Coopers HD-68W Manuale utente
Large Dehumidifier 8903 Instructions
Features
The Large Dehumidifier uses eltier technology (no compressor), which makes it
light and quiet. It is perfect for small rooms. oor ventilation causes musty
odours and fungus in wardrobes, larders, cabinets or storage rooms etc. The
Large Dehumidifier eliminates this problem by keeping them free of unwanted
moisture.
• To avoid electric shock. Do not open. There are no user serviceable parts
inside.
• Any repair work must be done by qualified technician.
• Specifications are subject to change for improvement without prior notice.
Specifications
Capacity: approximately 550ml – 600ml per day at 30°C, 80% RH
Cooling element: thermo-electric eltier module
Fan: 90mm x90mm DC Brushless motor
ower adaptor: 12V DC 6 Amp
ower consumption: 72W
Removable water tank: 2 Litre
Water Level Detector: Automatic switch off with “Yellow” LED Indicator when
water tank is full
roduct dimension: 215mm (W) x360mm (H) x185mm (D)
Working environment: Over 15, over 40% RH
Connections
1. After removing the packaging materials, there should be 2 items:
a. Large Dehumidifier.
b. AC/DC ower adaptor.
2. lug the DC power jack of AC/DC power adaptor to the DC power socket,
then connect the AC plug of the AC/DC power adaptor to the appropriate
main socket.
3. ress the “On/Off“ button to “On“ position, the Large Dehumidifier will
begin to operate. The green LED will turn on. Listen and feel for the air
blowing from dry air outlet.
4. To switch off the unit, press “On/Off“ button to “Off“ position, the Large
Dehumidifier will be turned off.
Removable Water tank
When the water tank is full, with approximately 1.5L of water collected, the
unit will switch off automatically and the “Yellow“ LED will be on.
To remove the water tank, first switch off the Large Dehumidifier, press
“On/Off“ button to the “Off“ position. Then, remove the water tank from the
unit and put the water tank back into the unit. To continue dehumidifying,
press the “On/Off“ button to “On“ position again.
Cleaning
Before cleaning the unit, turn off the Large Dehumidifier and unplug the AC
plug from the main socket first. Use a piece of soft cloth to clean the surface of
the product or use a brush to wipe the dust off the grills of the air inlet. Do not
immerse in water, keep dry at all times.
Cautions
1. Switch the unit off by pressing the “On/Off“ button to “Off“ position.
2. Avoid using the AC/DC power adaptor in wet or damp place, and position it
in areas where the air ventilation is good.
3. Keep the front inlet grill free from air blocking materials such as clothing,
plastic bag or papers.
4. Do NOT place on delicate surfaces that are susceptible to heat or moisture
damage.
5. Always keep the unit in an up-right position to avoid water leakage.
6. This not a toy keep away from children.
7. Not for commercial use.
Packaging
Dispose of the packaging at your local recycling centre.
Dispose of paper and box separately from plastic bags at your local recycling
centre.
Dispose of the item at the end of its lifespan at your local authorised household
waste recycling centre.
“On” green LED
On/Off button
“Full” yellow LED
Air inlet
Hydraulic cut- off
Water tank
Dry air outlet
Water displacement hole
Rubber feet
DC power jack
AC/ DC power adaptor
AC plug with power cord
Handle
