Cortelco C60 Manuale utente

IP Phone

Model: C60

www.cortelco.com

1703 Sawyer Road, Corinth, MS 38834

(800)288-3132

www.cortelco.com

1703 Sawyer Road, Corinth, MS 38834

(800)288-3132

www.cortelco.com

1703 Sawyer Road, Corinth, MS 38834

(800)288-3132

Features

• Supports SIP 2.0(RFC3261) and correlative RFCs.

• Supports 2 SIP lines. Can connect to 2 SIP servers at the same time.

• Multi-line HD Voice

• Supports IAX2

• Codecs: G.711A/u, G.723.1 high/low, G.729 a/b, G.722.1, G.726. Codecs may be set per line.

• Complies with G.168 for echo cancellation

• Acoustic echo cancellation with 96 ms max ﬁlter length in speakerphone mode

• Voice Gain Setting, VAD, CNG

• Full Duplex Speakerphone

• SIP Domain Support

• SIPAuthentication (none, basic, MD5)

• Supports SIP Peer-to-Peer calling

• DTMF Modes: SIP Info, RFC2833, Inband

• 9 Selectable Ringer Tones plus 5 User-Deﬁned Musical Ring Tones

• Headset or Speaker Ringing

• Large dot matrix LCD (128 X 64)

• RJ9 Headset Jack

• 2 Line Keys - Programmable for other features

• 8 DSS Keys

• 4 Context Sensitive Soft Keys

• 5 Navigation Keys

• 3 Hard Function Keys (Directory, History, Redial) - Programmable for other features

• Mute Key

• Call Control Features: Dial Plan, Anonymous Call Reject, DND, Caller ID

• SIPApplications: Call Forward, Transfer (Blind/Attended), Hold, Conference, Redial, Click to Dial

• Call Logs: Incoming, Outgoing, Missed Calls - 100 records each

• Directory 500 Records

• Supports up to 5 C10 Expansion Modules

• Keypad Lock with Emergency Call

Network Features

• 2 RJ45 10/100 Ethernet Ports (WAN/LAN)

• LAN Port Router or Bridge Mode

• PPPoE for DSL

• Power Over Ethernet (PoE)

• VLAN

• 802.1

www.cortelco.com

1703 Sawyer Road, Corinth, MS 38834

(800)288-3132

• STUN

• DHCP Client on WAN

• DHCP Server on LAN

• Main and Secondary DNS Server

• DNS Relay, SNTP Client, Firewall, OpenVPN

• VPN (L2TP) and DMZ

• QoS with DiffServ

• Ping, Trace Route, Telnet Client

Maintenance and Management

• Management via web, telnet or keypad

• User and Admin Accounts

• Firmware Upgrade via HTTP, FTP or TFTP

• Autoprovision

DHCP Option 66, Option 43 or Custom Option

Plug and Play Server

Phone Flash

TR-069 Speciﬁcations

Power Adapter Input 100 - 240 V

Power Adapter Output 5V @ 1A

WAN Port RJ45 10/100 Base-T

LAN Port RJ45 10/100 Base-T

Power Consumption Idle 2.5 W

Power Consumption Active 2.8 W

LCD Size 128 X 64

Operating Temperature 0 - 40º C

Chipset Broadcom

SDRAM 128 Mbits

Flash 32 Mbits

Weight 0.99 kg
