QUICK START GUIDE

SMART TAPE LIGHT STRIP

What's in the box

Please consult this checklist for all parts.

Controller

6.5 Foot Tape light Power Adapter

Connector Adhesive Pads

Manual

IR Remote

Description

Working voltage: DC12/24V

Current: 2Ax 3CH

Max load: 12V/36W; 24V/72W

Product size: L77 x W35 x H17mm

Working environment: Indoor

Working temperature: -10°C-40°C (14°F-104°F)

Humidity: <80%RH

90°

IR Antenna

(Receives signal

from IR remote,

within a 90° radius)

On/Off

Color Change

Music/Color Rhythm

Microphone

Tape Light Connector

Power Port for Wall Plug

Power Connection

Step 1: Connect Tape Light Strip to Controller

Step 2: Connect Power Adapter to Controller

Step 3: Plug Power Adapter into wall outlet

The white arrow on the Controller must

align with the “+12V” text printed on the

Tape Light Strip

Attach your Tape Lights

Clean the surface with a

wet, damp cloth. Surface

must be dry and free of

dirt or oils.

Peal off the backing

strip from the

adhesive.

Place the Tape

Light Strip where

you want, and

gently press down

to adhere.

Do NOT bend Tape

Light Strip at LED or

connection when going

around corners.

Do NOT bend at more

than a 90° angle.

Connect the Tape

Light Strip into the

Controller and Wall

Plug. Use the supplied

Adhesive Pad to

secure the conroller.

<90°

LED

Cut to adjust length

at the connector

sections.

Insert trimmed ends of Tape Light Strip

into the supplied Connector.

Important!

Match the “+12V” text printed on the

Tape Light Strip to the “+” sign on the

Connector. Close hinged Connector

securely.

Repeat for the other end. Use the

supplied Adhesive Pads to secure the

Connector to the mounting area.

Link up to 32 feet with the Cree Lighting

Connected Max Tape Light Extension Kit.

“+12V” to “+”

Trim Tape Lights / Connect Two Tape Light Strips

Trim Tape Light Strip

Connect two Tape Light Strips

Tape Light Strip Control

Adjust with Controller

Adjust with IR Remote

Click On / Off

Static / Dynamic mode

Music / Color Rhythm

Point the IR Remote at the

IR Antenna to control.

Adjust with App

See page 7 to pair Smart Tape

Light Strip with Cree Connected

Max App

Static /

Dynamic

Mode

Night

Light

Color

Changing

Music /

Color

Rhythm

On / Off

Brightness

Changing

Mode

Changing

CCT

Changing

Turn Off

60s Later

Pairing with the App

Download

The Connected Max Smart Tape Light Strip must pair to a 2.4GHz Wi-Fi network.

Once paired, you can control on any Wi-Fi or cellular network. For most users,

pairing will be quick and simple. But depending on the type of wireless router

you have, you may need a little more information to get started. Refer to our

Wireless Router Guide at creelighting.com/connectedmax for more

information.

NOTE: If you need to re-select the Wi-Fi network, please press and hold the

"Power" button on the Controller for 5 seconds, the device will restart, and the

Tape Light Strip will slowly flash.

Pairing to your network

Download App (Android)

Download App (iOS)

Please keep network available

2.4GHz 5GHz

The Cree Lighting App is available for both iOS and Android.

Search Cree Lighting in the App store or Google Play to download the app.

How to pair your Tape Light Strip

Pairing with the App

Download the Cree Lighting app and register your account. Open the Cree

Lighting App, click "Sign Up", read the "User Agreement Privacy Policy"

and click "Agree."

Plug the Cree Lighting Connected Max Smart Tape Light Strip you want to pair

into a wall outlet and press the power button. The Tape Light Strip should start

slowly flashing to indicate pairing mode. If the Tape Light Strip is not slowly

flashing, it may need to be reset.

Reset a Tape Light Strip by holding down the Power button on the Controller

for 5 seconds.

In the Cree lighting app, tap the “+ ”

of the Home screen.

The Tape Light Strip you are pairing

will appear on screen, tap “Next.”

The Wi-Fi network your phone is

connected to will appear. You can

change your network to a 2.4 GHz

network if needed and enter

password.

The Cree Lighting app will add your

Tape Light Strip.

Pairing with the App

1 2
