Connects2 Vision CAM-4 Manuale utente

www.c2vision-eu.com

Image Sensor: 1/4” (6.35mm) CMOS

TV Lines: 480

Resolution: 648 x 488

Minimum Illumination: 0.1 Lux

TV System: NTSC

Waterproof Rating: IP67

Infra-Red LED’s: Yes (20-30ft)

Angle: 170 Degrees

Parking Lines: Yes

Enhanced Performance In Low Light: Yes

Video Output: 1.0V p-p 75ohm

Operating Voltage: DC9-16V (Negative Ground)

Current Consumption: 56mA @ 13.8V

Operating Temperature: -30 Degrees C to +65 Degrees C

User Manual

Prior to Installation

Read the manual prior to installation. Technical knowledge is necessary for installation.

Please ensure you use the correct tools to avoid damage to the vehicle or product.

Connects2 can not be held responsible for the installation of this product.

Technical Support

Connects2 want to provide a fast and suitable resolution should you encounter any

technical issues. With this in mind, when contacting Connects2, try to provide as much

Information as possible. This will speed up the process and help us to help you.

Please use our dedicated online technical support centre: support.connects2.com

Mini Rearview CMOS Camera

Pivoting, Surface Mounted with IR LEDs

(Vertical Adjustment)

PRODUCT FEATURES:

DISCLAIMER:

CAM-4

2

Connects2Vision

www.c2vision-eu.com

CONTENTS

• Camera with adjustable mounting bracket and 1m cable to RCA Female

video connector and Female DC connector

• 2.5m DC power cable with Male DC connector

• 6m RCA Male to Male extension cable

• Instructions

INSTALLATION

1. Connect the Black wire to a suitable ground and the Red wire to a switched

+12V supply.

2. If the camera is to be used in the rear of the vehicle, the Red wire should

be connected to the reversing light circuit or an interface which provides a

reverse signal.

3. Select a suitable location for the camera and ensure that the area is free

from all cables, fuel & oil. Whenever possible, avoid locations that are subject

to road dirt & water spray.

4. Remove the protective backing from the adhesive pad and place the

camera in the required position.

5. Using the supplied video cable, connect the camera to the display screen

and ensure that the image is displayed correctly.

6. Adjustment of the camera may be required to ensure that the correct angle

of the image is achieved.

Subscribe to our YouTube Channel for installation

guides and tips... www.youtube.com/connects2
