Continental Refrigerator 1F-LT Manuale utente

2420.83

REACH-IN

LOW TEMPFREEZERS

Utilizing Environmentally Safe, CFC-free R-404A Refrigerant

Standard Features

• Modern, State-of-the-Art Styling Performance

Rated Refrigeration System Designed

for -15°F Cabinet – Ideal for Ice Cream

• 3" Non-CFC Polyurethane Foam Insulation

• Chrome Plated Flow Line Handles

• Cam-Action Lift-Off Hinges

• Self-Closing Doors

• Automatic Interior Lighting

• Magnetic Snap-In Door Gasket

• Cylinder Lock in Each Door

• Automatic Electric Condensate Evaporator

• 5" Casters

• Heavy-Duty, Epoxy-Coated Steel Shelves

• External Dial Thermometer

• Automatic Electric Defrost

• Thermal Expansion Valve Governs Refrigerant

Flow for Quick Recovery

Standard (S/S Front, Aluminum End Panels & Interior)

Suffix SA (S/S Exterior, Aluminum Interior)

Suffix SS (S/S Exterior & Interior)

Optional Features & Accessories

•Half Door •Remote

•Shallow Depth •Hinged Glass Doors

•Stainless Steel Shelves •Legs

•Digital Thermometer •Rehinging of Doors

•Pan Slide Assemblies •Stainless Steel Case

•Increased Refrigeration Back

Systems

FREEZERS

1F-LT

2F-LT

3F-LT

2420.83

FREEZERS

VLFLT305

SPECIFICATIONS

A Division of National Refrigeration & A/C Products, Inc.

539 Dunksferry Road Bensalem, PA 19020

(800) 523-7138 Fax: (215) 244-9579

www.continentalrefrigerator.com

1F-LT 2F-LT 3F-LT

One Section Two Section Three Section

CHARACTERISTICS Reach-In Reach-In Reach-In

DIMENSIONAL DATA

Net Capacity (cu. ft.) 20 48 70

Width, Overall (in.) 26 52 78

Depth, Overall (Incl. Hdls.) (in.) 351/2351/2351/2

Depth (Less Door(s)) (in.) 32 32 32

Depth (Doors(s) Open 90°) (in.) 551/2551/2551/2

Clear Door Width (in.) 193/8193/8193/8

Clear Full-Door Height (in.) 585/8585/8585/8

Clear Half-Door Height (in.) 271/2271/2271/2

Height, Overall

(Inc. 5" Casters)(in.)

853/4853/4853/4

No. of Full Door(s) 1 2 3

No. of Half Door(s) 2 4 6

No. of Shelves 3 6 9

Shelf Area (sq. ft.) 20.4 40.8 61.2

Tray Slide Capacity (Half) 11 ea. 11 ea. 11 ea.

Tray Slide Capacity (Full) 24 ea. 24 ea. 24 ea.

REFRIGERATION DATA

Condensing Unit Size (H.P.) 3/412

Capacity (BTU/Hr)* 2050 3175 6300

ELECTRICAL DATA

Cabinet Specifications 115/208-230/60/1 115/208-230/60/1 115/208-230/60/1

Feed Wires (Incl. Ground) 4 4 4

Condensing Unit Specs. 208-230/60/1 208-230/60/1 208-230/60/1

Total Amperes 10.8 13.1 20.0

Cabinet Amperes 1.6 2.7 3.6

Defrost Amperes 5.2 9.6 10.4

Power Supply Cord no no no

SHIPPING DATA

Height – crated (in.) 851/2851/2851/2

Width – crated (in.) 315/864 90

Depth – crated (in.) 42 42 42

Volume – crated (in.) 65 133 187

Weight Std – crated (lbs.) 450 565 810

Weight SS – crated (lbs.) 510 645 925

Weight Std – uncrated (lbs.) 350 395 600

Weight SS – uncrated (lbs.) 410 475 715

* Rating @ -30°F Evaporator, 90° Ambient

Note: All specifications subject to change without notice.

Note: If the cabinet is located directly against wall and/or under low ceiling,

a minimum clearance of 2" is required.

5" CASTERS

52"

853/4"

5" CASTERS

26"

32"

351/2"

853/4"

5" CASTERS

78"
