User’s Guide

Compaq TFT5030

Flat Panel Monitor

June 2001

Enhanced for accessibility

Compaq and Compaq logo Registered in U. S. Patent and Trademark

Office.

Microsoft, MS-DOS, Windows, Windows NT are trademarks of Microsoft

Corporation in the United States and other countries.

All other product names mentioned herein may be trademarks of their

respective companies.

Compaq shall not be liable for technical or editorial errors or omissions

contained herein. The information in this document is provided “as is”

without warranty of any kind and is subject to change without notice. the

warranties for Compaq products are set forth in the express limited

warranty statements accompanying such products. Nothing herein should

be construed as constituting an additional warranty.

CAUTION: Text set off in this manner indicates that failure to

follow directions could result in damage to equipment or loss of

information.

WARNING: Text set off in this manner indicates that failure to

follow directions could result in bodily harm or loss of life.

User’s Guide

Compaq TFT5030 Flat Panel Monitor

First Edition (June 2001)

Part Number: 235607-001

Product Features

The Compaq TFT5030 Flat Panel Monitor has an active matrix,

thin-film transistor (TFT), liquid crystal display (LCD). The

monitor features include:

■ 15-inch (38.1-cm) viewable area display

■ 1024 × 768 resolution, plus full-screen support for lower

resolutions

■ Wide viewing angle to allow viewing from a sitting or

standing position, or when moving side-to-side

■ Tilt and swivel capabilities

■ Removable base for flexible mounting solutions

■ Includes both VGA and DVI-D signal connectors; the DVI-

digital connection requires a special digital-compatible

graphics adapter card

■ Plug and Play capability if supported by your system

■ On-Screen Display (OSD) adjustments in six different

languages: English, Dutch, French, German, Italian, and

Spanish for ease of set-up and screen optimization

■ Programmable Sleep Timer

■ CD-ROM includes an information file (INF), Image Color

Matching file (ICM), Colorific Software package, the

Compaq LCD Display Assistant setup and configuration

utility, the Compaq Display LiteSaver utility, and product

documentation

■ Security lock slot

■ AssetControl

■ Energy Saver feature for Energy Star* compliance

Compaq TFT5030 Flat Panel Monitor User’s Guide 1

Product Features

■ Compliance with the following regulated specifications:

❏ EPA ENERGY STAR

❏ European Union CE Directives

❏ Swedish MPR II 1990

❏ Swedish TCO '99

Universal Driver Manager

This monitor may require a graphics driver (and/or .INF file) that

is compatible with your computer’s graphics adapter. The CD-

ROM included with this monitor contains an .INF file (see the

section on Information Files). Compaq has also created a

Universal Driver Manager (UDM) release that supports all

graphics adapters found on Compaq Deskpro and Compaq

Workstation products. The UDM eases graphics driver

deployment across Compaq platforms ensuring cross-

compatibility and backward-compatibility. The resulting solution

enables customers to manage and control ongoing software

maintenance costs. The UDM is available on the Compaq Support

Software CD for Compaq Desktop, Portable, and Workstation

Products and the Compaq World Wide Web site

(www.compaq.com).

2Compaq TFT5030 Flat Panel Monitor User’s Guide

Product Features

Information Files

This monitor includes a CD-ROM with two information files to

be installed onto your computer—an .INF file and an .ICM file.

■ The .INF file defines monitor resources and provides

specifications used by most operating systems to install

support software for certain hardware devices. The .INF file

ensures monitor compatibility and optimization with your

computer’s graphics adapter.

■ The .ICM file provides color matching consistency from

monitor screen to printer and is activated from within the

graphics programs that have this feature.

To install these files on your computer, follow the instructions on

the CD-ROM or on the "Configuring Your Compaq LCD

Monitor" card located in the Program License Agreement packet

along with the CD-ROM. INF file updates are downloadable by

clicking on: www.compaq.com/products/monitors/index.html

Compaq TFT5030 Flat Panel Monitor User’s Guide 3

Product Features

Setting Up the Monitor

To set up the monitor, ensure that the power is turned off to the

monitor, computer system, and other attached devices, then

follow these steps:

1. Place the monitor in a convenient, well-ventilated location

near your computer.

2. Connect the signal and power cables to the monitor 1.

3. Connect the DC connector of the AC adapter to the DC power

cable that extends from the monitor base.

4. Connect the AC cable 3 to the AC receptacle on the AC

adapter.

5. Connect the monitor signal cable 2to the appropriate video

connector on the rear panel of the computer.

6. Connect the power cable 4to an electrical wall outlet.

4Compaq TFT5030 Flat Panel Monitor User’s Guide

Product Features

Connecting the Monitor Cables

CAUTION: When connecting the monitor, be sure to use the AC

adapter supplied with the monitor. Failure to use this AC adapter

may result in damage to the monitor.

WARNING: To reduce the risk of electric shock or damage to

your equipment:

■ Do not disable the power cord grounding plug. The grounding

plug is an important safety feature.

■ Plug the power cord into a grounded (earthed) electrical

outlet that is easily accessible at all times.

■ Disconnect power from the monitor by unplugging the power

cord from the electrical outlet.

■ Do not place anything on power cords or cables. Arrange

them so that no one may accidentally step on or trip over

them. Do not pull on a cord or cable. When unplugging from

the electrical outlet, grasp the cord by the plug.

Compaq TFT5030 Flat Panel Monitor User’s Guide 5

Product Features

Note: For security purposes, this monitor has been fitted with a

slot for use with a security cable lock that can be purchased

separately at most computer stores.

Note: After you turn on the monitor, install the Compaq LCD

Display Assistant utility included on the CD-ROM. Use the on-

screen instructions to adjust the picture quality of your monitor.

To install this utility onto your computer, follow the instructions

on the "Configuring Your Compaq LCD Monitor" card located in

the Program License Agreement packet.

Important: Always activate a screen saver program, the

program-mable sleep timer, the Compaq Display LiteSaver

utility, or turn off the monitor when it is not in use for a

prolonged period of time. All LCD monitors that display the same

static image on the screen for a prolonged period of time may

exhibit screen image retention. Please note that image retention is

not a permanent condition and will fade over a period of time.

Image retention is a condition that may occur on all LCD screens.

6Compaq TFT5030 Flat Panel Monitor User’s Guide

Product Features

Connecting the Video Signal Cable

To connect the VGA analog or DVI-D (Digital Visual Interface-

Digital) cable to the corresponding connector on the back of the

monitor, you must first remove the monitor base cover.

Note: For the digital input to function, the VGA cable must be

disconnected from the monitor. If both VGA and DVI-D cables

are attached, the monitor will default to the VGA input.

WARNING: Before beginning to disassemble the monitor, be sure

the monitor is turned off and the power and signal cables are both

disconnected.

Note: The DVI-D cable supplied with this monitor is for digital

to digital connection only. Your computer must have a DVI-

compatible graphics card installed for use with this cable. When

connecting the DVI-D signal cable to the DVI connector on the

monitor, you must connect the other end of the DVI-D cable to

the DVI connector on the computer.

1. Lay the front bezel down on a soft area to prevent it from

getting scratched, defaced, or broken.

2. Remove the cover plate from the monitor base by placing

your fingers in the opening on the bottom of the base and

pulling upward, then pulling out to remove the cover.

3. Remove the back panel from the monitor by pushing the

bottom tabs upward and pulling out to remove the panel.

Compaq TFT5030 Flat Panel Monitor User’s Guide 7

Product Features

4. Connect the video cable to the corresponding connector on

the back panel of the monitor 1by threading the cable

through the neck on the monitor base to the connector, then

connect the other end of the cable 2to the appropriate video

connector on the back panel of the computer.

Connecting the Video Cable to the Monitor and Computer

5. Replace the monitor back panel and monitor base cover.

6. Reconnect the power cable and power on the monitor and

computer.

8Compaq TFT5030 Flat Panel Monitor User’s Guide
