COMPX TYPE360 Guida
CB-36X
03/24/03
TYPE 360GLASS DOOR DEADBOLT LOCK
915 Sherwood Drive
Lake Bluff, IL 60044
DRAWING#
DATE
Phone: 847-234-1864
Fax: 847-234-7922
.85
21.5
1.20
30.5
1.65
41.9
.50
12.7
CAM IN LOCKED POSITION
.30
7.6
PART NUMBERS:
CB-361 NICKEL FINISH
CB-365 BRASS FINISH
CB-367 SATIN NICKEL FINISH
1.12
28.5
.41
10.4
SET SCREW
TIGHTENS LOCK
TO GLASS DOOR
LOCK SLIPS ON TO
EDGE OF GLASS DOOR
AT ANY LOCATION
NO BORING REQUIRED
Questo manuale è adatto per i seguenti modelli
