Auto Dialler Mode G8-TEL, G3-TEL
10 1.0/0609
Auto Dialler Mode
A call from an Intercom station or an input message is transferred to a pre-defined telephone number.
The call is transferred to another telephone number after a configurable time if the call is not answered
(i.e. taken over with a password) by this telephone, or immediately if the telephone is busy.
The order, in which the telephone numbers shall be dialled, is defined in “Dialling sequences“.
Telephone Numbers, Dialling Sequences
Up to 8 telephone numbers can be defined, which will be dialled in case of a call from e.g. a door
station, emergency call station etc.
For each telephone number up to 24 digits are possible.
These telephone numbers can be arranged in up to 8 different dialling sequences.
The dialling sequences set the order, in which the telephone numbers will be dialled.
The dialling sequences are selected with inputs, to which e.g. a time switch is connected.
Each dialling sequence can contain up to 15 telephone numbers; each number can be dialled se-
veral times (i.e. for a number it is possible to appear in one dialling sequence several times).
Example
Telephone numbers:
1. “Guard 1”
2. “Guard 2“
3. “Mobile Phone 1“
4. “Mobile Phone 2“
In the daytime, dialling sequence 1 is selected by a time switch.
When a call is initiated, the 1st telephone number of dialling sequence 1 is dialled (“Guard 1“).
If the call is not answered within a configurable time or if the number is busy, the next telephone
number of dialling sequence 1 is dialled, and so forth until the end of the dialling sequence
(“Guard 2“– “Guard 1“ – “Guard 2“...).
At a certain point of time (nighttime), dialling sequence 2 is selected by the time switch.
The order of the calls now is: 3x “Mobile Phone 1“, then 3 x “Mobile Phone 2“.
Note:
In case, the call is not taken over by the last telephone number, it is possible to restart the dialling se-
quence see ”Restart of Dialling Sequence” on page 12.
Dialling sequence 1: 1 2 1 2 1 2 1
Dialling sequence 2: 3 3 3 4 4 4
Dialling Sequence 1: 1st no.
# 0663/...1 2nd no.
# 0663/...2 3rd no.
# 0663/...3 4th no.
# 0663/...1 ........... 15th no.
# 0663/...15
Dialling Sequence 2: 1st no.
# 0663/...3 2nd no.
# 0663/...4 3rd no.
# 0663/...3 4th no.
# 0663/...5 ........... 15th no.
# 0663/...11
:
:
:
:
:
:
Dialling Sequence 8: 1st no.
# 0663/...7 2nd no.
# 0663/...7 3rd no.
# 0663/...8 4th no.
# 0663/...8 ........... 15th no.
# 0663/...20
