Cornelius 2267 Manuale utente

91890 12/16/96

IMICORNELIUSINC.

OneCorneliusPlace

Anoka.MN55303-6234

Telephone(800)238--3600

Facsimile(612)422--3246

INSTALLATION INSTRUCTIONS

KIT,P/N 2267 & 2329

Remcor model DB100/150 dispenserwith:

1.ManitowocSeriesB320,420 IceMaker--RefertoFig 1.

2. Ice-O-MaticSeriesGC300 IceMaker--RefertoFig 2.

1.Sealcoverto dispenserasfollows:

A.Applya bead ofRTVon the hopperflange.

B.Setcoverontothe dispenser.Becarefulnot to disrupt the dispensercabinetlabels,ifpresent.

C.Wipe awayexcess RTVimmediately.

D.Cover mustbe sealed completelytothe dispenserhopper.Sealanygapsbetween the coverand hop-

per.

2.Seal icemakertothe dispensercoverasfollows:

A.Locatethe outline of the icemakeron the dispenseras shown.

B.Applya bead ofRTVon the dispensercoveraround the icemakerframe,sidesand rear.

C.Seticemakeron the cover.

D.Wipe awayexcess RTVimmediately.

3.Securethe icemakertothe dispenserwiththe bracketsprovided.Drilling mustnotinterferewith anyice

makercomponents.

4. Install adhesive backed gasketstriptothe removablelid.

5.Followthe manufacturersinstructionstocompletethe installation of the icemaker.

291890

12/16/96

APPLYRTVALONGHOPPER

FLANGEALL AROUND FORPROPER

SEAL.COMPLETECOVERMUSTBE

SEALEDTOHOPPER.

ICEMAKERTOBEFLUSHWITH BACK

EDGEOFCOVER.

APPLYRTVAROUND INSIDE

OFICEMAKEROUTLINEON

DISPENSER COVERTOFORM

ASEAL.(4PLCS)

USINGEXISTINGHOLES,MOUNTBRACKETS(4)

WITH1/4-20 SCREWS.USINGUPPER HOLES AS

TEMPLATE,DRILL (4).136 DIA.HOLES TOSECURE

ICEMAKER AND DISPENSER.DRILLINGISNOT TO

INTERFEREWITHICEMAKER COMPONENTS. IF

THEREISINTERFERENCE,USE OPTIONAL

MOUNTINGBRACKETS(2).

OPTIONALMOUNTINGBRACKETS(2)

REMOVABLEFRONT LIDFOR

MANUALICEFILLING.

APPLYRTVALONGBOTTOMEDGEOF

ICERAMPAND FRONTHOPPERLIP.

COOMPLETECOVERMUSTBE SEALED

TOHOPPER.

ICEMAKERTOBEFLUSHWITH BACK

EDGEOFCOVER.

ADD INSULATIONSTRIPTOFLANGE

OFREMOVABLELID.

APPLYRTVAROUND INSIDE

OFICEMAKEROUTLINEON

DISPENSER COVERTOFORM

ASEAL.(SIDES AND FRONT)

REMOVE ICEMAKERPANEL

SCREWSTHATAREINLINE

WITH COVER HOLES AND

INSTALL MOUNTINGBRACKETS

WITHSCREWS PROVIDED(4)

REMOVABLEFRONT LIDFOR

MANUALICEFILLING.

B320 AND 420

GC300

ADD INSULATIONSTRIPTOFLANGE

OFREMOVABLELID.
