Cornelius RC05001 Manuale utente
FEATURES:
NORdic REmOTE cONdENSERS
For CubeD ICe maChInes
CG5090-1211 Remote CondenseRs
• Designed for use with remote-cooled Nordic cubed
ice machines
• Environmentally responsible - All RC model condensers
use R404A, an approved non-ozone depleting refrigerant
• Constructed from sturdy, corrosion-resistant
galvanized steel
• Reduces air conditioning requirements and cost
• Fan is located away from the ice maker ensuring
quiet operation for customers
For more information or to place an order, contact your sales representative or authorized distributor.
OUTSIDE THE U.S.A.
Ph: 763.488.8200
Email: [email protected]
IN THE U.S.A.
Ph: 800.238.3600
Fax: 800.258.0255
101 Broadway Street West
Osseo, MN 55369
www.cornelius.com
© 2011 IMI CORNELIUS
38.90”
(988 mm)
27.90”
(709 mm)
29.50”
(743 mm
)
RT-25’ (7.6m)
RT-40’ (12.0m)
RT-60’ (18.2m)
oPTIons anD aCCessorIes
model no. Description Shipping Weight
lbs (kg)
Rt25 25' ft (7.6 m) Precharged Tubing Kit for R404A models 13 (6)
Rt40 40' ft (12.0 m) Precharged Tubing Kit for R404A models 18 (8)
Rt60 60' ft (18.2 m) Precharged Tubing Kit for R404A models 26 (12)
sPeCIFICaTIons
model no. Description Voltage
Characteristics
Shipping Weight
lbs (kg)
RC05001 Remote Condenser for one model CCM522R, 530R 115/60/1 122 (55)
RC06002 Remote Condenser for one model CCM630R 208-230/50-60/1 124 (56)
RC08002 Remote Condenser for one model CCM830R, CCM1030R 208-230/50-60/1 124 (56)
RC14002C Remote Condenser for one model CCM1448R, CCM1530R 208-230/50-60/1 126 (57)
RC21002C Remote Condenser for one model CCM1848R, CCM2148R 208-230/50-60/1 145 (66)
Rt25 25' ft (7.6 m) Precharged Tubing Kit for R404A models 13 (6)
Rt40 40' ft (12 m) Precharged Tubing Kit for R404A models 19 (9)
Rt60 60' ft (18.2 m) Precharged Tubing Kit for R404A models 26 (12)
RC05001, 06002, 08002, 14002C, 21002C
Number of wires
(iNcludiNg grouNd). . . . . . . . . 3
AgeNcy listiNg . . . . . . . . . . . . .
