CSSN MagShell 900 Manuale utente
(1)
© 2005 All rights reserved to CSSN card scanning solutions
MagShell 900
Manual swipe, bi-directional magnetic reader, conforms to ISO
7810, 7811, AAMVA, JIS & DMV format, All ISO tracks supported.
Communicates with a host computer or other terminal via a
standard Universal Serial Bus (USB) interface
Features
Buzzer and LED indicator
Read and convert RS232 magnetic data
Bi-Directional
All ISO tracks supported
(USB) interface, no external power required
Fully portable
Small footprint
Technical specifications
Interface USB Full Speed (1.1)
Scanner Weight 20 oz / 210gr.
Dimensions (LxWxH) 3.94"/100mm L x 1.1"/28mm H x 1.33"/34mm W
Power consumption USB powered ( 2.0 W @ 5Vdc)
Operating Voltage +5VDC +/- 10%, 110mA max
Certifications CE, FCC, UL, cUL
ISO ISO track 1, 2 and 3, 7810, 7811, AAMVA, JIS & DMV format
Electrical Performance
Power +5VDC ± 10% from USB port Read card
ISO 7810, 7811/1-6/AAMVA, custom data
Consumption
98mA max. in normal
condition
Coercive force Read 300-4000, Ce Magnetic Card
STD card Jitter ± 15% Amp 60%Communication
Standard RS232 to USB Read speed
5-55 ps 5-50 ps 5-50 ps
Mechanical Read error
rate
<0.5%
Body material
ABS 04V-0 Environment
Dimension 3.94"/100mm L x 1.1"/28mm
H x 1.33"/34mm W
Operation -10 to 550C, 10 to 90% Humidity
Weight 20 oz / 210gr. Storage -30 to 700C, 10 to 90% Humidity
Connection USB series "A" plugs Agency
approval
FCC/CE class A UL, cUL
Handling
Method
Manual, swipe, bi-directional
