait at least 10 minutes before
restart.
ENG-5 www.comedes.com
Intended use
The dehumidifier is designed only for use for dehumidifying in privately used rooms
(e.g. living rooms, bedrooms, storage areas or basements). The user must observe all
the operational parameters specified in this manual.
The device is allowed to be used only for its prescribed purpose. Any other use
is deemed to be a case of misuse. The user/operator and not the manufacturer will be
liable for any damage or injuries of any kind resulting from such misuse.
Operating instructions
The device is designed for a temperature range of between 5°C and 35°C. At below
5°C the humidity level tends to be very low, such that there is no need for a
dehumidifier. At above 35°C it is possible that the overheating guard will shut the
device down automatically.
The device does not have approval for operation outside the given temperature range.
To enable the dehumidifier to dehumidify the air to optimum effect, it warms the air.
The room temperature may therefore rise by 1-2 degrees. This is perfectly normal
and increases the efficiency of the device.
To operate efficiently in energy terms, the device switches off automatically once the
set humidity level has been reached. If the humidity level increases again, the device
switches on again automatically.
Always take the device from the front when you want to carry it.
The device switches off automatically when the water tank is full.
ENG-6 www.comedes.com
Technical data
Product name: Comedes Demecto 70
Voltage: 220~240V 50 Hz
Power rating: 930W
Dehumidifying capacity: 70 l / day (30°C 80% humidity)
Dehumidifying capacity (max.): 75 l / day
Weight: 18,6 kg
Permissible operating temperature: 5-35°C
Humidity operating range: 30-90% RH
Coolant / Quantity: R410a/305g
Refrigerant group: L1
Size of water tank: 4,8 l
Max. room size dehmidification: 120m² (ceiling height 2,3m)
Max. room size keeping dry: 240m² (ceiling height 2,3m)
Dimensions: 405 x 632 x 268 mm
Noise: < 51 dB
ENG-7 www.comedes.com
Layout
Control Panel
ENG-8 www.comedes.com
Setting up instructions
Remove all strips of adhesive tape which were used as transport braces. Make sure
that the device is stood securely on a dry surface.
Ensure that the device cannot cause any water damage if water were to escape
from water tank.
Before you start the device, always let it stand in its final position for at least 2
hours to allow the refrigerant to settle and ensure that there is no risk of damage to
the compressor.
Make sure that the device is not exposed to direct sunlight.
Check that the float is correctly positioned and moves easily.
Make sure that the water tank is correctly positioned.
Make sure that the socket outlet is fitted with a residual current protective device
circuitbreaker (earth-leakage circuit-breaker).
If you are unsure whether this is the case, ask your electrician or use a personal
protection plug (available from your DIY store).
To save power and to avoid potential danger, disconnect the device when it is not
operated.
Before starting up
Make sure, that the unit is switched off.
Starting up
Check the cable for damage before you insert the power plug. The device may only be
used if the power cable is in flawless condition. Plug in the power cable and switch the
unit with the ON/OFF switch.
IMPORTANT: Always allow the device to run for at least 35 minutes before you
switch it off, and never switch it on and off continuously in quick succession.
Otherwise there is a risk of damage to the compressor.
When the product shut down, please wait at least 3 minutes before moving the unit,
so that all water can run into the water tank.
The higher the humidity in a room and the higher the temperature in that room, the
more effectively the Comedes Demecto 70 can dehumidify the air.
The compressor therefore generates heat and warms up the air in the room. This is
perfectly normal and is no cause for alarm.
ENG-9 www.comedes.com
ON-/OFF Button:
Press this button to turn the unit on and press it again, to switch the unit off.
If the unit is switched on, the „operation“-LED flashs continuously.
If the unit has reached the setted humidity, the „operation“-LED flashs on and off.
Speed:
Use this button to switch between the two fan speeds.
Timer:
With the timer you can set the start- and run-time of the unit. You can set the time
between 1 and 24 hours. When the time is up, the unit will switch on or off.
When the timer LED is off, the unit is running in continuous mode.
To set a start time, press the timer button when the unit is in standby.
To set the run time of the dehumidifier, press the timer button when the unit is
switched on. After setting the run time, the time will be shown for about 5 seconds on
the display, then the current humidity is displayed again.
If you press the timer button again, the current run time will be displayed again for 5
seconds.
Humidity setting:
The device is equipped with a modern hygrostat (humidistat) and turns off
automatically after the desired humidity is reached, to save power.If the humidity
increase in the room again, the Comedes Demecto 70 will automatically restart.
Repeatedly pressing the humidity setting button, a target humidity of CO, 30%, 35%,
40%, 45%, 50%, 55%, 60%, 65%, 70%, 75%, 80%, 85%, 90% and AU could be
set. The hysteresis of the device is approximately 3%.
During operation, the current humidity is displayed on the display. If the actual
humidity is below 35% the display will show „LO“. When the humidity is above 95%
the display will show „HI“.
Memory Function
The unit has a memory function that saves the fan speed and target humidity setting
when the unit is switched off. If the dehumidifier is switched on again, it starts with
the saved settings.
Continuous operation (CO):
With the setting „CO“, the unit will dehumidify with maximum capacity and won‘t
switch off till the water tank is full.
Comfort mode (AU):
With this setting, the unit operates in an automatic mode, which is influenced by
temperature.
1. At a temperature below 5 ° C, the compressor stops.
2. At a temperature between 5 ° C and 20 ° C, a target humidity of 60% is
automatically set.
3. At a temperature between 20 ° C and 27 ° C, a target humidity of 55% is
automatically set.
4. At a temperature above 27 ° C, a target humidity of 50% is automatically set.
Important: After setting a value, don‘t press any other button within 5 seconds, to
save the setting.
Altri manuali per Demecto 70
2
Indice
Altri manuali Comedes Deumidificatore
Comedes
Comedes Demecto 70 Manuale utente
Comedes
Comedes Demecto 10 Manuale utente
Comedes
Comedes Demecto 10 Manuale utente
Comedes
Comedes Demecto 70 Manuale utente
Comedes
Comedes LTR 100 NEO Manuale utente
Comedes
Comedes BTR 50 Manuale utente
Comedes
Comedes Demecto 30 eco Manuale utente
Comedes
Comedes LTR 100 NEO Manuale utente
Comedes
Comedes LTR 100 NEO Manuale utente
Comedes
Comedes LTR 400 NEO Manuale utente
