Cudy LT18 Manuale utente
2
English
3 –11
Čeština
12 –20
Slovenčina
21 –29
Magyar
30 –38
Deutsch
39 –47
3
Dear customer,
Thank you for purchasing our product. Please read the following instructions carefully
before first use and keep this user manual for future reference. Pay particular attention
to the safety instructions. If you have any questions or comments about the device,
please contact the customer line.
✉www.alza.co.uk/kontakt
✆+44 (0)203 514 4411
Importer Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz
4
Install the SIM Card and Battery
1. Install the cellular antennas
2. Insert the Nano SIM card into the SIM1 slot until you hear a click.
Direction: With the gold contacts facing down, gently slide the SIM card into the slot.
Note: If both SIM1 and SIM2 card slots are inserted with SIM cards, the router will
automatically choose which SIM card to use. Since this automatic selection mechanism
is time-consuming, it is strongly recommended that only one card is inserted for the first
use.
Install the Antenna
Nano SIM
SIM card requirement
Nano SIM
4FF
Nano SIM
3FF
Nano SIM
2FF
5
3. Connect the power adapter to the router.
4. Turn on the router. Waiting 2-5 minutes for it to start.
5. Check the status of the .
If the turns to solid blue, means connect to cellular network and signal is
strong.
If the turns to solid purple, means connect to cellular network and signal
is average.
If the turns to solid red, please follow the instructions of Customize the
4G Router.
Note: For some ISPs a SIM card (such as version), it may take longer to connect to the
internet. Please kindly wait another 2-5 minutes.
Customize The 4G Router
1. Connect the router via ethernet cable or Wi-Fi. Network name and password is
printed on the bottom of the router.
Press the power button
6
2. Launch a web browser and enter http://cudy.net/ (or http://192.168.10.1) in the
address bar, use admin as password to login.
3. Below page would pop up if your SIM card needs PIN to unlock. Please enter your
PIN and click Save & Apply, then wait 15 seconds to connect to the internet.
4. Then please check 4G information card of the status page. If the status is connected,
means connected to the internet successfully.
Connected
Not connected
7
5. If 4G is not connected, or if you want to customize the router yourself, click “Quick
Setup” and follow the step-by-step instructions to configure the router.
Note:
1. If you are not sure about APN parameters, please contact your internet provider.
2. If you meet any other problems don’t hesitate to contact our technical support team:
support@cudy.com
3. Frequently Asked Questions: Find answers on https://www.cudy.com/faq
Enjoy the internet!
LED and Interface
Name
Status
Indication
Off
Not powered on
Flash
System starts up process or upgrade process
Solid
System starts up is complete
Off
Not powered on
Red
No internet connection
Purple
2G/3G connected
Blue
4G connected
Blinking Blue
Wi-Fi is disabled
Flash
WPS pairing
Solid
Wi-Fi is enabled
Off
Not detect the SIM card.
Red
Not connected to 4G network.
Purple
4G LTE signal is average
Blue
4G LTE signal is strong
LAN LED
Off
No connection
On
Connected
Button
Power
Press for “Power ON”, bounce for “Power PFF”
WPS
Press to take effect.
Reset
Long press for 2s to take effect without releasing it.
When it takes effect, all LED lights flash 3 times, and then
enter the restart process.
8
How to upgrade firmware
How to upgrade firmware?
1. Download the latest firmware from https://www.cudy.com/download
2. Unzip the file you download
3. Connect to Cudys network via WiFi or Ethernet.
4. Open a web browser and go to http://cudy.net/ or http://192.168.10.1/
5. Log in the web management page.
6. Click Advanced -> Firmware.
7. Choose the firmware you unzipped to upload.
8. Waiting 2 5 minutes for the router restart.
9. Done
Need Help?
Q1. What should I do if I cannot access the web management page?
A1: If the computer is set to a static IP address, change its settings to obtain an IP
address automatically.
A2: Make sure http://cudy.net/ or http://192.168.10.1/ is correctly entered in the web
browser.
A3: Use another web browser and try again.
A4: Reboot your router and try again.
A5: Disable and enable the active network adapter in use.
9
Q2. How do I restore the router to its factory default settings?
A1: With the router powered on, press, and hold the RESET button for 6 seconds before
release. Wait the router resets.
A2: Log in to the web management page of the router, and go to Advanced settings >
Reset, click Perform Reset and wait until the reset process is complete.
Q3: What can I do if I meet other problems?
A1: Find answers on https://www.cudy.com/faq
Warranty Conditions
A new product purchased in the Alza.cz sales network is guaranteed for 2 years. If you
need repair or other services during the warranty period, contact the product seller
directly, you must provide the original proof of purchase with the date of purchase.
The following are considered to be a conflict with the warranty conditions, for
which the claimed claim may not be recognized:
•Using the product for any purpose other than that for which the product is intended
or failing to follow the instructions for maintenance, operation, and service of the
product.
•Damage to the product by a natural disaster, the intervention of an unauthorized
person or mechanically through the fault of the buyer (e.g., during transport,
cleaning by inappropriate means, etc.).
•Natural wear and aging of consumables or components during use (such as
batteries, etc.).
•Exposure to adverse external influences, such as sunlight and other radiation or
electromagnetic fields, fluid intrusion, object intrusion, mains overvoltage,
electrostatic discharge voltage (including lightning), faulty supply or input voltage and
inappropriate polarity of this voltage, chemical processes such as used power
supplies, etc.
•If anyone has made modifications, modifications, alterations to the design or
adaptation to change or extend the functions of the product compared to the
purchased design or use of non-original components.
10
EU Declaration of Conformity
Identification data of the manufacturer's / importer's authorized representative:
Importer: Alza.cz a.s.
Registered office: Jankovcova 1522/53, Holešovice, 170 00 Prague 7
CIN: 27082440
Subject of the declaration:
Title: 4G LTE Wi-Fi Router
Model / Type: Cudy-LT18
The above product has been tested in accordance with the standard(s) used to
demonstrate compliance with the essential requirements laid down in the
Directive(s):
Directive No. 2014/53/EU
Directive No. 2009/125/EC
Directive No. 2011/65/EU as amended 2015/863/EU
Prague
