INSTRUCTION AND

RECIPE BOOKLET

For your safety and continued enjoyment of this product,

always read the instruction book carefully before using.

Smart Stick®Two Speed Hand Blender CSB-79

IMPORTANT SAFEGUARDS

When using an electrical appliance, basic safety precautions should

always be followed, including the following:

1. READ ALL INSTRUCTIONS.

2. Unplug from outlet when not in use, before putting on or

taking off parts, and before cleaning. To unplug, grasp plug

and pull from electrical outlet. Never pull cord.

3. To protect against electrical shock, do not put the motor body,

cord or electrical plug of this hand blender in water or other

liquids. Only the detachable blending shaft and other certain

parts of this appliance have been designed for immersion into

water or other liquids. Never submerge any other portion of this

unit. If hand blender falls into liquid, remove immediately. Do not

reach into the liquid without unplugging the unit first.

4. This appliance should not be used by children. To avoid possible

accidental injury, close supervision is necessary when any

appliance is used by or near children.

5. Avoid contact with moving parts.

6. During operation keep hands, hair and clothing, as well as

spatulas and other utensils, away from attachments and any

mixing container to reduce risk of injury to persons and/or

damage to the appliance. A spatula may be used, but must be

used only when the unit is not operating.

7. Do not operate any appliance with a damaged cord or plug,

or after the appliance has malfunctioned or has been dropped

or damaged in any way or is not operating properly. Return the

appliance to the nearest Cuisinart Repair Center for examination,

repair, or mechanical or electrical adjustment.

8. Remove detachable shaft from the blender before washing the

blades or shaft.

9. Blades are SHARP. Handle carefully when removing,

inserting or cleaning. Exercise the same care when

removing, inserting the cutting blade or reversing disc for

the food processor attachment.

10. When mixing liquids, especially hot liquids, use a tall container

or make small quantities at a time to reduce spillage, splattering

and possibility of injury from burning.

11. To reduce the risk of injury, never place chopper/grinder

attachment cutting blade on base without first putting work bowl

properly in place.

12. Be certain the food processor attachment cover is securely

locked in place before operating appliance. Do not attempt to

remove cover until blade has stopped rotating.

13. Check work bowl for presence of foreign objects before using.

14. The use of attachments or accessories not recommended by

Cuisinart may cause fire, electrical shock, or risk of injury.

15. Do not use outdoors or for other than intended use.

16. Do not let any cord hang over the edge of the table or counter.

Do not let cord contact hot surfaces, including stovetop.

17. Make sure the appliance is off, the motor has stopped

completely, and the appliance is unplugged from outlet before

putting on or taking off attachments, and before cleaning.

18. Maximum rating is based on the 400W food processor

attachment that draws the greatest power.

19.

Do not operate your appliance in an appliance garage or

under a wall cabinet. When storing in an appliance garage

always unplug the unit from the electrical outlet. Not doing

so could create a risk of fire, especially if the appliance

touches the walls of the garage or the door touches the unit

as it closes.

SAVE THESE INSTRUCTIONS

FOR HOUSEHOLD USE ONLY

NOTICE

This appliance has a polarized plug (one blade is wider than the

other). As a safety feature, this plug will fit in a polarized outlet only

one way. If the plug does not fit fully in the outlet, reverse the plug.

If it still does not fit, contact a qualified electrician. Do not attempt

to defeat this safety feature.

CONTENTS

Important Safeguards ....................................2

Unpacking Instructions ...................................4

Parts and Features ......................................5

Assembly..............................................7

Blending Attachment................................7

Chopper/Grinder Attachment .........................8

Whisk Attachment ..................................8

Reversible Blade ...................................9

Operation.............................................10

Blending.........................................10

Chopping/Grinding ................................10

Whisking ........................................11

Cleaning and Maintenance ...............................11

Tips and Hints .........................................12

Frequent Uses for Food Processor Attachment ...............14

Recipes ..............................................15

Warranty .............................................28

UNPACKING INSTRUCTIONS

Place the package containing the Cuisinart®Smart Stick®Two Speed

Hand Blender on a sturdy surface. Unpack the Smart Stick®Hand

Blender from its box by removing the upper protective insert. Gently

slide the unit from the box. Remove all support materials from the box

and replace the upper insert. Save packaging for possible repacking

of the unit.

NOTE: The blending blade is extremely sharp.

Before using the Cuisinart®Smart Stick®Two Speed Hand Blender for

the first time, we recommend that you wipe the unit with a clean,

damp cloth to remove any dirt or dust. Dry it thoroughly with a soft

absorbent cloth. To clean all parts see instructions on page 11. Read

all instructions completely for detailed operating procedures.

PARTS AND FEATURES

1. Low/High Two Speed Power Button: Allows you to activate

the hand blender at the touch of a button. Simply press and

hold down the Low or High button to blend or pulse. Once

the button is released, blending will stop.

2. Comfort Grip Handle: The handle allows you to control the

hand blender with ease.

3. Motor Body Housing

4. Blending Attachment: This attachment easily snaps into the

motor body housing. The fixed stainless blade is partially

covered by a stainless housing that keeps splashing to a

minimum. Press the release button on the back of the unit to

detach for easy cleaning.

5. Whisk Attachment: Whisk attachment snaps into the motor

body housing. This attachment is great for whipping cream,

egg whites and other delectable treats.

a. Gearbox: Whisk attaches to it.

6. Chopper/Grinder Attachment with Reversible Blade: Chop,

mince and grind with the Cuisinart chopper/grinder

attachment. Chopper/grinder attaches to the blender motor

body in place of the blender shaft or whisk attachment.

7. Mixing Cup: 2-cup blending cup is microwave and

dishwasher safe. Use this container to blend drinks, shakes,

salad dressings and more. Designed for easy gripping and

drip-free pouring.

Motor

Body

Housing

Detachable

Blending Shaft

Blade

Guard

Work Bowl Cover

Chopper/Grinder

Attachment

Work Bowl

Low/High

Button

Comfort

Handle

Whisk

Attachment

Detachable

Gearbox

Reversible

Blade

PARTS AND

FEATURES

ASSEMBLY

BLENDING ATTACHMENT

1. Align the motor body housing with

the blending shaft and push the

pieces together until you hear and

feel them click together. It may be

helpful to press the release button

when assembling.

2. Plug the power cord of the hand

blender into an electrical outlet.

CHOPPER/GRINDER ATTACHMENT

1. Connect the motor body

housing to the top of the

work bowl cover.

2. Align the spine in the food

processor cover’s drive

shaft with the ribbed

opening on the underside

of the motor body

housing.

3. When aligned properly,

slide the two pieces

together until you feel

and hear a slight click.

CHOPPER/GRINDER ATTACHMENT

1. Place the chopping/grinding blade into center of the work bowl

over metal blade shaft.

2. Place the motor body housing with cover on top of the work

bowl and rotate counterclockwise to lock into place.

3. Plug the power cord of the hand blender into an electrical outlet.

WHISK ATTACHMENT

1. Align the motor body housing

with the assembled whisk

attachment and push the pieces

together until you hear and feel

them click together. It may be

helpful to press the release

button when assembling.

Note: Whisk and whisk

gearbox are detachable

from one another.

SHARP SIDE

REVERSIBLE BLADE

The Cuisinart®Smart Stick®Two Speed Hand Blender chopper/grinder

attachment is equipped with a reversible blade. This blade is sharp on

one side and blunt on the other. The blade is attached to a plastic ring

that slides over the plastic blade sheath, so it can be easily turned

over to select the appropriate blade. To reverse the blade, see detailed

instructions below. Also see Frequent Uses for Chopper/Grinder

(page 14).

Assemble the parts.

1. Place the work bowl on a flat, dry, stable surface. It should

be close to an electrical outlet of the same voltage as stated

on the rating plate on the hand blender.

2. The metal blade assembly shaft (A) is

attached to the bottom of the work bowl.

If not already in place, slide the fully

assembled blade assembly (B) over the

top of the metal blade assembly shaft.

2a. Put together the blade assembly if not assembled:

Very carefully connect the blade ring (C) to the plastic blade

sheath (D). Line up the blade ring opening with the plastic

sheath. There are notches (E) on opposite sides of the

interior of the hub. These fit over ridges on the sides of the

plastic blade sheath (G). Let the blade ring slide to the

bottom of the plastic sheath. HOLD THE BLADE RING BY

THE CENTRAL HUB HOLDING RIBS (grips) (F) ONLY. DO

NOT TOUCH THE RAZOR-SHARP BLADES. Pick up the

blade ring by its hub holding ribs (grips) and turn it very

slightly clockwise. This locks it in place on the plastic blade

sheath and prevents it from sliding up during processing.

Note these important features of the blade ring. The blade ring can

be placed over the plastic blade sheath in two different ways:

If you hold it this way (A), you will see the word “Sharp” on the

blade. Assemble the blade this side up to use the sharp edge.

B. BLUNT SIDE UP

If you hold it this way (B), you will see no writing on the blade.

Assemble the blade this side up to use the blunt edge. (See

the section on processing food, page 14, for information about

when to use the blunt edge.)

OPERATION

BLENDING

The specially designed blade is for mixing and puréeing all kinds of

foods, including salad dressings, powdered drink products, soups and

sauces and blended drinks like milkshakes or smoothies.

This blade mixes and stirs while adding only a minimum of air to your

mixture. A gentle up-and-down motion is all you need to make the

most flavorful, full-bodied recipes. Be careful never to remove the

blending shaft from the liquid while in operation, for it will splatter.

Tilt the pan or bowl away from you if needed to ensure the protective

blade guard on the blending shaft is fully submerged.

1. Put blending shaft into mixture to be blended.

2. Press and hold the desired speed button. The hand blender will

continue to run as long as the button is pressed in. To turn hand

blender off, release the Power button and the motor will stop.

3. Do not press the button for longer than 60 seconds at a time.

4. Unplug immediately after use.

CAUTION: DO NOT PUT FINGERS NEAR BLADE.

TO DISLODGE FOOD, UNPLUG HAND BLENDER

FROM THE OUTLET FIRST.

PULSING

To pulse, press and release desired speed button.

CHOPPING FOOD

1. Place the work bowl firmly on a flat, sturdy surface like a

countertop.

2. Put food in the work bowl. Be sure the food is cut into small

pieces (½ to 1 inch), and the bowl is not overloaded.

3. Put the work bowl cover on top of the work bowl. Be sure the

cover is properly seated.

4. Press and hold the desired speed button.

Indice

Altri manuali Cuisinart Miscelatore

Cuisinart

Cuisinart CPB-380 Manuale di servizio

Cuisinart

Cuisinart BFP-650 Manuale di servizio

Cuisinart

Cuisinart CSB-79C Manuale

Cuisinart

Cuisinart VELOCITY Manuale utente

Cuisinart

Cuisinart SmartPower Deluxe SPB-600 Manuale utente

Cuisinart

Cuisinart SmartPower Duet IB-9570 Manuale utente

Cuisinart

Cuisinart SPB-600C Manuale utente

Cuisinart

Cuisinart CBT700E Manuale utente

Cuisinart

Cuisinart SPB-7CH - SmartPower Electronic Blender Manuale di servizio

Cuisinart

Cuisinart SMARTPOWER SPB-7C Series Manuale di servizio

Cuisinart

Cuisinart EVOLUTIONX CORDLESS RPB-100C Manuale operativo

Cuisinart

Cuisinart SmartPower Classic SPB-6C Manuale di servizio

Cuisinart

Cuisinart CSB300U Manuale utente

Cuisinart

Cuisinart Smart Stick PowerTrio CSB-80C Manuale di servizio

Cuisinart

Cuisinart SmartPower SPB-7 Series Manuale di servizio

Cuisinart

Cuisinart CSB-78 - Cordless Rechargeable Hand Blender Manuale di servizio

Cuisinart

Cuisinart CSB800U Manuale utente

Cuisinart

Cuisinart Hurricane CSB-750H Manuale utente

Cuisinart

Cuisinart Velocity Ultra 1 HP Manuale utente

Cuisinart

Cuisinart CBT700U Manuale utente

Cuisinart

Cuisinart Tasty HB200T Manuale utente

Cuisinart

Cuisinart Hurricane Pro CBT-2000C Manuale utente

Cuisinart

Cuisinart SmartPower Premier CBT-500C Manuale di servizio

Cuisinart

Cuisinart SSB-1HK Manuale utente

Manuali Miscelatore popolari di altre marche

ROTOR

ROTOR 1125.201 Manuale utente

Braun

Braun Multiquick 5 Vario series Manuale utente

ARENDO

ARENDO MIRA 305424 Manuale utente

CHEF-BUILT

CHEF-BUILT CCB-3500 Manuale utente

Viconte

Viconte VC-4406 Manuale utente

Oster

Oster BLSTAB-CB0 Manuale utente

HOFFEN

HOFFEN MC-3005 Manuale utente

Black & Decker

Black & Decker BLC18750DM Manuale utente

Sunbeam

Sunbeam 4182 Manuale utente

Bialetti

Bialetti FMX35 Manuale utente

Black & Decker

Black & Decker BL8000 Manuale utente

Duronic

Duronic BL530 Manuale utente

Exquisit

Exquisit MS 3002 wes Manuale utente

Lumme

Lumme LU-KP1891A Manuale utente

Binatone

Binatone HB-735 Manuale utente

Moulinex

Moulinex LM936E10 Manuale utente

Oster

Oster VERSA Manuale di installazione e funzionamento

Ninja

Ninja NN210Q Manuale utente
