PACKING CONTENTS
CBP6324DN-HD
Important: Ensure all cautionary procedures are
observed during installation.
It is recommended the camera is tested during the most
demanding environmental conditions such as low light
or bright sunlight to ensure continuity of effective CCTV
monitoring.
lUsing the supplied fitting screws, securely attach the
camera to the drilled surface
lAdjust the tri-axis gimbal zoom/focus to give the
required image of the area to be monitored.
lReplace the dome cover by pushing firmly in place
onto the base
lCarefully clean the dome surface with a soft lint
free cloth
lRemove the camera unit carefully from the box
reserving the accessory contents in a safe place
lUse the supplied mounting template to mark the
space for drilling
lRemove the dome cover using a suitable coin or
screwdriver
FIXING TO A WALL
CBP6324DN-HD
INTERNAL DOME INSTALLATION
Ceiling
Wall Plugs
X4
Mounting Template
X1
Fitting Screws
X4
1. This installation should be made by a qualified service person and should abide to all local
codes.
2. Avoid installation on a surface subjected to frequent vibration or shocks.
3. Do not operate the camera beyond its temperature range or power source ratings.
4. Should any damage or suspected damage occur, shutdown the power source, unplug and
contact your service provider.
5. Do not install the camera under unstable lighting conditions. Severe lighting change or
flicker can cause the camera to work improperly.
6. Never use the camera close to a gas or oil leak.
7. Do not disassemble the camera.
8. Never keep the camera face to strong light directly.
9. Ensure all removable covers are replaced to protect the inner components.
10. Do not install near devices which emit a strong electro-magnetic field.
11. Use a dry or damp cloth only for cleaning.
12. Internal dome only - Do not drop the camera or subject the unit to physical shocks.
PLEASE FOLLOW THE ABOVE CAUTIONS – FAILURE TO DO SO MAY
INVALIDATE THE WARRANTY OR CAUSE SERIOUS INJURY.
