Commercial cool CCFE54 Manuale utente

1. READ these instructions carefully before installing and operating the

freezer. Keep them for further reference.

2. Record in the space below the “SERIAL NO.” found on the nameplate on

your freezer and retain this information for future reference.

SERIAL NO.:

Please save sales receipt for warranty.

User Manual

Chest Freezer

MODEL:CCFE35

CCFE54

CCFE7

Page 2

Staple your receipt to your manual.

You will need it to obtain warranty service.

Thank you for purchasing our

W Appliance product. This easy-to-

use manual will guide you in getting

the best use of your freezer.

Remember to record the model and

serial numbers. They are on a label

on the back of the product.

_____________________________

Model number

_____________________________

Serial number

_____________________________

Date of purchase

CONTENTS

PRODUCT REGISTRATION

SAFETY INFORMATION

Important Safety Instructions..........................................................................................................................................3-4

Refrigerant...................................................................................................................................................................................4

Grounding Instructions......................................................................................................................................................... 5

SET UP & USE

Installation Guide .....................................................................................................................................................................6

Starting your New Freezer................................................................................................................................................. 7

Parts & Features ....................................................................................................................................................................... 8

Operation Instructions......................................................................................................................................................8-9

CLEANING & CARE........................................................................................................................................ 10-11

TROUBLE SHOOTING & WARRANTY

Before You Call For Service ................................................................................................................................................12

Customer Service .....................................................................................................................................................................12

Troubleshooting..................................................................................................................................................................12-13

Limited Warranty..................................................................................................................................................................... 14

Page 3

IMPORTANT SAFETY INSTRUCTIONS

1. Use this appliance only for its intended purpose as described in this

use and care guide.

2. This freezer must be properly installed in accordance with the

installation instructions before it is used. See grounding instructions

in the installation section.

3. Never unplug your freezer by pulling on the power cord. Always

grasp the plug rmly and pull straight out from the outlet.

4. Do not operate any appliance with a damaged cord or plug. Return

appliance to the nearest authorized service facility for examination,

repair or adjustment.

5. Unplug your freezer before cleaning or before making any repairs.

Note: If for any reason this product requires service, we strongly

recommend that a certied technician performs the service.

Component parts shall be replaced with like components and

servicing shall be done by factory authorized service personell, so

as to minimize the risk of possible ignition due to incorrect parts or

improper service.

6. Do not use any electrical device or any sharp instrument in

defrosting your freezer.

7. DANGER – Risk of child entrapment. Before you throw away your

old freezer or freezer, take off the doors and leave the shelves in

place to that children may not easily climb inside.

NOTE: If the freezer has been placed in a horizontal or tilted position

for any period of time, wait 24 hours before plugging the unit

in.

SAFETY INFORMATION

DANGER

DANGER - Immediate hazards

which WILL result in severe

personal injury or death

WARNING

WARNING - Hazards or unsafe

practices which COULD result in

severe personal injury or death

WARNING

When using electrical appliances, basic safety precautions

should be followed, including the following

CAUTION

CAUTION - Hazards or unsafe

practices which COULD result in

minor personal injury

Page 4

8. After your freezer is in operation, do not touch the cold surfaces in

the freezer compartment, particularly when hands are damp or wet.

Skin may adhere to these extremely cold surfaces.

9. Do not refreeze foods that have been thawed completely. The

United States Department of Agriculture in Home and Garden

Bulletin No. 69 reads: “…You may safely refreeze frozen foods that

have thawed if they still contain ice crystals or if they are still cold-

below 40˚F.

“…Thawed ground meats, poultry, or sh that have any off-odor or

off-color should not be refrozen and should not be eaten. Thawed

ice cream should be discarded. If the odor or color of any food is

poor or questionable, discard it. The food may be dangerous to eat

… Even partial thawing and re-freezing reduce the eating quality of

foods, particularly fruits, vegetables, and prepared foods. The eating

quality of red meats is affected less than that of many other foods.

Use refrozen foods as soon as possible, to save as much of its eating

quality as you can.”

10. This freezer should not be recessed or built-in in an enclosed

cabinet. It is designed for freestanding installation only.

11. Do not operate your freezer in the presence of explosive fumes.

SAVE THESE INSTRUCTIONS

HOUSEHOLD USE ONLY

REFRIGERANT

GAS WARNINGS

• DANGER - Risk of re or explosion. Flammable refrigerant used. DO NOT use

mechanical devices to defrost freezer. DO NOT puncture refrigerant tubing.

• DANGER - Risk of re or explosion. Flammable refrigerant used. To be repaired

only by trained service personnel. DO NOT puncture refrigerant tubing.

• CAUTION - Risk of re or explosion. Flammable refrigerant used. Consult repair

manual/owner’s guide before attempting to service this product. All safety

precautions must be followed.

• CAUTION - Risk of re or explosion. Dispose of property in accordance with

federal or local regulations. Flammable refrigerant used.

• CAUTION - Risk of re or explosion due to puncture of refrigerant tubing; Follow

handling instructions carefully. Flammable refrigerant used.

SAFETY INFORMATION

DANGER

Risk of child entrapment. Before you throw away your old

freezer or freezer, take off the doors. Leave the shelves in place

so that children may not easily climb inside.

Page 5

GROUNDING INSTRUCTIONS

ELECTRICAL REQUIREMENTS

The electrical requirements are a 115 volt 60 Hz, AC only, 15 amp. It is recommended

that a separate circuit serving only the product be provided. The product is equipped

with a 3-wire cord having a 3-prong grounding plug. It must be plugged into a wall

receptacle that is properly installed and grounded.

This appliance must be grounded. In the event of an electrical short circuit, grounding

reduces risk of electric shock by providing an escape wire for the electric current.

The cord provided with this appliance is equipped with a grounding wire and a

grounding plug. The plug must be plugged into an outlet that is properly installed

and grounded.

Avoid the use of three prong adapters or cutting off the third grounding prong in

order to accommodate a two prong outlet. This is a dangerous practice since it

provides no effective grounding for the freezer and may result in shock hazard.

Consult a qualied electrician or serviceman if:

1) The grounding instructions are not completely understood.

2) You are unsure that the appliance is properly grounded.

3) You have any questions about the grounding or electrical instructions.

POWER SUPPLY CORD

1. Avoid the use of an extension cord because of potential safety hazards under

certain conditions. Have a qualied electrician or serviceman to install an outlet

near the appliance.

2. If it is absolutely necessary to use longer cord sets or an extension cord, extreme

care must be exercised.

a) Use only a grounding type 3-wire extension cord that has a 3-blade grounding

plug and a 3-slot receptacle that will accept the plug on the appliance.

b) The marked electrical rating of the cord set or extension cord must equal to

or greater than the electrical rating of the appliance. The longer cord should be

arranged so that it will not drape over the counter top or table top where it can

be pulled on by children or tripped over unintentionally.

NOTE: Neither W Appliance nor the dealer can accept any liability for damage to the product or

personal injury resulting from failure to observe the electrical connection procedures.

SAFETY INFORMATION

WARNING

Improper use of the grounding plug can result

in a risk of electric shock.

Page 6

INSTALLATION GUIDE

1. Unpack your freezer by removing all packaging materials like carton, base, foams,

adhesive tape, etc.

2. Remove all accessories, internal packaging material used to hold shelves, ice tray,

etc. in place.

3. Clean the remains of all adhesive tap used and remove all printed material

supplied.

4. Install the freezer in a convenient location away from extreme heat and cold.

Allow sufficient clearance between the freezer and side wall so the door(s) will

open without obstruction. Freezer is not designed for recessed installation.

5.The floor on which the freezer should be placed must be flat, hard, solid, and

even. The freezer should not be placed on any soft material such as foam, plastic,

etc.

6. The following are recommended minimum clearances around the freezer for

proper air circulation:

Sides: 4” (10cm)

Back: 4” (10cm)

Proper air circulation will help your freezer work at maximum efficiency.

NOTE: · The appliance must be correctly connected to the power supply.

WARNING

It is important to keep the power cord away from the compressor at the

back of the freezer as during operation, the compressor can reach a high

temperature and could cause serious damage to the power cord.

CAUTION

Care should be taken during the handling moving and use of the freezer to

avoid damaging the refrigerant tubing or increasing the risk of a leak.

SET UP & USE

Page 7

PROTECTION FROM HEAT AND MOISTURE

• Do not install your freezer in any location where heavy moisture is present or if

the location is not properly insulated. This freezer is not designed to operate in

temperature setting below 55° Fahrenheit.

• Location for the freezer should be on a hard surface and away from direct

sunlight and heat source, e.g., radiators, baseboard heaters, cooking appliances,

etc.

STARTING YOUR NEW FREEZER

1. After cleaning your freezer thoroughly. Wipe the outside with a soft dry cloth, the

interior with a clean moist cloth.

2. Insert the power supply cord into the electrical outlet.

3. Turn the thermostat dial to an initial setting of “7” for 24 hours and then set the

freezer to your desired setting.

NOTE: · As the door gets pressed in during shipping, the gasket may have to be reset. This is

done to prevent the cool refrigerated air from escaping. If there is a gap between the

door gasket and the cabinet, set the gasket by gently pulling it out of the seal gap.

SET UP & USE

PARTS & FEATURES

Page 8

TEMPERATURE CONTROL

OPERATION INSTRUCTIONS

NOTE: If the freezer has been placed in a horizontal or tilted position for any period of time,

wait 24 hours before plugging the unit in.

• The settings of the temperature control are 1 (warmest), 2, 3, 4, 5, 6, 7 (coldest).

Adjust the temperature control to the setting that best suits your needs.

• Turning the temperature to “0” position willl shut off the cooling cycle, but does not

turn off the electrical power to the unit.

• Unplug the unit to shut off the power to the unit.

NOTE:

• Wait 3-5 minutes before restarting if you unplug the freezer. The unit may fail to operate

properly if restarted too quickly.

• If the ambient temperature is too high, the freezer may not reach the desired

target temperature.

• Large amounts of food will lower the cooling efﬁciency of the appliance.

• Do not place the foods on the air outlet and leave space for airﬂow.

•If you choose to change the thermostat setting, adjust thermostat one increment at a time.

Allow several hours for temperature to stabilize between adjustments.

• If the temperature control knob sets to 7, the compressor may run continuously.

It’s a quick freeze mode, please do not set to 7 frequently.

RUNNINGPOWER

RUNNING

POWER

Controls

Drain

Adjustable

Leveling Legs

Power

Light

Compressor

On Light Temperature

Control

SET UP & USE

Page 9

FOOD STORAGE

• Your freezer has a basket. Removable baskets allow you to store food more

accesibly or you can them if not needed.

DEFROSTING & DRAINING

• Defrost whenever the frost becomes 1/8” thick. Never use a sharp or metallic

instrument to remove the frost, as it may damage the cooling coils. (A punctured

coil will void the warranty).

• Turn the temperature control to OFF position and unplug the unit. Remove the

drain plug from the inside of the freezer. Defrosting usually takes a few hours. To

defrost faster keep the door open.

• For draining place a tray beneath the outer drain dial. Turn the drain dial in a

counter-clockwise direction to remove (see g. #3). This will let the water ow

out into the tray. When nished, replace the drain dial and turn in a clockwise

direction to close. Note: Monitor the container under the drain to avoid overow.

• Wipe the interior of the freezer and replace the electrical plug in the electrical

outlet.

• Reset the temperature control to the desired setting.

SET UP & USE

Page 10

CLEANING AND

MAINTAINING

The freezer should be cleaned and

maintained once a month. Before doing

so, you must unplug the freezer.

POWER INTERRUPTION

In case of a power interruption/outage,

unplug the power cord from the wall

outlet. Replug the power cord to the

wall outlet once the power has been

restored. For long period of power

outage, inspect and discard the spoiled

or thawed foods from the freezer and

freezer compartments. Clean the freezer

thoroughly before using again.

CLEANING METHOD

Prepare a cleaning solution of 3-4

tablespoons of baking soda mixed with

warm water. Use sponge or soft cloth,

dampened with the cleaning solution to

wipe down your freezer.

• Rinse with clean warm water and dry

with a soft cloth,

• Do not use harsh chemicals,

abrasives, ammonia, chlorine bleach,

concentrated detergents, solvents or

metal scouring pads. Some of these

chemicals may dissolve, damage

and/or discolor your freezer.

DOOR GASKET

Clean door gaskets every three months

according to general instructions.

Gasket must be kept clean and pliable to

assure a proper seal.

• Petroleum jelly applied lightly on the

hinge sides of gaskets will keep the

gasket pliable and ensure a good

seal.

CLEANING AND CARE

WARNING

Always unplug your freezer before

cleaning to avoid electric shock.

Ignoring this warning

may result in death or injury

CAUTION

To avoid personal injury or

product damage always read and

follow manufacturer’s instructions and

warnings before using any

cleaning products.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali commercial cool Congelatore

commercial cool

commercial cool CCUK12W Manuale utente

Manuali Congelatore popolari di altre marche

Siemens

Siemens GU..D SERIES Manuale utente

Omcan

Omcan FR-CN-0155 Manuale utente

Beko

Beko FNE290E24W Manuale utente

Electrolux

Electrolux ARCTIS G 8 60 50-6I Manuale utente

Electrolux

Electrolux EUF2042AOX Manuale utente

Dometic

Dometic CoolFreeze CFX95DZ Manuale utente

Electrolux

Electrolux EUF7000W1 Manuale utente

Polar Electro

Polar Electro CT330 Manuale utente

MPM

MPM MPM-145-SK Series Manuale utente

SAF

SAF PRESTOTIG 200AC/DC Guida rapida

Zanussi

Zanussi ZFT11407WA Manuale utente

AEG

AEG A63190GT Manuale utente

AEG

AEG A81000TNW0 Manuale utente

Matsui

Matsui MUC50S15E Manuale utente

NEFF

NEFF G4344X8 Manuale utente

Frigidaire

Frigidaire FV 1246 H Manuale utente

Frigidaire

Frigidaire FFC13K1AW Manuale utente

Electrolux

Electrolux EU 2400C Manuale utente

commercial cool CCFE54 Manuale utente

Manuali Congelatore popolari di altre marche
