Compalcomm Penguin Lite CAP8 Manuale utente

User Guide

COMPALCOMM

Penguin Lite

CAP8

Contents

Your Phone ................................ 3

Home Screen ........................... 12

Text Entry ................................ 17

Calls ......................................... 23

Contacts ................................... 26

Messaging ............................... 31

Email ........................................ 36

Gmail ........................................ 41

Google Talk .............................. 44

Photos & Videos ...................... 46

Music ....................................... 55

Wireless Connections .............. 58

USB Connections ..................... 61

Internet .................................... 62

Maps ........................................ 66

Latitude .................................... 70

Navigation ................................ 73

Android Manager Agent ........... 73

Android Market™ ..................... 73

YouTube™ ............................... 75

Facebook ................................. 78

Twitter™ .................................. 81

News and Weather .................. 83

Quickoffice .............................. 85

Calendar ................................... 89

Clock ........................................ 92

FM Radio ................................. 94

Calculator ................................. 95

Sound Recorder ....................... 96

Speech Recorder ..................... 96

Voice Dialer .............................. 97

Settings ................................... 97

Safety & Regulatory ............... 107

3 Your Phone

Your Phone

Phone Overview

1. Earpiece

Listen to the phone conversation from

here.

2. Camera

Use for video calls.

3. LED indicator

See “LED Indicator” on page 7.

4. Touch screen

5. Home key

Touch to go to the Home screen.

6. Search key

Touch to use Google search.

7. Menu key

Touch to open menu options.

8. Back key

Touch to go back the previous screen.

9. Microphone

Your Phone 4

1. Power button

-Press and hold to turn the device on.

-When the device is turned on, press and

hold, then select Power off to turn the

device off.

-Press to turn the screen backlight on or off.

2. Earphone jack (3.5mm)

Connect the earphone for a hands-free

conversation or to listen to music.

3. Camera

See “Photos & Videos” on page 46.

4. Volume buttons

-Press up to raise or press down to lower

sound volume.

5. Back cover

6. Memory card slot

Insert a memory card to increase device memory. See “Storage Card” on

page 7.

7. Strap holder

8. USB connector

-Connect a USB cable to transfer files to and from a computer.

-Connect the Wall/USB charger to charge the battery.

5 Your Phone

Package Contents

•Phone

•USB cable

•Wall/USB charger

•Battery

Battery

Your device comes with a Lithium-ion

battery. Battery consumption

depends on the signal strength,

running applications, and settings

used.

Note: Use only the supplied battery

or batteries recommended by the

manufacturer.

Before installing the battery, you

must remove the back cover first.

To remove the back cover

1. Hold the device face down.

2. Place your

fingernail on

the grip then lift

the back cover.

To replace the

back cover

Align the back

cover to the device

then press the back

cover until it snaps

into place.

Install the Battery

1. Remove the back cover.

2. Insert the

battery with

the metal

contacts facing

those on the

device.

Your Phone 6

3. To replace the back cover.

Remove the battery

1. Make sure the device is turned

off.

2. Remove the back cover.

3. Place your

fingernail on

the grip then

lift to remove

the battery.

Charge the Battery

1. Connect the

USB cable to

the Wall/USB

charger, then

connect the

mini-USB side

of the cable to the connector on

the bottom of the device.

2. Plug the Wall/USB charger into a

wall outlet.

Note: You can also charge your

phone by plugging the USB cable into

your computer and the mini-USB side

into the device.

Warning:

•Do not remove the battery while

it is charging.

•Always remove the Wall/USB

charger from the wall outlet first

before removing the USB cable

from the device.

•Do not disassemble or open the

battery.

•Do not crush, bend, deform,

puncture, or shred the battery.

•Do not immerse the battery in

water or other liquid.

7 Your Phone

LED Indicator

The LED indicator on your device

shows the battery charging status.

SIM Card

Your SIM card contains your

subscription information, phone

number and contacts.

Install the SIM Card

1. Remove the back cover.

2. Remove the battery.

3. Insert the SIM

card into the

slot with the

metal contacts

facing the front

of the device.

Remove the SIM Card

1. Remove the back cover.

2. Remove the battery.

3. Slide the SIM card out of the slot.

Storage Card

Use a compatible microSD™ card for

additional storage space to save your

pictures, videos, and other files.

Install the Storage Card

1. Open the memory card slot

cover.

LED Indicator Status

Red Battery is charging.

Green Battery full.

Your Phone 8

2. Insert the

microSD™card

into the slot

with the metal

contacts facing

the front of the

device.

3. Push the microSD™card until it

snaps into place.

Remove the Storage Card

1. Open the memory card slot

cover.

2. Push the microSD™ card into the

slot to eject card.

Note: Do not remove the memory

card while downloading or saving

files to it. Doing so may damage the

card and cause data loss.

Turn Device On and Off

•Press and hold the Power button

to turn on the device.

•When turned on, press and hold

the Power button, then touch

Power off to turn off the device.

Silent Mode

1. When turned on, press and hold

the Power button.

2. Touch Silent mode to set the

device to silent mode.

To undo silent mode, repeat the

above steps.

Airplane Mode

1. When turned on, press and hold

the Power button.

2. Touch Airplane mode to set the

device to airplane mode.

9 Your Phone

To undo airplane mode, repeat the

above steps.

Note: For safety reasons, some

functions do not work in airplane

mode.

Sleep and Wake Device

To set the device to sleep mode,

press the Power button. The

backlight turns off.

To wake the device, press the Power

button again. The backlight turns on,

and the screen is locked.

Lock and Unlock Device

To avoid accidentally touching the

screen, set the Screen timeout

setting of your device to

automatically lock the screen after

being idle for a period of time. See

“Screen Timeout” on page 101.

To manually lock the touch screen,

press the Power button to set device

to sleep mode and lock the screen.

Unlock the Touch Screen

1. Press the Power button to turn

the backlight on.

2. Drag the lock icon to the right of

the screen to unlock.

Drag to unlock.

Your Phone 10

Adjust the Volume

Your device has the following system

volumes:

•Ringer: Sounds when there is an

incoming call or when a message

is received. Press the volume up /

down buttons to increase/

decrease volume.

•Media: Sounds when music or

video is played. During music or

video playback, press the volume

up/down buttons to increase/

decrease volume.

•In-call volume: The volume level

of a phone conversation. During a

call, press the volume up/down

buttons to increase/decrease

volume.

•Alarm: Sounds when the alarm

goes off. See “Clock” on

page 92.

Do the following steps to adjust the

volume at one time.

1. Touch > Settings > Volume.

2. Drag the Ringtone, Media, or

Alarm slider to adjust its volume.

Note: If “Use incoming call

volume for notifications” is

unchecked, the notification

volume can be adjusted

separately.

3. Touch OK.

Navigate Your Device

•Touch: Touch the screen with

your finger to highlight or select

items on screen or touch the

keys on your device

•Touch and hold: Touch and hold

an item to open its options

window.
