Compaq 1600XL Manuale utente

Presario 1600XL Series

Model 1600T, 1600-XL140, 1600-XL141, 1600-XL142, 1600-XL143, 1600-XL144,

1600-XL146, 1600-XL147, 1600-XL150 XL156, XL157, XL255, XL256, XL257, and XL258

Before You

Begin

Product

Description Specifications

Assignments

Battery

Operations Troubleshooting

Removal

Sequence

Parts

Catalog MSG Index

Welcome to the Maintenance & Service Guide (MSG)

Welcome to the Maintenance and Service Guide (MSG) for Compaq Presario 1600XL Series

Portable Notebooks. This online guide is designed to serve the needs of technicians whose

job is to repair Compaq products.

For copyright and trademark information, refer to the Notice section of this MSG. To locate

your unit’s serial number, to see symbol conventions, or to view technician’s notes, see the

Preface. This MSG is updated online as needed.

For comments or questions about the contents of this MSG, contact Compaq. The term

Notebook as referred to throughout this MSG is synonymous with the term Computer.

To report a technical problem, contact your Regional Support Center or IM Help Center.

For help on navigating in this guide, refer to Using this Guide.

Presario 1600XL Series

Model 1600T, 1600-XL140, 1600-XL141, 1600-XL142, 1600-XL143, 1600-XL144,

1600-XL146, 1600-XL147, 1600-XL150 XL156, XL157, XL255, XL256, XL257, and XL258

2 PRESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE 1600XL SERIES

Using this Guide

To use this guide effectively, refer to the list of bookmarks at the left of the screen. These

bookmarks help you navigate through the document quickly and easily. They are accessible

from anywhere in the Maintenance and Service Guide (MSG).

Viewing a Chapter

Click one of the bookmarks or the color-coded bubbles on the Welcome page to view a

chapter of this MSG.

Expanding and Hiding Topics

Click the +to expand or show the contents of a section, or click the –to hide the contents.

Opening another Chapter

Return to the Welcome page by clicking the bookmark, 1600XL Series Maintenance and

Service Guide, and then click the bookmark or color-coded bubble for another chapter.

Printing the MSG

For portable copies of this MSG, you can print single pages, multiple pages, or the entire

guide. In the Acrobat Reader, click File, and then Print... for printing options.

PPRESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE 1600XL SERIES BEFORE YOU BEGIN 1

Presario 1600XL Series

Model 1600T, 1600-XL140, 1600-XL141, 1600-XL142, 1600-XL143, 1600-XL144,

1600-XL146, 1600-XL147, 1600-XL150 XL156, XL157, XL255, XL256, XL257, and XL258

Before You Begin

Notice

The information in this guide is subject to change without notice.

COMPAQ COMPUTER CORPORATION SHALL NOT BE LIABLE FOR TECHNICAL OR EDITORIAL

ERRORS OR OMISSIONS CONTAINED HEREIN, NOR FOR INCIDENTAL OR CONSEQUENTIAL

DAMAGES RESULTING FROM THE FURNISHING, PERFORMANCE, OR USE OF THIS

MATERIAL.

This guide contains information protected by copyright. No part of this guide may be

photocopied or reproduced in any form without prior written consent from Compaq

Computer Corporation.

Compaq, Presario 1600XL Series Registered U. S. Patent and Trademark Office.

Microsoft, MS-DOS, and Windows are registered trademarks of Microsoft Corporation.

Windows 98 and Windows 2000 are trademarks of Microsoft Corporation.

The software described in this guide is furnished under a license agreement or

nondisclosure agreement. The software may be used or copied only in accordance with the

terms of the agreement.

Product names mentioned herein may be trademarks and/or registered trademarks of their

respective companies.

Maintenance and Service Guide

Compaq Presario 1600XL Series Notebook Computer

First Edition (June 2000) Compaq Computer Corporation

2 BEFORE YOU BEGIN P

RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE 1600XL SERIES

Presario 1600XL Series

Model 1600T, 1600-XL140, 1600-XL141, 1600-XL142, 1600-XL143, 1600-XL144,

1600-XL146, 1600-XL147, 1600-XL150 XL156, XL157, XL255, XL256, XL257, and XL258

Preface

This Maintenance and Service Guide is a troubleshooting guide for use as a reference guide

when servicing the Compaq Presario 1600XL Series Notebook Computers.

Compaq Computer Corporation reserves the right to make changes to the Compaq Presario

1600XL Series Notebooks without notice.

Symbols

The following words and symbols mark special messages throughout this guide.

ÅWARNING: Text set off in this manner indicates that failure to follow the

directions in the warning could result in bodily harm or loss of life.

ÄÄ

CAUTION:

Text set off in this manner indicates that failure to follow the directions

in the cautioncould result in damage to equipment or loss of data.

Important: Text set off in this manner presents clarifying information or specific

instructions.

Note: Text set off in this manner presents commentary, sidelights, or interesting

points of information.

Technician Notes

ÅWARNING: Only authorized technicians trained by Compaq should repair this

equipment. All troubleshooting and repair procedures are detailed to allow only

subassembly/module-level repair. Because of the complexity of the individual

boards and subassemblies, the user should not attempt to make repairs at the

component level or modifications to any printed circuit board. Improper repairs

can create a safety hazard. Any indications of component replacement or printed

circuit board modifications may void any warranty.

Serial Number

When requesting information or ordering spare parts, you should provide the Notebook

serial number to Compaq. The serial number location is underneath the Notebook.

PPRESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE 1600XL SERIES BEFORE YOU BEGIN 3

Presario 1600XL Series

Model 1600T, 1600-XL140, 1600-XL141, 1600-XL142, 1600-XL143, 1600-XL144,

1600-XL146, 1600-XL147, 1600-XL150 XL156, XL157, XL255, XL256, XL257, and XL258

Locating Additional Information

The following documentation is available to support this product:

•Compaq Presario 1600XL Series Notebook Computer documentation set

•Introducing Windows 98 Guide

•Introducing Windows 2000 Guide

•Service Training Guides

•Compaq Service Advisories and Bulletins

•Compaq QuickFind

•Compaq Service Quick Reference Guide

4 BEFORE YOU BEGIN P

RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE 1600XL SERIES

Presario 1600XL Series

Model 1600T, 1600-XL140, 1600-XL141, 1600-XL142, 1600-XL143, 1600-XL144,

1600-XL146, 1600-XL147, 1600-XL150 XL156, XL157, XL255, XL256, XL257, and XL258

Presario 1600XL Series

Model 1600T, 1600-XL140, 1600-XL141, 1600-XL142, 1600-XL143, 1600-XL144,

1600-XL146, 1600-XL147, 1600-XL150 XL156, XL157, XL255, XL256, XL257, and XL258

PRESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE 1600XL SERIES PRODUCT DESCRIPTION 1

Product Description

Models and Features

Additional Models on Next Page

Compaq Presario 1600XL Series Portable Notebook Computer Models

XL140 XL141

Display 12.1 inch TFT 12.1 inch TFT

Processor Celeron 466-MHz w/128 Cache Celeron 466-MHz w/128 Cache

Hard Drive 6.0GB 6.0GB

CD or DVD Drive 24 CD Drive 6X DVD Drive

Diskette Drive 3.5 inch Floppy Drive 3.5 inch Floppy Drive

Modem 56.0 Kbps Data/Fax with PCI-I 56.0 Kbps Data/Fax with PCI-I

Networking None None

Battery 3.2 Li-ION 3.2 Li-ION

System Memory 64 MB PC100 64 MB PC100

Misc 1 TV-Out TV-Out

XL142 XL143

Display 12.1 inch TFT 14.1 inch TFT

Processor Pentium III/500-MHz w/128

Cache

Pentium III/500-MHz w/128

Cache

Hard Drive 6.0GB 12.0GB

CD or DVD Drive 6X DVD Drive 6X DVD Drive

Diskette Drive 3.5 inch Floppy Drive 3.5 inch Floppy Drive

Modem 56.0 Kbps Data/Fax 56.0 Kbps Data/Fax

Networking None None

Battery 3.2 Li-ION 3.2 Li- ION

System Memory 64 MB PC100 64 MB PC100

2 PRODUCT DESCRIPTION P

RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE 1600XL SERIES

Presario 1600XL Series

Model 1600T, 1600-XL140, 1600-XL141, 1600-XL142, 1600-XL143, 1600-XL144,

1600-XL146, 1600-XL147, 1600-XL150 XL156, XL157, XL255, XL256, XL257, and XL258

Additional Models on Next Page

Compaq Presario 1600XL Series Portable Notebook Computer Models

XL144 XL145

Display 14.1 inch TFT 14.1 inch TFT

Processor Celeron 466-MHz w/128 Cache Pentium III 500-MHz w/256 Cache

Hard Drive 6.0GB 6.0GB

CD or DVD Drive 6X DVD Drive 6X DVD Drive

Diskette Drive 3.5 inch Floppy Drive 3.5 inch Floppy Drive

Modem 56.0 Kbps Data/Fax International

with PCI

56.0 Kbps Data/Fax International

with PCI

Networking None None

Battery 3.2 Li-ION 3.2 Li-ION

System Memory 64 MB PC100 64 MB PC100

Misc 1 TV-Out TV-Out

XL146 XL147

Display 14.1 inch TFT 14.1 inch TFT

Processor Pentium III 500-MHz w/256

Cache

Pentium III 500-MHz w/256 Cache

Hard Drive 12.0GB 12.0GB

CD or DVD Drive 6X DVD Drive 6X DVD Drive

Diskette Drive 3.5 inch Floppy Drive 3.5 inch Floppy Drive

Modem 56.0 Kbps Data/Fax 56.0 Kbps Data/Fax-I

Networking None None

Battery 3.2 Li-ION 3.2 Li-ION

System Memory 64 MB PC100 64 MB PC100

PRESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE 1600XL SERIES PRODUCT DESCRIPTION 3

Presario 1600XL Series

Model 1600T, 1600-XL140, 1600-XL141, 1600-XL142, 1600-XL143, 1600-XL144,

1600-XL146, 1600-XL147, 1600-XL150 XL156, XL157, XL255, XL256, XL257, and XL258

Additional Models on Next Page

* Modem Legend

1) 56K Mini PCI d/f 1 = Bear/Grizzly Modem/NIC Combo = NA, CKK, LA

2) 56K Mini PCI d/f 2 = Seminole = EMEA/APD

3) 56K Mini PCI d/f 3 = Seminole 2 = All AUS/NZ

Compaq Presario 1600XL Series Portable Notebook Computer Models

XL150 XL156

Display 14.1 inch TFT 12.1 inch TFT

Processor Celeron 500-MHz w/128 Cache PIII/600(256) FCPGA

Hard Drive 6.0GB 6.0GB

CD or DVD Drive 6X DVD Drive 24X

Diskette Drive 3.5 inch Floppy Drive 3.5 inch Floppy Drive

Modem 56.0 Kbps Data/Fax 56K Mini PCI d/f 1*

Networking None None

Battery 3.2 Li-ION 3.2 Li-ION

System Memory 64 MB PC100 64 MB PC101

XL157 XL255

Display 14.1 inch TFT 13.3 inch TFT

Processor PIII/600(256) FCPGA Cel/566(128) FCPGA

Hard Drive 6.0GB 6.0GB

CD or DVD Drive 6X DVD Drive DVD

Diskette Drive 3.5 inch Floppy Drive 3.5 inch Floppy Drive

Modem 56K Mini PCI d/f 1* 56K Mini PCI d/f 2*

Networking None None

Battery 3.2 Li-ION 3.2 Li-ION

System Memory 64 MB PC102 64 MB PC100

4 PRODUCT DESCRIPTION P

RESARIO NOTEBOOK MAINTENANCE AND SERVICE GUIDE 1600XL SERIES

Presario 1600XL Series

Model 1600T, 1600-XL140, 1600-XL141, 1600-XL142, 1600-XL143, 1600-XL144,

1600-XL146, 1600-XL147, 1600-XL150 XL156, XL157, XL255, XL256, XL257, and XL258

* Modem Legend

1) 56K Mini PCI d/f 1 = Bear/Grizzly Modem/NIC Combo = NA, CKK, LA

2) 56K Mini PCI d/f 2 = Seminole = EMEA/APD

3) 56K Mini PCI d/f 3 = Seminole 2 = All AUS/NZ

Compaq Presario 1600XL Series Portable Notebook Computer Models

XL256 XL257

Display 14.1 inch TFT 14.1 inch TFT

Processor PIII/650(256) FCPGA Cel/566(128) FCPGA

Hard Drive 6.0GB 12.0GB

CD or DVD Drive DVD DVD

Diskette Drive 3.5 inch Floppy Drive 3.5 inch Floppy Drive

Modem 56K Mini PCI d/f 2* 56K Mini PCI d/f 1*

Networking None None

Battery 3.2 LiON 3.2 LiON

System Memory 64 MB PC100 64 MB PC100

XL258

Display 14.1 inch TFT

Processor PIII/600(256) FCPGA

Hard Drive 12.0GB

CD or DVD Drive DVD

Diskette Drive 3.5 inch Floppy Drive

Modem 56K Mini PCI d/f 1*

Networking None

Battery 3.2 LiON

System Memory 64 MB PC100

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Compaq Computer portatile

Compaq

Compaq Evo N180 Manuale

Compaq

Compaq Armada E500 Series Manuale

Compaq

Compaq Presario CQ62-300 - Notebook PC Manuale d'uso e manutenzione

Compaq

Compaq 2230s - Notebook PC Istruzioni per l'installazione

Compaq

Compaq Presario 700 Series Manuale utente

Compaq

Compaq Presario CQ45 Manuale

Compaq

Compaq Armada 6500 - Notebook PC Manuale utente

Compaq

Compaq Evo Notebook N200 Series Manuale utente

Compaq

Compaq Armada E500 Series Scheda tecnica

Compaq

Compaq Compaq Presario Istruzioni di installazione e manutenzione

Compaq

Compaq Evo n1005v - Notebook PC Manuale operativo e di manutenzione

Compaq

Compaq Armada 7700 Guida di riferimento rapido

Compaq

Compaq Presario R3000 - Notebook PC Istruzioni per l'installazione

Compaq

Compaq Armada 7800 Guida di riferimento rapido

Compaq

Compaq Armada 100 Manuale

Compaq

Compaq PRESARIO 250029-001 Manuale utente

Compaq

Compaq Armada 7400 Series Specifiche tecniche

Compaq

Compaq ARMADA 6500 SM Manuale utente

Compaq

Compaq N115 Manuale

Compaq

Compaq Armada 110 Guida di riferimento rapido

Compaq

Compaq CONTURA AERO Manuale

Compaq

Compaq LTE 5000 - Notebook PC Manuale utente

Compaq

Compaq Armada 110 Guida di riferimento rapido

Compaq

Compaq Compaq Presario Scheda tecnica

Manuali Computer portatile popolari di altre marche

HP ze2401xt - Pavilion Notebook PC Manuale utente

Velocity

Velocity NoteMagix M10 Manuale utente

Dell

Dell Alienware 17 R2 Manuale utente

Toshiba

Toshiba A105-S2236 Manuale utente

HP ENVY 17 Manuale

Winbook

Winbook LM Manuale utente

Dell

Dell Inspiron 1464 Manuale utente

Dell

Dell Inspiron 15R 5537 Manuale utente

HP PROBOOK 4520S Manuale

Dell

Dell Latitude ATG D620 Manuale utente

Sony

Sony VAIO PCG-FX270 Manuale utente

Dell

Dell Latitude 7310 Manuale utente

Dell

Dell Precision GU806 Manuale utente

Sony

Sony VAIO PCG-R505JLK Manuale utente

Lenovo

Lenovo THINKPAD X32 Manuale utente

HP Compaq tc4200 Guida rapida

Toshiba

Toshiba mini NB300 Manuale utente

Lenovo

Lenovo ThinkPad X201 Tablet Manuale
