QUICK START AND TROUBLESHOOTING GUIDE
ABM-HOOD &
ABM-HOOD-200
Patented Wireless Technology
QUICK START GUIDE
APP DOWNLOAD & SETUP
The CPS Link app will work with older smart phones and tablets but has
been optimized for use with Apple iPhones SE, 8 and 8 Plus or newer,
and iPads with operating system iOS 9.3 or newer.
For phones and tablets with Android operating systems, the CPS Link
app has been optimized for all Bluetooth Smart compatible devices with
operating system 7.0-7.1.2, (Nougat) or newer.
1. To download CPS Link™ app go to the
App Store or Google Play
2. If you have a QR code scanner app on your
phone, scan the QR code below to be
redirected to the App Store or Google Play.
3. After downloading app, select the
CPS Link app on your mobile device.
4. Starting from Device List screen in the
app, look for an "available" ABM-100
or ABM-200 (indicated by a GREEN
circle with a "check mark").
a. Touch either available device and
wait for it to to connect to your
mobile device.
b. Starting from Dashboard Screen, select TESTS then select
ABM-Hood-200.
c. Once on the ABM EasyHood main screen (Location Description
Screen), input Duct Type and select Test Type.
5. Select "Start" when ready to begin.
CPS Link™
Version 4.3 or higher
U.S. Patent No. 9,043,161
QUICK START GUIDE (CONT’D)
1. For greater convenience, mount your
mobile phone to the adjustable
[2-3/8" to 5-5/8" (60 to 90 mm)] spring
loaded base.
If using ABM-100, use cable inside
smartphone platform and connect to
headphone jack on smartphone.
1. If using ABM-200, attach threaded mic jack metal adapter (chrome
metal pin) to meter, then plug meter into socket inside
control box opening.
2. If using ABM-100, plug meter into socket inside control box opening.
HANDS FREE MOBILE PHONE USE
INSTALL METER
QUICK START GUIDE (CONT’D)
REGULAR TEST [35 ~ 720 CFM (59 ~1,223 M3/H)]
1. From the ABM EasyHood screen, select REGULAR TEST.
2. Place hood over grille to capture airow readings.
3. App will calculate airow and other values.
4. When test is done, press STOP on mobile device screen or the test
will end automatically after 30 seconds.
5. Press STOP to end test.
6. Press SAVE (or CANCEL) on screen to end your session.
7. If SAVED, retrieve test report from Job File.
ABM EasyHood Main Screen Capture Airow Readings
12
Temperature
Wet Bulb
Dew Point
RH %
3
4
MAX
MIN
AVG
Airow Volume (CFM or M3/H)
QUICK START GUIDE (CONT’D)
1. Select LOW VOLUME from main screen on ABM-EasyHood app.
2. Insert Low Volume Adapter into WIDE
portion of Vortex grille (see photo below).
3. Place hood over grille to capture
airow readings.
4. App will calculate airow and other
values.
5. When test is done, press STOP on
mobile device screen.
6. Obtain test report from Job File.
LOW VOLUME TEST [7 TO 50 CFM (12 TO 85 M3/H)]
7. Press SAVE (or CANCEL) on screen to end your session.
ABM EasyHood Main Screen
1
Capture airow readings
3
Low Volume Adapter
2
Airow Volume (CFM or M3/H)
Temperature
Wet Bulb
Dew Point
RH %
4
5
MAX
MIN
AVG
LOW VOLUME TEST [7 TO 50 CFM (12 TO 85 M3/H)]
TROUBLESHOOTING GUIDE (GRILLES UP TO 24" X 24")
1. Squeeze BOTH sides of rubber
"skin" and push UPWARDS
simultaneously.
2. Pull "skin" over BACK of the
housing to expose coin cell
battery compartment
3. Open battery compartment and
replace coin cell.
4. Reinstall "skin" over molded housing.
3 4 Snap
1 2
TO REPLACE ABM-200 BATTERY
TROUBLESHOOTING GUIDE (CONT’D)
PROBLEM SOLUTION
CPS Link App
1. CPS Link App Crashes
Ensure mobile device is Bluetooth compat-
ible. And, Bluetooth setting is ON in mobile
device
Turn-off and restart mobile device in case of
other conicting apps running
Delete app and reinstall on your mobile
device
2. CPS Link app won't pair
to wireless device
Ensure wireless device is CPS brand only
Download CPS Link app from Apple App
Store or Google Play then pair mobile device
to CPS wireless meter
Mobile device must be ≤ 100 Ft (30m) from
CPS wireless device, range is reduced by
interior obstructions
3. App screen freezes
Exit CPS Link app and restart ABM-200
meter. Then reopen app and pair to wireless
device
4. Inconsistent air velocity
or air volume readings
Ensure ABM-100 or ABM-200 fan blades
are ALWAYS PERPENDICULAR to airow
direction during each test
Airow from same size but different air vents
will likely differ (before being balanced)
Fan or blower motor air volume varies based
on uctuations in power, fan curve, duct
pressure and building envelope conditions. A
door opening in another part of the building,
wind or stack effect can change the reading
5. App won't calculate
values Exit app and restart meter
TROUBLESHOOTING GUIDE (CONT’D)
PROBLEM SOLUTION
ABM-100 (Mounted In ABM EasyHood)
1. Won't provide readings
Meter must be connected to mobile device
phone jack via supplied cable (inside storage
compartment)
ABM-200 Meter (Mounted in ABM Easyhood)
1. Won't provide readings
Ensure meter properly paired to mobile
device
Replace ABM-200 coin cell battery
Fan or blower motor output varies
2. Low airow readings
seem inaccurate
Install supplied Low Volume Adapter plate
(see EasyHood Owner's Manual)
Connection Status
1. How do I know when the
IAQ PRO SmartAir is
paired to my mobile
device?
A blue dot is visible in the upper right corner
of the Performance Screen or Test Screen
2. How do I know if the IAQ
PRO is trying to
reconnect to my mobile
device?
A YELLOW dot will appear in the upper right
corner of the mobile device screen
3. How do I know if the IAQ
PRO is no longer paired
to my mobile device?
A FLASHING RED DOT will appear in the up-
per right corner of the mobile device screen
TROUBLESHOOTING GUIDE (CONT’D)
PROBLEM SOLUTION
ABM-HOOD (Must Be Used With Separately Purchased ABM
Meters)
1. Won't provide consistent
readings from same
vent
Hold hood rmly over entire grille area to
ensure all airow is captured
Fan or blower motor output varies
2. Low (Or Regular)
Airow-Readings seem
inaccurate
Install supplied Low Volume Airow plate
(see Owner's Manual) for airow ranging
from 7 to 100 CFM. No plate required for
airow readings from 35 to 720 CFM
HVAC system or blower motor may be off or
have variable speeds
