Creative ZEN MICROPHOTO Manuale utente

English............................................ 1

日本語........................................... 14

简体中文 ....................................... 27

繁體中文 ....................................... 40

한국어........................................... 53

Türkçe........................................... 65

Contents_CLA.fm Page i Tuesday, December 6, 2005 2:44 PM

Contents_CLA.fm Page ii Tuesday, December 6, 2005 2:44 PM

Getting Started 1 English

Getting Started

Congratulations on your purchase of Zen™ MicroPhoto! Follow the next few

steps to set up the software and your player to enjoy a new level in portable

digital entertainment.

51 32 4

78911 10

1. Power switch/

Screensaver LED

2. Lock

3. Headphone jack

4. USB 2.0 port

5. Microphone

6. Next/Fast Forward

button

7. Options button

8. Play/Pause button

9. Vertical Touch Pad

10. Menu/Back button

11. Previous/Rewind button

Zen MicroPhoto_CLA.fm Page 1 Wednesday, December 28, 2005 9:37 AM

2 Using the Vertical Touch Pad

Using the Vertical Touch Pad

■Move your thumb up and down the Vertical Touch Pad to scroll

through menu items.

To rapidly scroll through menu items, hold down the top or bottom

portion of the Vertical Touch Pad with your thumb.

To select a menu item, firmly tap the Vertical Touch Pad.

■To adjust the sensitivity of the Vertical Touch Pad, press the Menu/

Back button , and select System Player Settings TouchPad

Sensitivity. Sensitivity can be set to low, medium or high.

■To turn the Vertical Touch Pad's clicking sound on and off, press

the Menu/Back button , and select System Player Settings

TouchPad Clicker.

■Slide the Power switch towards the Lock icon to disable

Zen MicroPhoto's Vertical Touch Pad and buttons. This is useful

when you do not want to activate controls accidentally when your

player is in your pocket or bag.

Zen MicroPhoto_CLA.fm Page 2 Wednesday, December 28, 2005 9:37 AM

Insert the battery 3

Step 1: Insert the battery

Step 2: Set up the software

1Turn on your computer.

You must log in as an administrator in Windows® before you can set up the

software. For more information, refer to your operating system’s online

Help.

2Insert the Installation and Applications CD into your CD-ROM/DVD-ROM

drive.

Your CD should start automatically. If it does not, follow the steps below:

i. Double-click the My Computer icon.

Alternatively, click Start My Computer.

ii. Right-click the CD-ROM/DVD-ROM drive icon, and then click

Autoplay.

3Follow the instructions on the screen.

4When prompted, restart your computer.

WARNING DO NOT connect your player to your computer before setting up the

software.

1 2 3

Zen MicroPhoto_CLA.fm Page 3 Wednesday, December 28, 2005 9:37 AM

4 Charge the battery

Step 3: Charge the battery

1Connect your player to your computer’s USB port with the supplied USB

cable.

2When the battery is charging, the battery charging icon flashes on the

Organic Light Emitting Diode (OLED) display.

3Disconnect your player from your computer when the battery is fully

charged and you see on your player’s OLED display. Fully charging your

player takes approximately five hours. If your fully charged player remains

connected to your computer for a prolonged period, the OLED display

blanks out automatically to save battery power.

NOTE ■For continuous battery charging using the USB port, make sure

your computer is not in power conservation mode. For more

information on power conservation modes, refer to your

operating system's Help.

■Connect to a computer USB port only; avoid connecting to a USB

hub.

■For express battery charging without using your computer,

purchase the Zen MicroPhoto Power Adapter or Universal Travel

Adapter. For more information on this and other Zen MicroPhoto

accessories, visit www.creative.com.

Zen MicroPhoto_CLA.fm Page 4 Wednesday, December 28, 2005 9:37 AM

Turn On Your player 5

Step 4: Turn On Your player

1Slide the Power switch towards the Power icon and hold it there until

the OLED display lights up.

2When you turn on Zen MicroPhoto for the first time, the default language is

in English. To change the language:

i. Press the Menu/Back button . The main menu appears.

ii. Use the Vertical Touch Pad to select System Language, and

then select the language that you want.

3After you have finished using your player, slide the Power switch towards

the Power icon until the Shutting down message appears.

Step 5: Transfer Content

Transfer music and other files from your CD collection or computer. For

more details, see “Managing Music and Data” on page 9.

To transfer or ‘rip’ music from your CD collection

1Make sure your player is connected to your computer as shown on page 4.

2Double-click the Zen MicroPhoto Media Explorer icon on the desktop.

3Click the Rip Audio CDs button .

TIP You can acquire content from many legal sources. Here are some

suggestions:

■Audio tracks - ripped from personal audio CDs, home studio

recordings or purchased from online music stores.

■Pictures - encoded from your personal digital camera or scanned

from printed photos.

Zen MicroPhoto_CLA.fm Page 5 Wednesday, December 28, 2005 9:37 AM

6 Transfer Content

4Follow the instructions on the screen.

To transfer audio files or pictures from your computer

1Repeat steps 1 and 2 in "To transfer or ‘rip’ music from your CD collection".

2Click the Browse Media button .

3Locate your media files and copy them to your player using the

drag-and-drop method.

To transfer data files

1Repeat steps 1 and 2 in "To transfer or ‘rip’ music from your CD collection".

2Click the Browse Documents button .

3Locate your data files and transfer them to your player using the

drag-and-drop method. You can also transfer audio files and pictures using

the Browse Documents button .

NOTE Creative Media Explorer uses MusicIDSM from Gracenote®to get artist,

title, track, credits, and other information about the CDs you play. This

service is FREE and automatic. You must be connected to the Internet when

using this service. For more information, refer to the Creative Audio CD

Ripper online Help.

NOTE Make sure files are transferred to the correct folder, for example

pictures are transferred to Media Pictures and music to Media

Music.

Zen MicroPhoto_CLA.fm Page 6 Wednesday, December 28, 2005 9:37 AM

Transfer Content 7

Step 6: Disconnect Your Player

When you have finished transferring files, disconnect Zen MicroPhoto.

DO NOT disconnect your player if you see the left picture below on the

display. Track or data file transfer is in progress and disconnecting your

player may damage the content being transferred. Wait until you see the

right picture below on the display before disconnecting your player.

Docked Docked

Zen MicroPhoto_CLA.fm Page 7 Wednesday, December 28, 2005 9:37 AM

8 Transfer Content

Step 7: Play Music or View Files

You are now ready to play music that you have ripped, and view files you

have transferred!

To play music

1Connect your earphones to the Headphone jack.

2In the main menu, select Music Library category that you want.

3Select a track and select Play.

4Move your thumb up and down the Vertical Touch Pad to adjust the volume.

To view pictures

1In the main menu, select Photos, and select the picture you want to view.

2Press the Options button to select display and wallpaper options.

If you select Zoom In, use the Vertical Touch Pad to move your picture up or

down. Press the Previous/Rewind button or Next/Fast Forward button

to move your picture left or right.

To view pictures in a slideshow

1In the main menu, select Photos, and highlight the picture or folder that you

want.

2Press the Options button , and select Start Slideshow.

3To change the slideshow interval duration, select System Photo Settings

Slide Timer.

Zen MicroPhoto_CLA.fm Page 8 Wednesday, December 28, 2005 9:37 AM
