1. This document is intended for both the administrator and users of Video Processor model.
2. This manual contains information for configuring, managing and using Video Processor model.
4. To prevent fire or electrical shock, do not expose the product to heat or moisture.
3. Be sure to read through this manual before using this Video Processor model.
5. Check electricity at the place you want to install the unit if it is stable and meets our electricity requirements. Unstable
electricity will cause malfunction of the unit or give critical damage to the unit.
6. Several chips on the main board of the unit and hard disk drive inside the unit generate heat, and it must be
properly discharged.
Do not put any objects just beside exhaust port(fan) on the left side of the unit and do not close up an opening
(fresh air in-take) on the right side of the unit.
7. Put the unit at well-ventilated place and do not put heat-generating objects on the unit.
When it is installed inside 19 inch mounting rack together with other devices, please check built- in ventilation fan of
the rack is properly running.
Before installing Video Processor, be sure to thoroughly review and follow the instructions in this User’s Manual.
Pay particular attention to the parts those are marked NOTICE.
Also, when connecting with external application, first turn the power OFF and follow manual instruction for appropriate installation.
8. For questions and technical assistance of this product, contact your local dealer.
About this manual
Before reading this manual
Install hard disk drive
1) HDD should be up to 7200rpm. Capacity of HDD is Max. 300GB. (Tested with maxtor HDD)
We recommend Maxtor HDD.
2) Please make sure that jumper setting of HDD must be MASTER.
3) After install HDD, start . First, set the date and time.
Set at Factory Default in SETUP Menu and please clear HDD.
4) Go into Menu HDD Management HDD information and Verify that the second drive detected CD-Recorder.
15-VP04-HDD2 & 15-VP04-CDRW
