Connects2 CAM-56 Manuale utente

www.c2vision-eu.com

Image Sensor: 7090

TV Lines: 480

Resolution: 720 x 480

Minimum Illumination: 0.1 Lux

TV System: NTSC

Waterproof Rating: IP68

Horizontal Angle: 110 Degrees

Vertical Angle: 90 Degrees

Parking Lines: Yes (Removable)

Image Adjustment: Yes (Mirror/Normal)

Enhanced Performance In Low Light: Yes

Video Output: 1.0V p-p 75ohm

Operating Voltage: 12V DC (Negative Ground)

Operating Temperature: -20 Degrees C to +70 Degrees C

User Manual

Prior to Installation

Read the manual prior to installation. Technical knowledge is necessary for installation.

Please ensure you use the correct tools to avoid damage to the vehicle or product.

Connects2 can not be held responsible for the installation of this product.

Technical Support

Connects2 want to provide a fast and suitable resolution should you encounter any

technical issues. With this in mind, when contacting Connects2, try to provide as

much Information as possible. This will speed up the process and help us to help you.

Please use our dedicated online technical support centre: support.connects2.com

Universal 110° Camera

in Flush Mount Housing (Drill to Fit)

PRODUCT FEATURES:

DISCLAIMER:

CAM-56

Connects2Vision

www.c2vision-eu.com

CONTENTS

• Camera with 1m cable to Female DC connector and RCA Female

connector

• 1m DC power cable with Male DC connector

• 6m Male to Male RCA extension cable

• Hole saw

• Instructions

INSTALLATION

1. Connect the Black wire to a suitable ground and the Red wire to a switched

+12V supply.

2. If the camera is to be used in the rear of the vehicle, the Red wire should

be connected to the reversing light circuit or an interface which provides a

reverse signal.

3. Select a suitable location for the camera and ensure that the area is free

from all cables, fuel & oil. Whenever possible, avoid locations that are subject

to road dirt & water spray.

4. Aim to mount the camera preferably 45-60cm from the ground and cut a

suitable hole using the cutting tool provided.

5. Using the supplied video cable, connect the camera to the display screen

and ensure that the image is displayed correctly.

NB: Rotation of the camera may be required to ensure that the correct

orientation of the image is achieved.

6. To swap the image from mirror to normal view, cut the small White looped

wire which is located on the camera connection cable.

7. To remove the parking line feature, cut the small Blue looped wire which is

located on the camera connection cable.

Subscribe to our YouTube Channel for installation

guides and tips... www.youtube.com/connects2
