OWNER’S MANUAL
CT094 – HORIZONTAL/VERTICAL
SANDER
2
INDEX
GENERAL SAFETY INSTRUCTIONS Page 3
Features Page 4
Adjustments
Belt Tracking Page 5
Scale Page 6
Roller Adjustment Page 7
Operations
Test Run Page 8
Belt Selection Page 8
Edge & End Sanding Page 9
Contour Sanding Page 10
Changing the belt Page 11
Maintenance
General Page 12
Lubrication Page 12
Sanding Belt Page 12
Schematic Diagram Page 13
Parts List Page 14
Warranty Page 15
3
GENERAL SAFETY INSTRUCTIONS
EXTREME CAUTION SHOULD BE USED IN OPERATING ALL POWER TOOLS. KNOW
YOUR POWER TOOL, BE FAMILIAR WITH ITS OPERATION. READ THE OWNER’S
MANUAL AND PRACTICE SAFE USAGE PROCEDURES AT ALL TIMES.
CONNECT your machine ONLY to the matched and specified power source.
WEAR SAFETY GLASSES, RESPIRATORS, HEARING PROTECTION
and SAFETY SHOES when operating heavy machinery. Always wear safety
glasses.
DO NOT wear loose clothing or jewellery when operating machinery.
A Safe Environment is important. Keep the area free of dust, dirt and other
debris in the immediate vicinity of the machine.
BE ALERT! Do Not Use prescription or other drugs that may affect your ability
or judgement to safely use this machine.
DISCONNECT the power source when changing drill bits, hollow chisels or
making other adjustments or repairs.
NEVER leave an operating tool unattended.
NEVER reach over the table when the tool is in operation.
ALWAYS keep blades, knives or bits sharp and properly aligned.
ALWAYS keep all safety guards in place and ensure their proper function.
ALWAYS use push sticks and featherboards to safely feed your work through the
machine.
ALWAYS make sure that any tools used for adjustments are removed before
operating the machine.
ALWAYS secure your work with the appropriate clamps or vises.
ALWAYS keep bystanders safely away while operating machinery.
THINK SAFETY. WORK SAFELY. Never attempt a procedure if it does not
feel safe or comfortable.
4
CT094 – HORIZONTAL/VERTICAL SANDER
FEATURES
As part of the growing line of Craftex woodworking equipment, we are proud to
offer the CT094 Horizontal/Vertical Sander. The Craftex name guarantees Craft
Excellence. By following the instructions and procedures laid out in this owner’s
manual, you will receive years of excellent service and satisfaction. The CT094 is
a professional tool and like all power tools, proper care and safety procedures
should be adhered to.
Features
Motor: 1/2 HP - 4 AMP, 110V, 3450 RPM with keyed switch
Table Size -Two 12" x 8" cast aluminum tables, one with a 3/4" mitre gauge slot
Bed Size - 12 1/2" x 43/4"
Belt Size - 4" x 36" Quick Release
Belt Speed - 2,200 F.P.M Approx.
Pulley Size for Contour - 21/2"
Overall Height: 20" x 15" x 17"High
Gross Weight - 30 kg
Carton Size - 24" x 18" x 17"
5
CT094 – HORIZONTAL/VERTICAL SANDER
ADJUSTMENTS
6
CT094 – HORIZONTAL/VERTICAL SANDER
7
CT094 – HORIZONTAL/VERTICAL SANDER
8
CT094 – HORIZONTAL/VERTICAL SANDER
OPERATIONS
9
CT094 – HORIZONTAL/VERTICAL SANDER
10
CT094 – HORIZONTAL/VERTICAL SANDER
