Contemporary Research VSC Guida utente
RSH
01/30/04
PRODUCT DRAWING
VIDEO TO S-VIDEO
NONE
1 1 950-5050
CST-VS
CST-VS_PD.DWG
UNLESS OTHERWISE SPECIFIED:
DECIMAL DIMENSIONS INCLUDING HOLES XX .010
FRACTIONAL DIMENSIONS INCLUDING HOLES 1/64
SURFACE FLATNESS .003 TIR PER LINEAR INCH.
DO NOT SCALE THIS DRAWING.
ALL DIMENSIONS IN INCHES.
ANGLES 1
XXX
DIR FILE
Research
Contemporary
**** REVISIONS ****
RELEASED
CHECKED
APPROVED
.005
SCALE
SHT
DATE
OF
TITLE
DATE
DATE
ECO NO.
DRAWN
SYM
DATE
DWG. NO.
DESCRIPTION DATE APPR.
TOP
5.50
TOP VIEW
1.125
3.35
1234
Video In Video SettingsS-Video Out
( ) ( )
12 VDC Pwr In
75 mA max
Pwr
LED
Contemporary
Research
VSC
Video to S-Video Converter
CR System Tools
