Connect Tech SSD/104 SATA Manuale utente

SSD/104 SATA

User Manual

Connect Tech Inc.

42 Arrow Road

Guelph, Ontario

N1K 1S6

Tel: 519-836-1291

Toll Free: 800-426-8979 (North America only)

Fax: 519-836-4878

Email: sales@connecttech.com

[email protected]

Web: www.connecttech.com

CTIM-00146 Revision 0.00

Connect Tech SSD/104 SATA User Manual

Revision 0.00

Limited Lifetime Warranty

Connect Tech Inc. provides a lifetime warranty for all of our products. Should this product, in

Connect Tech Inc.’s opinion, fail to be in good working order during the warranty period,

Connect Tech Inc. will, at its option, repair or replace this product at no charge, provided that the

product has not been subjected to abuse, misuse, accident, disaster or non Connect Tech Inc.

authorized modification or repair.

You may obtain warranty service by delivering this product to an authorized Connect Tech Inc.

business partner or directly to Connect Tech Inc. along with proof of purchase. Product returned

to Connect Tech Inc. must be pre-authorized by Connect Tech Inc. with an RMA (Return

Material Authorization) number marked on the outside of the package and sent prepaid, insured

and packaged for safe shipment. Connect Tech Inc. will return this product by prepaid ground

shipment service.

The Connect Tech Inc. lifetime warranty is defined as the serviceable life of the product. This is

defined as the period during which all components are available. Should the product prove to be

irreparable, Connect Tech Inc. reserves the right to substitute an equivalent product if available

or to retract lifetime warranty if no replacement is available.

The above warranty is the only warranty authorized by Connect Tech Inc. Under no

circumstances will Connect Tech Inc. be liable in any way for any damages, including any lost

profits, lost savings or other incidental or consequential damages arising out of the use of, or

inability to use, such product.

The information contained in this document is subject to change without notice. Connect Tech

Inc. shall not be liable for errors contained herein or for incidental consequential damages in

connection with the furnishing, performance, or use of this material. This document contains

proprietary information that is protected by copyright. All rights are reserved. No part of this

document may be photocopied, reproduced, or translated to another language without the prior

written consent of Connect Tech Inc.



2012 by Connect Tech Inc.

Trademark Acknowledgment

Connect Tech Inc. acknowledges all trademarks, registered trademarks and/or copyrights

referred to in this document as the property of their respective owners.

Not listing all possible trademarks or copyright acknowledgments does not constitute a lack of

acknowledgment to the rightful owners of the trademarks and copyrights mentioned in this

document.

Connect Tech SSD/104 SATA User Manual

Revision 0.00

Table of Contents

Limited Lifetime Warranty............................................................................................................................................... 2

Copyright Notice............................................................................................................................................................... 2

Trademark Acknowledgment............................................................................................................................................ 2

Table of Contents.............................................................................................................................................................. 3

Revision History............................................................................................................................................................... 3

Customer Support Overview............................................................................................................................................. 4

Contact Information.......................................................................................................................................................... 4

Introduction....................................................................................................................................................................... 5

Product Features ............................................................................................................................................................... 6

Board Diagram.................................................................................................................................................................. 7

Block Diagram.................................................................................................................................................................. 8

Part Number Information.................................................................................................................................................. 9

Power Sourcing Explaination...........................................................................................................................................10

Hardware Installation Information...................................................................................................................................10

mSATA SSD Module Information ..................................................................................................................................10

Using SATA Port from the PCIe/104 Type 2 Bus...........................................................................................................11

mSATA Slot Connector Pinout........................................................................................................................................12

Revision History

Revision

Date

Author(s)

Change(s)

0.00

02-10-2012

Initial Manual Revision Created

Connect Tech SSD/104 SATA User Manual

Revision 0.00

Customer Support Overview

If you experience difficulties after reading the manual and/or using the product, contact the

Connect Tech Inc. reseller from which you purchased the product. In most cases the reseller can

help you with product installation and difficulties.

In the event that the reseller is unable to resolve your problem, our highly qualified support staff

can assist you. Our support section is available 24 hours a day, 7 days a week on our website at:

www.connecttech.com/sub/support/support.asp. See the contact information section below for

more information on how to contact us directly. Our technical support is always free.

Contact Information

We offer three ways for you to contact us:

Mail/Courier

You may contact us by letter at: Connect Tech Inc.

Technical Support

42 Arrow Road, Guelph, ON

Canada N1K 1S6

Email/Internet

You may contact us through the Internet. Our email and URL addresses on the Internet are:

[email protected]m

www.connecttech.com

Note:

Please go to the Download Zone or the Knowledge Database in the Support Center on the

Connect Tech Inc. website for product manuals, installation guides, device driver software and

technical tips. Submit your technical support questions to our customer support engineers via

the Support Center on the Connect Tech Inc. website.

Telephone/Facsimile

Technical Support representatives are ready to answer your call Monday through Friday, from

8:30 a.m. to 5:00 p.m. Eastern Standard Time. Our numbers for calls are:

Telephone: 800-426-8979 (North America only)

Telephone: 519-836-1291 (Live assistance available 8:30 a.m. to 5:00 p.m. EST, Monday to

Friday)

Facsimile: 519-836-4878 (online 24 hours)

Connect Tech SSD/104 SATA User Manual

Revision 0.00

Introduction

The SSD/104 SATA is a complete rugged stackable storage solution. This product allows for up to two

mSATA SSD modules to be installed into any PC/104 stack or embedded type system.

This allows users to easily integrate a high performance, high capacity storage solution directly onto their

embedded PC/104 stack. This solution eliminates the need to use larger 2.5” magnetic or solid state drives,

while greatly reducing the overall storage footprint in your embedded system.

Because the SSD/104 SATA leverages installing the latest generation technology of modular mSATA SSD

modules, your systems capacity and performance can easily be upgraded as new modules are released.

Another benefit to using the SSD/104 SATA with mSATA SSD modules is that it directly interfaces to the

standard SATA bus and can be a drop-in replacement for any SATA type storage device.

The SSD/104 SATA can be interfaced to any SBC or embedded type system using standard 7-pin SATA.

As well as having the option for cable-free usage using the PCIe/104 Type 2 standard which passes the

SATA signals directly over the bus connector.

The SSD/104 SATA can purchased from Connect Tech as a complete storage solution with the mSATA

modules already installed or the product can also be purchased as a mSATA carrier in which case the user

can source and install their own mSATA SSD modules.

Connect Tech SSD/104 SATA User Manual

Revision 0.00

Product Features

Specification

Details

SSD Slots

2 x mSATA SSD slots (JEDEC MO-300B compatible)

Storage Capacities

Options

4GB, 8GB, 16GB, 32GB, 64GB, 128GB, 256GB (per mSATA slot)

** Or larger as new mSATA modules come to market

Flash Type Options

SLC or MLC

Operating

Temperature Options

Industrial (-40 to +85) or Commercial (0 to +70)

Power Requirement

+3.3V / 0.5A max

Which can be sourced by PCIe/104 Bus, PCI-104 Bus or External Connector

Interface

SATA Revision 2.6

SATA II 1.5Gbps / 3.0Gbps

Will work with any SBC SATA port

Performance

Numbers may vary

depending on mSATA

module used

Host Transfer Rate: 300MB/s

Sequential Read: Up to 270MB/s

Sequential Write: Up to 240MB/s

Random Read IOPS: Up to 35k

Random Write IOPS: Up to 30k

SSD/104 Carrier

Dimensions

(Overall Board Size)

3.550” x 3.775” (90.17mm x 95.89mm)

PC/104 Compliant

mSATA SSD Module

Dimensions

2.000” x 1.175” (50.80mm x 29.85mm)

JEDEC 300-MB Compliant

Mini PCIe Form Factor Compliant

Power

Supply Voltage: +3.3V ±5%

Low Power Consumption: 260mA (Active) / 130 mA (Idle)

Power is sourced directly from the PCIe/104 bus, PCI-104 bus or the external power

connector

Connectors

Standard Right Angle 7-pin SATA data connectors

mSATA Connectors

PCI-104 stacking connector (optional)

PCIe/104 stacking connectors (optional)

3.5mm pitch Phoenix Type power connector

Build Options

PCI/104-Express Build –Both PCIe/104 and PCI-104 stacking connectors installed

PCIe/104 Build –Only the PCIe/104 stacking connector is installed

PCI-104 Build –Only the PCI-104 stacking connector is installed

No Bus Build –No stacking bus connectors installed

Cable-Free Operation

Option

(PCIe/104 Type 2)

The SSD/104 SATA also has the option to take the SATA signals directly from any PCIe/104 or

PCI/104-Express Type 2 SBC, eliminating the need to use any SATA cables.

mSATA SSD ports

Up to 2 mSATA SSD modules can be installed

Connect Tech SSD/104 SATA User Manual

Revision 0.00

Board Diagram

Connect Tech SSD/104 SATA User Manual

Revision 0.00

Block Diagram

Connect Tech SSD/104 SATA User Manual

Revision 0.00

Part Number Information

Part Number

Features

SDG001

Full Build –Both PCIe./104 and PCI-104 Connectors are installed

SDG002

PCIe/104 Build –Only PCIe/104 Connector is installed

SDG003

PCI-104 Build –Only PCI-104 Connector is installed

SDG004

No bus connectors installed, external power must be used.

To order any of these part numbers or to inquire about the other available ordering options please contact

[email protected]m for further information.

Connect Tech SSD/104 SATA User Manual

Revision 0.00

Power Sourcing Explaination

The SSD/104 SATA board powers it’s mSATA modules from +3.3V. This voltage rail can be provided

from the PCI-104 bus +3.3V rail, the PCIe/104 bus +3.3V rail or from the external +3.3V power connector

on the board. It is important to check whether your SBC or SBC’s power supply provides +3.3V over the

embedded buses, if the SBC does NOT provide +3.3V power over the bus connectors the external power

connector MUST be used.

The SSD/104 SATA board also has Ferrite Beads located near each power source that can be populated or

de-populated to select the sourcing from a particular voltage rail, in most cases the default configuration of

all installed will be adequate. These ferrites have the following designators L2, L3, and L4.

Hardware Installation Information

Please follow these steps with installing the SSD/104 SATA into your system.

1) Ensure your SBC is powered OFF

2) Install the SSD/104 SATA card onto your PC/104 stack (if available)

3) Install mSATA modules into mSATA slots on carrier

4) Connect SATA cables from SSD/104 Carrier to SBC

5) Power ON your SBC

mSATA SSD Module Information

Connect Tech’s SSD/104 SATA Carrier board allows for the installation of 2 mSATA SSD Modules.

mSATA modules should be JEDEC MO-300B compatible pinout and size. mSATA SSD modules are not

only small in size and rugged but extremely and can drastically reduce boot time.

Both SLC and MLC flash types can be used as well as commercial and industrial operating temperature

grades.

mSATA is a relatively new format for ultra-small Solid-State Disks (SSDs), developed by Intel. mSATA

SSDs take a form factor similar to mini-PCI Express cards, and is now adopted by many manufactures, see

below for a current listing of popular vendors with mSATA SSD modules available.

Listing of mSATA SSD Module Vendors

ADATA

AMP Inc.

Apacer

Delkin

innodisk

Intel

Kingston

Memoright

NetList

OCZ

Renice

RunCore

Samsung

Super Talent

Swissbit

mSATA size comparison

Altri manuali per SSD/104 SATA

Indice

Altri manuali Connect Tech Hardware per computer

Connect Tech

Connect Tech CANpro/104 Manuale utente

Connect Tech

Connect Tech CPG004 Manuale utente

Connect Tech

Connect Tech Xtreme/104 Plus Manuale utente

Connect Tech

Connect Tech PCIe/104 Manuale utente

Connect Tech

Connect Tech Rudi-NX Manuale utente

Connect Tech

Connect Tech BLUESTORM UNIVERSAL PCI Manuale utente

Connect Tech

Connect Tech NVIDIA Jetson GMSL Camera Platform Manuale utente

Connect Tech

Connect Tech Rudi-NX Manuale utente

Connect Tech

Connect Tech Blue Heat/PCI PCI Serial Communications Manuale utente

Connect Tech

Connect Tech NVIDIA Jetson AGX Xavier GMSL Manuale utente

Connect Tech

Connect Tech CTIM-00080 Manuale utente

Connect Tech

Connect Tech Xtreme/10G Manuale utente

Connect Tech

Connect Tech NGX012 Manuale utente

Connect Tech

Connect Tech FreeForm/PCI-104 Manuale utente

Connect Tech

Connect Tech Rogue-X2 Manuale utente

Connect Tech

Connect Tech FPD-Link III Manuale utente

Connect Tech

Connect Tech NVIDIA Jetson TX2 Manuale utente

Connect Tech

Connect Tech CANpro/104-Plus Opto Manuale utente

Connect Tech

Connect Tech Xtreme/104-Express Manuale utente

Connect Tech

Connect Tech ComSync/104 Manuale utente

Connect Tech

Connect Tech SMARC 2.0 Carrier Manuale utente

Connect Tech

Connect Tech NVIDIA Jetson TX2 Manuale utente

Connect Tech

Connect Tech FreeForm/Express S6 Manuale utente

Connect Tech

Connect Tech FREE FORM/PCI-104 104 Manuale utente

Manuali Hardware per computer popolari di altre marche

EMC2

EMC2 VNX Series Manuale del proprietario

Panasonic

Panasonic DV0PM20105 Manuale utente

Mitsubishi Electric

Mitsubishi Electric Q81BD-J61BT11 Manuale utente

Gigabyte

Gigabyte B660M DS3H AX DDR4 Manuale utente

Raidon

Raidon iT2300 Manuale utente

National Instruments

National Instruments PXI-8186 Manuale utente

Hauppauge

Hauppauge WinTV-HVR-2250 Manuale utente

Kontron

Kontron CP6002 Manuale utente

Manhattan

Manhattan 702843 Manuale utente

Aphex

Aphex 230 Manuale utente

AMD

AMD Phenom II Manuale operativo

Intel

Intel NUC 12 Pro Manuale utente

dbx

dbx Zone Pro 1260 Manuale utente

Galaxy

Galaxy GHDX2-2430S-24F4D Manuale utente

Intel

Intel AXXRMFBU4 Manuale utente

Kontron

Kontron DIMM-PC/MD Manuale utente

ST X-NUCLEO-SAFEA1B Istruzioni operative

STEINWAY LYNGDORF

STEINWAY LYNGDORF SP-1 Manuale utente
