Creative ZEN Zen Vision Manuale utente
i
English............................................ 1
Français........................................ 16
Español......................................... 32
Brasileiro...................................... 47
CLI_Monet QS_Rev 2.book Page i Tuesday, August 30, 2005 10:28 AM
ii
CLI_Monet QS_Rev 2.book Page ii Tuesday, August 30, 2005 10:28 AM
Congratulations! 1 English
Congratulations!
Thank you for purchasing Creative’s multiformat player, Creative Zen™
Vision. Read on to learn how to get started with your new player!
To get the most out of your player, also read the comprehensive User’s
Guide on your Installation and Applications CD.
1
3
2
4
5
6
8
7
910
11
12
1. Infrared receiver
2. Menu/Back button
3. Options button
4. Navigation buttons
5. Play/Pause button
6. Next/Fast-Forward
button
7. Integrated speaker
8. Previous/Rewind button
9. Compact Flash memory
card slot
10. Headphone jack
11. A/V Out jack
12. DC IN 5V jack
CLI_Monet QS_Rev 2.book Page 1 Tuesday, August 30, 2005 10:28 AM
2 Congratulations!
Selecting Options
In the following sections of this document, we use the term ‘Select’ to
indicate that you should use the Navigation buttons (Up, Down, Left or
Right) to highlight menu options, then press the OK button to select the
option.
1 2 3 4 5
7 6
1. Volume Decrease button
2. Volume Increase button
3. Power switch
4. Lock icon
5. Microphone
6. Docking connector
7. USB 2.0 port
1. Up button
2. OK button
3. Right button
4. Down button
5. Left button
12
3
4
5
CLI_Monet QS_Rev 2.book Page 2 Tuesday, August 30, 2005 10:28 AM
Getting Started 3
Getting Started
Step 1: Charge Your Player
The high performance lithium-ion battery supplied with your player needs
to be fully charged before you use it. The battery is fully charged in
approximately two hours. To charge your player's battery, connect the
power adapter to your player and wall outlet as shown in the diagram below.
1
2
1. DC IN 5V jack
2. Power adapter cable
CLI_Monet QS_Rev 2.book Page 3 Tuesday, August 30, 2005 10:28 AM
4 Set up the software
Step 2: Set up the software
1Turn on your computer.
You must log in as an administrator in Windows before you can set up the
software. For more information, refer to your operating system’s online
Help.
2Insert the Installation and Applications CD into your CD-ROM/DVD-ROM
drive.
Your CD should start automatically. If it does not, follow the steps below:
i. Double-click the My Computer icon.
Alternatively, click Start My Computer.
ii. Right-click the CD-ROM/DVD-ROM drive icon, and then click
Autoplay.
3Follow the instructions on the screen and when prompted, restart your
computer.
4When your computer restarts, follow the product registration instructions
on the screen.
WARNING DO NOT connect your player to your computer before setting up the
software.
NOTE You need an Internet connection to register your product.
CLI_Monet QS_Rev 2.book Page 4 Tuesday, August 30, 2005 10:28 AM
Set up the software 5
5When prompted, connect your player to your computer’s USB port using the
supplied USB cable.
NOTE Connect to a computer USB port only; avoid connecting to a USB hub.
CLI_Monet QS_Rev 2.book Page 5 Tuesday, August 30, 2005 10:28 AM
6 Turn On Your Player
Step 3: Turn On Your Player
1To turn on your player, slide the Power switch towards the Power icon
and hold it there until the LCD lights up.
2Connect your earphones and use the Volume Increase and Volume
Decrease buttons to adjust the volume.
3When you turn on your player for the first time, the menu is in English. To
change the language:
i. Press and hold the Menu/Back button. The main menu
appears.
ii. Use the Navigation buttons to select System Language, and then
select the language that you want. For tips on using the Navigation
buttons, see “Selecting Options” on page 2, or refer to the User’s
Guide on the Installation and Applications CD.
4After you have finished using your player, slide the Power switch towards
the power icon until the Shutting Down message appears.
CLI_Monet QS_Rev 2.book Page 6 Tuesday, August 30, 2005 10:28 AM
Rip and Copy Music 7
Step 4: Rip and Copy Music
Rip music from your CD collection to your player, or copy audio files (such
as music you have purchased online) from your computer. Before ripping or
copying files, make sure your player is connected to your computer as
shown on page 5.
To rip music from your CD collection
1Double-click the My Computer icon on your desktop.
Alternatively, click Start My Computer.
2Click the Zen Vision Media Explorer icon .
3Click the Rip Audio CDs button .
4Follow the instructions on the screen.
If you are connected to the Internet, album information is automatically
retrieved.
To copy audio files, videos or photos from your computer
1Double-click the My Computer icon on your desktop.
Alternatively, click Start My Computer.
2Click the Zen Vision Media Explorer icon .
3Click the Import Media button .
4Follow the instructions on the screen.
CLI_Monet QS_Rev 2.book Page 7 Tuesday, August 30, 2005 10:28 AM
8 Rip and Copy Music
To copy data files
1Double-click the My Computer icon on your desktop.
Alternatively, click Start My Computer.
2Click the Zen Vision Media Explorer icon .
3Click the Transfer Documents button .
4Locate your data files and copy them to your player or computer using the
drag-and-drop method.
CLI_Monet QS_Rev 2.book Page 8 Tuesday, August 30, 2005 10:28 AM
