Connects2 CAM-KIT16 Manuale utente

www.c2vision-eu.com

CAMERA MONITOR

Image Sensor: 1080P Digital TFT LCD

TV Lines: 800 Display size: 5-inch

Resolution: 1280 x 720 Display format: 16:9

Minimum Illumination: 0.1 Lux Contrast: 350:1

TV System: NTSC Operating Voltage: 12V DC

Waterproof Rating: IP68

Horizontal Angle: 160 Degrees

Vertical Angle: 140 Degrees

Parking Lines: Yes (Removable)

Enhanced Performance In Low Light: Yes

Video Output: 1.0V p-p 75ohm

Operating Voltage: 12V DC (Negative Ground)

Operating Temperature: -20 to +70 Degrees C

User Manual

Prior to Installation

Read the manual prior to installation. Technical knowledge is necessary for installation.

Please ensure you use the correct tools to avoid damage to the vehicle or product.

Connects2 can not be held responsible for the installation of this product.

Technical Support

Connects2 want to provide a fast and suitable resolution should you encounter any

technical issues. With this in mind, when contacting Connects2, try to provide as

much Information as possible. This will speed up the process and help us to help you.

Please use our dedicated online technical support centre: support.connects2.com

Universal AHD/CVBS Camera & Monitor

with Vertical Adjustment

PRODUCT FEATURES:

DISCLAIMER:

CAM-KIT16

Connects2Vision

www.c2vision-eu.com

CONTENTS

• Camera with 1m cable to Female DC connector and RCA Female

connector

• 1m DC power cable with Male DC connector

• 6m Male to Male RCA extension cable

• 5-inch Digital TFT LCD Display (with 2x AV ports and power connection cable)

• Instructions

INSTALLATION

1. Connect the Black wire to a suitable ground and the Red wire to a switched

+12V supply.

2. If the camera is to be used in the rear of the vehicle, the Red wire should

be connected to the reversing light circuit or an interface which provides a

reverse signal.

3. Select a suitable location for the camera and ensure that the area is free

from all cables, fuel & oil. Whenever possible, avoid locations that are subject

to road dirt & water spray.

4. Mount the camera in the required position and connect the 1m camera

connection cable to the to the 1m power cable cable.

5. Connect the camera to the monitor via the 6m RCA cables and ensure that

the image is displayed correctly on the monitor.

6. Connect the Blue auto switching input wire located on the monitor cable to

the reversing light circuit or an interface which provides a reverse signal.

7. When reverse gear is engaged, the monitor will automatically switch to the

reversing camera screen and switch back to the previous input when reverse

gear is disengaged.

Note: the reversing camera screen can also be selected by pressing the input

selector button on the monitor.

8. Adjustment of the camera may be required to ensure that the correct angle

of the image is achieved and that the distance markers on the parking lines

correspond to that of the object in view.

9. To swap the image from the camera from mirror to normal view, cut the

White looped wire located on the camera cable.

10. To remove the parking line feature, cut the Blue looped wire located on the

camera cable.
