GEN 3 & GEN 4

G.L.O.V.E.

Product User Guide


Compliant Technologies LLC Version 1.2
(859) 447-0576 Last updated:
[email protected] 11/19/2023 21:30
P.O. Box 24714, Lexington, KY 40524 Page 2of 24
1CONTENTS
Safety and Terms ...................................................................................................................................4
1 Safety .............................................................................................................................................4
2 Terms .............................................................................................................................................4
General Overview, Specifications, and Components ............................................................................6
1 Overview........................................................................................................................................6
2 Specifications.................................................................................................................................6
3 Training Model (CT-F2T) ................................................................................................................7
4 Component Identification..............................................................................................................7
Pre-Operational Checks .........................................................................................................................8
G.L.O.V.E. Use and Operation................................................................................................................9
1 Charging.........................................................................................................................................9
1.1 Generation 3 and 4 devices ...................................................................................................9
2 Replacing Micro-Processor..........................................................................................................10
2.1 GEN 3, 4 Devices ..................................................................................................................10
3 Digital Event Record Retrieval .....................................................................................................11
4 Powering On/Off..........................................................................................................................12
5 Activating on Subject’s Body .......................................................................................................12
6 Tap Test (Optional) ......................................................................................................................12
Medical, Physiological Effects and ExDS..............................................................................................13
1 Medical Considerations ...............................................................................................................13
2 Physiological Considerations .......................................................................................................14
3 Agitated Chaotic Event (ACE) previously known as Excited Delirium Syndrom (ExDS) and
Suicidal Considerations............................................................................................................................14
Tactical Considerations for Use of Force .............................................................................................15
Suggested ROE and Post-Incident Actions...........................................................................................17
1 Suggested ROE (Rules of Engagement) Levels.............................................................................17
1.1 Level 1..................................................................................................................................17
1.2 Level 2..................................................................................................................................18
1.3 Level 3..................................................................................................................................19
Post-Incident........................................................................................................................................19
1.1 CD3 Anonymous After-Action Report..................................................................................19


Compliant Technologies LLC Version 1.2
(859) 447-0576 Last updated:
[email protected] 11/19/2023 21:30
P.O. Box 24714, Lexington, KY 40524 Page 3of 24
Device Troubleshooting Procedure .................................................................................................19
Maintenance and Decontamination................................................................................................21
1 Precautions for Lithium-Ion Batteries .........................................................................................21
1.1 During Use ...........................................................................................................................21
1.2 During Charging ...................................................................................................................22
1.3 Battery Discharge.................................................................................................................22
1.4 Battery Storage....................................................................................................................22
2 Decontamination .........................................................................................................................23
Product Support, Warranty, and Contact Information ...................................................................24
1 Product Warranty ........................................................................................................................24
2 Compliant Technologies Contact Information.............................................................................24



Compliant Technologies LLC Version 1.2

(859) 447-0576 Last updated:

[email protected] 11/19/2023 21:30

P.O. Box 24714, Lexington, KY 40524 Page 4of 24

2SAFETY AND TERMS

2.1 SAFETY

CD3 Technology is not risk free and should be treated seriously like any other weapon. Follow all laws,

agency policies, and Tactics, Techniques, and Procedures (TTPs) when deploying the G.L.O.V.E. CD3.

2.2 TERMS

May result in injury or death if not followed or observed

May result in equipment damage or failure if not followed or observed

Informational notes or comments

CD3

Conductive Distraction and De-escalation Device

G.L.O.V.E.

Generated Low Output Voltage Emitter CD3

MAY

Optional at user’s discretion

NPI

Neuro-Peripheral Interference

ROE

Rules of engagement

SHOULD

Suggested course of action

TTP

Tactics, Techniques, and Procedures

WILL/SHALL

Mandatory and non-negotiable

ACE

Agitated Chaotic Event (ACE) previously known as ExDS (Excited Delirium

Syndrome)

Compliant Technologies LLC Version 1.2

(859) 447-0576 Last updated:

[email protected] 11/19/2023 21:30

P.O. Box 24714, Lexington, KY 40524 Page 5of 24

In order to operate The G.L.O.V.E., you must be trained and qualified on this tool. See your agency’s

instructor for training and qualification or contact Compliant Technologies for more information.

Once qualified and certified on The G.L.O.V.E., an individual’s certification is good for two years from the

date of course completion. All individuals will have to go through re-certification or instructor level

courses by the end of their second year. Failure to complete the bi-annual training will disqualify you from

using the device until you recertify.

Compliant Technologies LLC Version 1.2

(859) 447-0576 Last updated:

[email protected] 11/19/2023 21:30

P.O. Box 24714, Lexington, KY 40524 Page 6of 24

3GENERAL OVERVIEW,SPECIFICATIONS,AND COMPONENTS

3.1 OVERVIEW

The G.L.O.V.E. stands for Generated Low Output Voltage Emitter. It is a CD3 (Conductive Distraction and

De-escalation Device) available from Compliant Technologies LLC. It is a tool used within the Force

Continuum to assist Law Enforcement Corrections, Security, Military, and EMS personnel. It is not

intended to compete with or replace any existing tool but to supplement existing weapons and tools

within an agency’s policies and TTPs.

The G.L.O.V.E. is a Force Multiplier for officers operating within their agency’s current Force Continuum

when on their own or in mass.

3.2 SPECIFICATIONS

Table 1: Product Specifications

Specification

Specification Value

Available Sizes

S, M, L, XL, XXL depending on model

Battery life –continuous stimulation

2 hrs.

Battery life –standby mode

12-24 hrs.

Battery life –fully charged “shelf life”

Months, recommend charging

monthly

Charging time –full charge

2 hrs.

Power on/off mechanism

Wrist switch

Battery

User-replaceable 3.7V lithium ion

Battery lifetime

2000 charge/discharge cycles

Maximum Voltage:

210-380V (cannot go above 380V)

Maximum Current:

0.9-1.5A

Pulse Duration

105-115 us

Pulse Charge

84-125 uC

Pulse repetition rate

29.7-30.8 pps

Duty Cycle

0.32-0.35 %

Operation Temperature

14-122°F (-10-50°C)

Compliant Technologies LLC Version 1.2

(859) 447-0576 Last updated:

[email protected] 11/19/2023 21:30

P.O. Box 24714, Lexington, KY 40524 Page 7of 24

3.3 TRAINING MODEL (CT-F2T)

The CT-F2T is a special G.L.O.V.E. model designed specifically for training exercises. The CT-F2T operates

at 1/50th the power of a regular G.L.O.V.E. device. It is deal for training exercises without generating the

full effects of the G.L.O.V.E. which allows for more extensive training scenarios.

Figure 1: CT-F2T Training Model

3.4 COMPONENT IDENTIFICATION

Compliant Technologies LLC Version 1.2

(859) 447-0576 Last updated:

[email protected] 11/19/2023 21:30

P.O. Box 24714, Lexington, KY 40524 Page 8of 24

4PRE-OPERATIONAL CHECKS

All Compliant Technologies’ CD3s, including G.L.O.V.E. devices should be inspected for overall condition

prior to training or anticipated utilization. The pre-operational inspections should include a check of at

least the following items:

•Velcro adherence

•Tears or frays in materials inside and out

•General condition of Contact Pad

•Broken zippers

•Loose components

•Stains or contaminates

•On/Off Activation

•Operational “Tap Test” – Optional (See Section 0)

•Visually inspect charger and cable for frayed wiring or poor condition

•Check battery charge level

•If Generation 4 G.L.O.V.E. or higher, conduct tap test and verify recorded data via SD card or

User Management Software.

If any component is deemed unacceptable from the pre-operational checks, the device should be

removed from service.

If a single G.L.O.V.E. is inoperative, the other G.L.O.V.E. from the pair may still be utilized. A single

G.L.O.V.E. device is usually adequate for effective usage.

Compliant Technologies LLC Version 1.2

(859) 447-0576 Last updated:

[email protected] 11/19/2023 21:30

P.O. Box 24714, Lexington, KY 40524 Page 9of 24

5G.L.O.V.E. USE AND OPERATION

5.1 CHARGING

5.1.1 Generation 3 and 4 devices

GEN 3 and 4 G.L.O.V.E. devices are supplied with charging USB cables and AC mains charging cube. Prior

to use, inspect all components to ensure there are no frayed or broken wires.

The Battery and Micro-Processor (“B/MP”) contains four indicator LEDs and a charging USB port. To

begin charging, first access the B/MP by unzipping the zipper pouch on the G.L.O.V.E. Connect the

supplied USB cable to the B/MP charging port and to a powered USB charger or the supplied charging

cube.

Each of the four red indicators represents ~25% of charge. While charging, the indicators will illuminate

in sequence to reflect the charging status. Once charging is complete, all four indicators will be

illuminated then turn Green in color. Disconnect the USB charging cable and close the zipper pouch

before use.

Figure 2: GEN 3, 4 charging illustration

Compliant Technologies LLC Version 1.2

(859) 447-0576 Last updated:

[email protected] 11/19/2023 21:30

P.O. Box 24714, Lexington, KY 40524 Page 10 of 24

5.2 REPLACING MICRO-PROCESSOR

5.2.1 GEN 3, 4 Devices
