COMPRO CP180 Manuale utente
User’s Guide
V1-110607
P/N: 3GA0310721
Model No.
CP180
Before attempting to set up or operate this camera,
please read this user's guide and retain it for future
reference.
Analog Video Camera
Copyright
© 2011 Compro Technology, Inc. All rights reserved.
Trademark
Compro Technology is the registered trademark of Compro Technology
Inc. All other company and product names mentioned in this document are registered
trademarks of the respective companies.
Restriction
No part of this document may be copied or reproduced in any form or by any means
without the prior written consent of Compro Technology, Inc.
Disclaimer
Compro Technology makes no warranties with respect to this documentation and
disclaims any implied warranties of merchantability, quality, or tness for any particular
purpose. The information in this document is subject to change without notice.
COMPRO reserves the right to make revisions to this publication without obligation to
notify any person or entity of any such changes.
Revision History
2011/01/27 Original version
Compro Technology Inc.
www.comprosecurity.com
Tel. +886 2 2918 0169, Fax +886 2 2915 2389
3F, No.12, Alley 6, Lane 45, Pao Shin Road,
Hsintien District, New Taipei City 231, Taiwan
Compro CP180 - User's Guide
Compro CP180 - User's Guide
1
Contents
Contents
Table of Contents
Important Notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Hardware Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
IR Connector Pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Power Connector Pinout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installation & Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installing Lens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Connecting Video and Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
D/N Mode Jumper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Operating the Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Setup Menus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Camera Operation Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Technical Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Compro CP180 - User's Guide
Compro CP180 - User's Guide
2Important Notices
Regulatory Notice
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) This device
must accept any interference received, including interference that may cause undesired
operation.
FCC Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment o
and on, the user is encouraged to try to correct the interference by one of the following
measures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandreceiver.
• Connecttheequipmentintoanoutletonacircuitdierentfromthattowhichthe
receiver is connected.
• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
To assure continued compliance, any changes or modications not expressly approved
by the party responsible for compliance could void the user's authority to operate this
equipment.
Safety Rules
• Thecameraoughttobeinstalledbyaqualiedtechnician.
• Placethecameraonalevelsurfacewheneverpossible.
• Donotdropthecamerabodytotheground;itmaycausethedamagetomainparts.
• Pleasedonotdisassembleorremodeltheproduct;itmaycausedamageorre.
• Donotshake,moveordisturbthecamerawhenitisinoperation,assuchactions
may result in the malfunction of the device.
• Powerothecameraassoonasitisfoundsmokingorsmeltunusual.
• Pleasedonotplacethecameraaroundtheheatsources,suchastelevisionor
microwave oven.
Important Notices
Compro CP180 - User's Guide
Compro CP180 - User's Guide
3
Product Overview
Package Contents
Contact your local distributor should you nd anything missing from the package.
12 3 4
Analog camera (with body cap) x 1
Power terminal block x 1
IR terminal block x 1
User's guide x 1
Hardware Overview
Body cap – Remove the body cap to mount the lens you purchased.
Screw hole – For ceiling mount and bracket.
Screw hole – For ceiling mount and bracket.
DC auto iris lens connector – Connect to the cable from your DC auto iris lens.
Operation buttons – Used to perform OSD settings.
Video output terminal – Connect to a BNC video cable.
IR connector – Connect to a switch to control IR-cut lter externally. Under external
D/N mode, when the positive and negative pole are connected (with a jumper or
otherwise),theIR-cutlterwillbeused;whentheyaredisconnected,theIR-cutlter
will be removed.
Power input terminal – A 3-pin power connector.
Product Overview
Compro CP180 - User's Guide
Compro CP180 - User's Guide
4Product Overview
Note:
The camera is configured in digital day/night mode by default,
which does not use IR cut filter during daytime and nighttime.
And once the positive and negative pole of the IR connector are
disconnected, camera image will turn monochromatic. To switch to
external day/night mode, refer to the 'D/N Mode Jumper' section.
IR Connector Pinout
The following describes the pinout of the IR connector used to control IR-cut lter.
2 1
Pin Function
1
3.3V DC or floating: camera switches to night
mode with IR-cut lter removed.
Ground or connection to pin-2: camera
switches to day mode with IR-cut lter in use.
2 Ground
Power Connector Pinout
The following describes the pinout of the terminal power connector.
2
31
Pin Function
1 + 12V DC
2COM
3 24V AC
Compro CP180 - User's Guide
Compro CP180 - User's Guide
5
Installation & Connections
Installing Lens
Installation & Connections
The following describes how to attach your lens to the camera.
1. Remove the body cap at the front of the camera.
2. Screw the lens into the camera body. While you’re gently turning the lens
clockwise, you will hear a 'click'. Then twist the lens by another one-third inch to
rmly secure the lens. If you are installing a DC auto iris lens, connect the lens'
control cable to the DC iris connector located at the back of the camera.
Connecting Video and Power
1. Use a BNC video cable to connect the terminal BNC connector from the camera
to a mating BNC connector.
2. Attach the Power adapter (optional accessory) to the terminal power connector
on the camera. The recommended adapter specications is DC 12V/500mA or AC
24V/500mA. Then connect the power plug to a power outlet.
Analog Camera
Power Adapter
Monitor
Compro CP180 - User's Guide
Compro CP180 - User's Guide
6Installation & Connections
D/N Mode Jumper
The D/N mode jumper lets you toggle between digital day/night mode (default) and
external day/night mode. In digital D/N mode, the IR-cut filter is always removed. In
external D/N mode, the IR-cut lter is used/removed by connecting/disconnecting the
positive pole and negative pole of the IR connector. If you wish to externally control the
IR-cut lter, follow the description below to switch to external D/N mode.
1. Power o the camera and loosen the four screws shown in the below gure to
remove the back panel. Then gently pull out the main circuit board connected to
the back panel to reveal the D/N jumper as circled in the gure below.
D/N Jumper (J7)
2 1 3 2
Digital D/N
(Default)
Ext. D/N
2. Reset the jumper (J7) to pins 2-3 to use external D/N mode. Then re-attach the
back panel.
3. Connect the IR connector on the back panel to an external switch or light sensor.
4. Connect the camera to a monitor and power. Press the setting button on the
back panel to enter the OSD menu. Select 'DAY/NIGHT' item and set it as 'COLOR'
(in digital D/N mode, set the 'DAY/NIGHT' item as 'AUTO').
Compro CP180 - User's Guide
Compro CP180 - User's Guide
7
Operating the Camera
Setup Menus
Prior to using this camera, enter the setup menu and make the appropriate settings
for each item in accordance with the condition of the camera's monitoring area. Listed
below is the structure of the setup menu.
Setup Item Description Available
Options Submenu Items
LENS
Lets you select the iris
adjustment mode of your
lens.
AUTO /
MANUAL
Under 'AUTO': type,
mode, speed
SHUTTER /
AGC
Allows you to congure
the shutter speed and
auto gain control function.
AUTO /
MANUAL
Under 'AUTO': mode
and brightness for
high/low luminance
Under 'Manual': mode,
shutter, AGC
WHITE BAL Provides adjustment on
white balance.
ATW / PUSH
/ USER1 /
USER2 /ANTI
CR / MANUAL /
PUSH LOCK
Under 'ATW': speed,
delay cnt, atw frame,
environment
Under 'USER1/2':
b-gain, r-gain
Under 'MANUAL': level
BACKLIGHT
Enables or disables the
back light compensation
function.
OFF / BLC / HLC N/A
PICT
ADJUST Species video properties.
MIRROR /
BRIGHTNESS
/ CONTRAST /
SHARPNESS /
HUE / GAIN
Under 'MIRROR': o, on
Under 'BRIGHTNESS/
CONTRAST/
SHARPNESS/HUE/
GAIN': 0~255
ATR
Lets you switch on/o
the ATR (Adaptive Tone
Reproduction) function.
OFF / ON Under 'ON': luminance,
contrast
MOTION
DET
Congures the motion
detection mode. OFF / ON
Under 'ON': detect
sense, block disp,
monitor area, area sel,
top, bottom, left, right,
right
Operating the Camera
Compro CP180 - User's Guide
Compro CP180 - User's Guide
8Operating the Camera
Setup Item Description Available
Options Submenu Items
PRIVACY Protects sensitive areas in
the scene. OFF / ON
Under 'ON': area sel,
top, bottom, left, right,
color, transp, mosaic
DAY /
NIGHT
Congures the day/night
function.
AUTO / COLOR/
B/W
Under 'AUTO': burst,
delay cnt, day > night,
night > day
Under 'B/W': burst
NR
Provides settings for the
digital noise reduction
function.
NR MODE o, y, c, y/c
CAMERA ID
Creates a camera title
to be displayed on the
screen.
OFF / ON Under 'ON': key-in ID,
chr1, chr2, clr, pos
LANGUAGE Changes the language of
the setup menu
ENGLISH /
DEUTSCH /
FRANCAIS /
PУCCKИЙ /
PORTUGUĔS /
ESPAÑOL
N/A
CAMERA
RESET
Restores all the settings to
the default value N/A N/A
