Commax DP-2S Manuale utente

DOOR PHONE DP-2S

User Manual

•Thank you for purchasing COMMAX products.

•Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow

instructions to use a product exactly.

•The company is not responsible for any safety accidents caused by abnormal operation of the product.

To prevent fire or shock hazard, do not expose

This symbol is intended to alert the use to the

“

“dangerous Voltage”

”

within the product’s enclose that

may be of sufficient magnitude to constitute a risk of

This symbol is intended to alert the use to the

accompanying the appliance

1. W arnings and Caution

the unit to rain or moisture.

presence of uninsulated

electric shock to persons.

presence of important operating and maintemance

(servicing) instructions in the literature

Handset

Call Volume Switch

Door Open Button

Power Cord

2. Overview

3. Operation

[SUB UNIT]

1. Electric chime call.

2. Back call tone for visitor.

3. Hands free talk within 30cm.

[MASTER UNIT]

1. Lift up handset and talk when a call's coming.

2. Control a call sound with volume control.

3. Door release button able to open the door.

CAUTION : To reduce the risk of electric shock, do not

personnel.

caution

Risk of electric shock

do not open

part inside refer servicing to qualified service

remove cover(or back) no user-serviceable

①VOLUME CONTROL

②HANDSET

③DOOR RELEASE BUTTON

④S-CORD

⑤POWER CORD

SCREW T4X50 (2EA)

(1)

(2)

(3)

1. Non polarity wiring with Sub

2. Door Release(3) should

Unit(1) and Master Unit (2).

additional power source.

4. Installation 5. W iring

be provided with

6. Specification

Model DP-2S

Power Source 100/110/120/220/230/240V~, 50/60Hz

Consumption Power 4.5W(MAX)

Distance 100m( Ø0.65mm), 150m( Ø0.8mm)

Wiring Call : 2-wire, Door Release : 2-wire(Ø1.6mm Copper wire)

Dimension(mm) 108(W)°X210(H)°X61.4(D)mm

Weight(g) 640g

Printed In Korea / 2016.04.105

513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea

Int’l Business Dept. : Tel.; +82-31-7393-540~550 Fax.; +82-31-745-2133

Web site : www.commax.com
