Commax DP-2S Manuale utente

DOOR PHONE DP-2S

User Manual

•Thank you for purchasing COMMAX products.

•Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow

instructions to use a product exactly.

•The company is not responsible for any safety accidents caused by abnormal operation of the product.

Introduction .........................................................2

Important Safeguard ...........................................3

1. Parts names....................................................4

2. Wiring..............................................................5

3. Installation.......................................................6

4. Caution ...........................................................7

5. Operation ........................................................7

6. Specification ...................................................8

Contents

Your unit is designed so it can be flush mounted on the or used. When flush mounted on the wall, the stand permils you to the

unit for an gular of unit view. The model number is located on the bottom and record the serial number in the space provided

below(available). Refer to these numbers whenever you call upon your COMMAX dealer regarding this product.

Model No. Serial No.

To prevent fire or shock hazard, do not expose the unit to rain or moisture.

This symbol is intended to alert the use to the presence of uninsulated

“

“dangerous Voltage”

”

within the product’s enclose that

may be of sufficient magnitude to constitute a risk of electric shock to persons.

This symbol is intended to alert the use to the presence of important operating and maintemance(servicing) instructions in the

literature accompanying the appliance

CAUTION: To reduce the risk of electrix shick, do not remove cover(or back) no user-serviceable

part sinside refer servicing to quaured service personnel

caution

Rosk of electric shock

do not open

1. Introduction

▲

Damage Requiring Service: This equipment from the power source and source and refer servicing to qualified service personnel under the following

conditions:

ⓐwhen the power is damaged.

ⓑif liquid has been spiled or objects have hallen into the unit

ⓒif the equipment has been exposed to rain or water.

ⓓif the equipment has beem dropped or otherwise damaged.

ⓔwhen the equipment exhibits a distinct change in performance- this indicates a need for service.

▲

Water and Moisture: Do not use this product near water, for example, near a bath tub, wash bowl, kitchen sink, or laundru tub, in a wet basement, or near

a swimming pool, and the like.

▲

Accessories: The product may fall, causing serious injury to a child or adult, and serious damage to the appliance. Any mounting of the manufacture’s

insturctions, and should use a mounting accessory recommended by the manufacturer.

▲

Object and Liquid Entry: Never push objects of any kind into this product through openings as they may touch dangerous voltage points or short-out parts

that could result in a fire or electric shock. Never spill liquid of any kind on the product.

▲

Lightning: For added protection for this product before a lihgtning storm, or when it is left un attached and un used for long periods of time, unplug it from

the wall outlt and disconnect the other system. This will prevent damage to the product due to lightming and power-line surges. If you live in an

ared heavily prone to lightning stoms, it is recommended that you invest in power-line, telephone-line, RFcable and actuator/ polarization surge

protectors to protect your appliance system from possiple damage

2. Important Safeguards

3. Overview

①VOLUME CONTROL

②HANDSET

③DOOR RELEASE BUTTON

④S-CORD

⑤POWER CORD

Wiring

AC220V

•Non polarity wiring with Sub Unit(1) and Master Unit (2).

•Door Release(3) should be provided with additional power source.

OYP

OXP

zv|yjl

wv~ly

OZP

5. Installation

6. Caution

•It is only available with wall mount-type, not for desk type.

•Please do not install the product in the following place.

>>> Where there is much humidity and big difference in temperature.

>>> Where there is much sunlight and rain.

>>> Where there is much vapor and gas.

7. Operation

[SUB UNIT]

1. Electric chime call.

2. Back call tone for visitor.

3. Hands free talk within 30cm.

[MASTER UNIT]

1. Lift up handset(②) and talk when a call's coming.

2. Control a call sound with volume control(①).

3. Door release button(③) able to open the door.

6. Specification

model DP-2S

Power Source 100/110/120/220/230/240V~, 50/60Hz

Consumption Power 4.5W(MAX)

Distance 100m(Ø0.65mm), 150m(Ø0.8mm)

Wiring Call : 2-wire, DoorRelease : 2-wire(Ø1.6mm Copper wire)

Dimension(mm) 108(W)°X210(H)°X61.4(D)mm

Weight(g) 640g

Printed In Korea / 2012.03.105

513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea

Int’l Business Dept. : Tel.; +82-31-7393-540~550 Fax.; +82-31-745-2133

Web site : www.commax.com
