Cuisinart SS-700 Manuale utente

For your safety and continued enjoyment of this product, always read the instruction book carefully before using.

Single Serve Brewing System

SS-700

INSTRUCTION BOOKLET

IMPORTANT

SAFEGUARDS

When using electrical appliances, basic

safety precautions should always be

followed to reduce the risk of fire, electric

shock and/or injury to persons, including the

following:

1. READ ALL INSTRUCTIONS.

2. Do not touch hot surfaces. Use handles

and knobs.

3. To protect against electric shock, do not

place cord, plug, or base unit in water or

other liquids.

4. Close supervision is necessary when

any appliance is used by or near

children.

5. Always unplug from outlet when not in

use and before cleaning. Allow to cool

before putting on or taking off parts and

before cleaning the appliance.

6. Do not operate any appliance with a

damaged cord or plug or after the

appliance malfunctions or has been

dropped or damaged in any manner.

Return appliance to the nearest

Cuisinart Repair Center for examination,

repair, or electrical or mechanical

adjustment.

7. The use of accessory attachments not

recommended by Cuisinart may cause

injuries, fire, electric shock or injury to

persons.

8. Do not use outdoors.

9. Do not let cord hang over edge of table

or counter, or touch hot surfaces.

10. Do not place on or near a hot gas or

electric burner, or in a heated oven.

11. Always fill water reservoir first, then plug

cord into the wall outlet. To disconnect,

turn controls to Off, then remove plug

from wall outlet.

12. Do not use appliance for other than

intended use.

13. Do not lift handle to open the lid of the

brewer while brewing is in progress.

14. Do not overfill the water reservoir with

water. Use ONLY WATER in this

appliance! Do not put any other liquids

or foods in the water reservoir except as

instructed in the cleaning instructions in

this guide.

15. Do not clean drip tray with cleansers,

steel wool pads, or other abrasive

materials.

16. WARNING: TO REDUCE THE RISK OF

FIRE OR ELECTRIC SHOCK, DO NOT

REMOVE THE BASE PANEL. NO

USER-SERVICEABLE PARTS ARE

INSIDE. REPAIR SHOULD BE DONE

ONLY BY AUTHORIZED PERSONNEL.

SAVE THESE

INSTRUCTIONS.

FOR HOUSEHOLD

USE ONLY

WARNING: RISK OF FIRE OR ELECTRIC SHOCK

The lightning flash with arrowhead symbol within an equilateral triangle is intended

to alert the user to the presence of uninsulated dangerous voltage within the

product’s enclosure that may be of sufficient magnitude to constitute a risk of fire

or electric shock to persons.

The exclamation point within an equilateral triangle is intended to alert the user to

the presence of important operating and maintenance (servicing) instructions in the

literature accompanying the appliance.

SPECIAL CORD SET

INSTRUCTIONS

A short power-supply cord is provided to

reduce the risks resulting from becoming

entangled in or tripping over a longer cord.

Longer extension cords are available and

may be used if care is exercised in their use.

If a long extension cord is used, the marked

electrical rating of the extension cord must

be at least as great as the electrical rating of

the appliance. The extension cord should be

a grounding-type 3-wire cord, and the

longer cord should be arranged so that it will

not drape over the countertop or tabletop

where it can be pulled on by children or

tripped over.

NOTICE

If you have a

diecast metal unit,

for your protection,

it is equipped with

a 3-conductor cord

set that has

a molded 3-prong

grounding-type

plug, and should

be used in combi-

nation with a prop-

erly connected

grounding-type

outlet as shown

in Figure A.

If a grounding-type outlet is not available, an

adapter, shown in Figure B, may be obtained

so that a 2-slot wall outlet can be used with

a 3-prong plug. As shown in Figure C, the

adapter must be grounded by attaching its

grounding lug under the screw of the outlet

cover plate.

NOTE: Do not remove the grounding

prong.

CAUTION: Before using an adapter, it must

be determined that the outlet cover plate

screw is properly grounded. If in doubt,

consult a licensed electrician. Never use

an adapter unless you are sure it is

properly grounded.

Note: Use of an adapter is not permitted in

Canada.

IMPORTANT UNPACKING

INSTRUCTIONS

1. Place the box on a large, sturdy, flat

surface.

2. Remove the instruction book and any

other literature.

3. Turn the box so that the backside of the

Brewer is down and slide the

coffeemaker from the box.

4. After the Brewer has been removed,

place the box out of the way and take

the pcaking materials away.

5. Remove the polybag covering the Brewer.

We suggest you save all packing materials

in the event that future shipping of the

machine is needed. Keep all plastic bags

away from children.

WARNING

RISK OF FIRE OR ELECTRIC SHOCK

DO NOT OPEN

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK)

NO USER-SERVICEABLE PARTS INSIDE

REPAIR SHOULD BE DONE BY AUTHORIZED SERVICE PERSONNEL ONLY

Circuit Grounding

Conductor

Connected

Properly

Grounding

Prong

Adapter

Grounding Lug

Cover

Mounting

Screw

Cover of

Grounded

Outlet Box

Important Safeguards . . . . . . . . . . . . . . . . . . . . . 2

Important Unpacking Instructions . . . . . . . . . . . . 3

The Quest for the Perfect Cup . . . . . . . . . . . . . . 5

Features and Benefits. . . . . . . . . . . . . . . . . . . . . 6

Set-Up & First Brew . . . . . . . . . . . . . . . . . . . . . . 8

Setting Up Your Brewer . . . . . . . . . . . . . . . . . . . 8

Charcoal Water Filter . . . . . . . . . . . . . . . . . . . . . 9

Brewing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Hot Water/Rinse . . . . . . . . . . . . . . . . . . . . . . . . 12

Brewing with the My K-Cup®Accessory. . . . . . 13

Stopping the Brew Process . . . . . . . . . . . . . . . 14

Adding Water . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Purging the Brewer. . . . . . . . . . . . . . . . . . . . . . 14

Programming . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Setting the Clock . . . . . . . . . . . . . . . . . . . . . 15

Programming On/Off Features . . . . . . . . . . 15

Programming Brew Temperature . . . . . . . . 17

Programming Your Brew Size . . . . . . . . . . . 18

Cleaning & Maintenance. . . . . . . . . . . . . . . . . . 18

Cleaning External Parts . . . . . . . . . . . . . . . . 18

Cleaning the My K-Cup®Filter . . . . . . . . . . . 18

Cleaning the K-Cup®Holder . . . . . . . . . . . . 19

Cleaning the Water Reservoir and Lid . . . . . 19

De-Scaling Your Brewer . . . . . . . . . . . . . . . 20

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . 21

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Contents

Element 1:

WATER

Any hot beverage is made up primarily of water.

Often overlooked, the quality of the water is as

important as the quality of the coffee, tea or cocoa.

A good rule of thumb is that if your water doesn’t

taste good from the tap, it won’t taste any better

in your beverage. That’s why the Cuisinart®Single

Serve Brewing System has added a charcoal water

filter that removes chlorine, bad tastes and odors,

for the purest cup every time.

Element 2:

COFFEE

While the bulk of the liquid is water, all of the flavor

should be from the coffee, tea or cocoa. To achieve

the same great quality you receive at coffee bars,

you need to use the same quality ingredients. By

using the K-Cup

, brought to you by some of the

most premium brands on the market, you can be

assured that you’re getting the finest, freshest

gourmet product with every cup you brew. If you

choose to use your own coffee in the included

My K-Cup

, make sure all your ingredients are

at their freshest.

Element 3:

GRIND

The grind of coffee and cocoa, or the refinement of

your tea leaves, is critical for proper flavor extraction.

With the pre-measured, pre-ground ingredients

found in every K-Cup

, you can rest easy knowing

that it’ll brew perfectly each and every time, locking

in maximum flavor and freshness.

Element 4:

PROPORTION

No matter which cup size you choose, the Cuisinart

Single Serve Brewing System, working in conjunction

with K-Cup

, always produces the perfect cup every

time. When grinding your own coffee and using it

in the included My K-Cup

, remember to add the

amount of ground coffee that corresponds to the

number of ounces being brewed.

The Quest

for the Perfect

Cup of Coffee

1. Charcoal Filter Holder

1a. Charcoal Water Filter

2. Water Reservoir Lid

Removes for easy filling.

3. Removable 80-oz.

Water Reservoir

Offers extra-large capacity, eliminating

the need for frequent refills.

4. Removable Drip Tray Plate

Allows extra space for travel mugs.

5. Drip Tray

6. Drip Tray Base

7. Removable K-Cup

Holder

8. Handle

Easy grip prevents slips.

9. Brewing Head

10. Brewing Chamber

Holds My K-Cup®or the K-Cup®Holder.

11. Housing

Features and Benefits

12. Control Panel

13. Menu Button

14. Up Button ( )

15. Down Button ( )

16. Brew Button

17. Rinse Button

18. Hot Water Button

19. My K-Cup

Compartment

Conveniently stores My K-Cup

20. My K-Cup®Reusable

Coffee Filter

21. Power Cord

(not shown)

22. Power Switch

(located rear side of Brewer)

23. Coffee Scoop

Setting Up Your Brewer

1. Unwrap cord and plug the Brewer into

a grounded outlet. Make sure to

remove packing tape, clear plastic

sticker from control panel, and sticker

from water reservoir. Also be sure to

remove the polybag from the My

K-Cup

located in the compartment

on the right side of the brewer.

2. Place a large cup or mug (10 oz.

minimum) on the drip tray.

3. Remove lid from reservoir, then lift

reservoir straight up and away from the

Brewer. Wash the reservoir with warm

soapy water.

4. Fill reservoir with water to the max fill line

and return with lid to unit (see figure 1).

5. Press the power switch located on the

rear right side of the Brewer. The switch

is spring-loaded and will return to original

position automatically.

6. The Brewer will automatically fill the

internal tank with water and heating

will begin. This will take approximately

4 minutes. During the heating period,

NOT READY will be displayed on the

control panel (see figure 2).

Note: It is normal to see small amounts

of water dripping into the water

reservoir during this and subsequent

heatings.

Once the water is heated, OPEN HEAD

will be displayed.

7. When the control panel displays

OPEN HEAD (see figure 3), open and

close the brewing chamber. READY and

brew size icons will be displayed with

the default size shown as a solid mug

(see figure 4).

Set-Up & First Brew

IMPORTANT: Do not attempt to use

your Cuisinart®Single Serve Brewing

System until it has been set up for its

first use as outlined below.

NOTE: If Brewer has been exposed

to temperatures below freezing, wait

at least two hours for Brewer to reach

room temperature before brewing. An

extremely cold Brewer will not operate.

Water Reservoir Lid

figure 1

Water Reservoir

Ready Mode

Idle Mode

figure 4

figure 3

Heating Mode

figure 2

8. Making sure your mug is in place, press

the Brew button to start a cleansing

cycle (unit will dispense approximately

8 oz. of water). The control panel will

display BREWING, as well as the factory

default brew size (see figure 5). When

cycle is complete, dispose of the hot

water.

Note: Do not use a K-Cup

for this

cycle.

The one-time set-up

process is complete.

Charcoal Water Filter

Your coffeemaker comes with a charcoal

water filter that eliminates chlorine, bad

tastes and odors from tap water.

Inserting the Water Filter

1. Remove the filter and filter holder from

the polybags.

2. Soak the filter, fully immersed in cold tap

water, for 15 minutes.

3. Remove lower portion of filter holder by

pressing the tabs on the sides and

pulling apart. Rinse with fresh water.

4. Insert the charcoal filter into the upper

filter holder, then attach the lower

portion by pressing on tabs and pushing

until it locks into place (see figure 6).

5. Flush filter by running fresh water

through lower portion of the filter

holder.

6. Allow the filter to drain completely.

7. Place the assembled water filter

holder into the water reservoir,

pushing it down to fit into place (see

figure 7).

Note:

We recommend changing the

water filter every 60 days or after 60 uses,

and more often if you have hard water.

Replacement filters can be purchased in

stores, by calling Cuisinart Customer

Service, or at www.cuisinart.com.

figure 5

figure 6

Upper Filter Holder

Charcoal Water Filter

Lower Filter Holder

PRESS TABS

figure 7

Water Reservoir Lid

assembled

Charcoal

Water Filter

Water

Reservoir

Brewing

1. The control panel will display OPEN

HEAD while in idle mode.

2. Place a cup or mug on the drip tray.

The drip tray can be removed to

accommodate travel mugs.

3. Lift the handle. The brewing chamber

will open toward you.

4. Select a K-Cup

®Portion Pack®

Note: Do not remove the foil lid or

puncture the K-Cup

5. Place a K-Cup

in the brewing chamber

(see figure 8).

Caution: There are two sharp

needles that puncture the

K-Cup

, one above and one

below. To avoid risk of injury,

do not put your fingers in the

K-Cup

brewing chamber.

6. Lower the handle to close the brewing

chamber. When closed completely, the

control panel will indicate READY (see

figure 9).

Note: If not used within 60 seconds,

the unit will return to Idle mode and

OPEN HEAD will be displayed on the

control panel. To restart the process,

open and close the handle and control

panel will display READY again.

7. All brew size icons will be displayed with

the default size shown as a solid mug.

To choose a different size, use the

or buttons. Choose from 4-oz. (iced

beverage), 6-oz., 8-oz., 10-oz., and

12-oz. brew sizes.

Note: The 8-oz. serving is the factory-

set default brew size. To program your

favorite brew size, see Programming

Your Brew Size on page 18.

a. Once a size is chosen, press Brew.

Only the Brew button will be lit. The

control panel will now display

BREWING, as well as the serving

size you selected (see figure 10).

figure 8

figure 9

K-Cup

Portion Pack

Ready Mode

Altri manuali per SS-700

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Cuisinart Macchina per il caffè

Cuisinart

Cuisinart FlavorBrew DCC-755 Series Manuale utente

Cuisinart

Cuisinart Brew Central CBC-5200PC Series Manuale utente

Cuisinart

Cuisinart DGB625BCU Manuale utente

Cuisinart

Cuisinart EM-100N Series Manuale utente

Cuisinart

Cuisinart DCC-1400 Series Manuale utente

Cuisinart

Cuisinart Brew Central DCC-1200PRC Manuale utente

Cuisinart

Cuisinart Burr Grind & Brew DGB-800 Series Manuale utente

Cuisinart

Cuisinart Buona Tazza Manuale di servizio

Cuisinart

Cuisinart DGB-625BC - Grind & Brew Automatic Coffee... Manuale utente

Cuisinart

Cuisinart Coffee Center SS-16 Series Manuale utente

Cuisinart

Cuisinart DCC-100C Manuale utente

Cuisinart

Cuisinart Grind & Brew Thermal DGB-650 Series Manuale utente

Cuisinart

Cuisinart DCC-1150BKP1 Manuale utente

Cuisinart

Cuisinart PerfecTemp DCC-3200C Series Manuale utente

Cuisinart

Cuisinart DCC-1400 - Coffee Maker, Brew Central... Manuale utente

Cuisinart

Cuisinart Brew Central DCC-2200RC Manuale utente

Cuisinart

Cuisinart Coffee Center BaristaBar SS-4N1C Series Manuale utente

Cuisinart

Cuisinart DCC-T20 Manuale utente

Cuisinart

Cuisinart DCC-1120C Series Manuale utente

Cuisinart

Cuisinart Brew Central CBC-7000PC Manuale utente

Cuisinart

Cuisinart DCC-2000 Series Manuale utente

Cuisinart

Cuisinart Coffee Center SS-12 Manuale utente

Cuisinart

Cuisinart Grind & Brew DGB-850 Series Manuale utente

Cuisinart

Cuisinart SS-10 Manuale utente

Manuali Macchina per il caffè popolari di altre marche

Taurus

Taurus Livorno 6 Manuale utente

Delta-q

Delta-q QUICK Manuale utente

Bunn

Bunn LCA-1 Guida alla risoluzione dei problemi

Black & Decker

Black & Decker BLACK DECKER HOME DE790 Istruzioni per l'installazione

Saeco

Saeco Vienna Plus Sup 018M Manuale utente

DeLonghi

DeLonghi DC300 Manuale utente

INCAPTO

INCAPTO BXCO1470E Manuale utente

Bosch

Bosch TASSIMO finesse TAS16B Series Manuale utente

Exido

Exido 245-072 Manuale utente

Animo

Animo OptiVend Choco Manuale utente

Siemens

Siemens TQ505DF Series Manuale utente

DeLonghi

DeLonghi ECI341 Manuale utente

Krups

Krups KT406511 Manuale utente

Cimbali

Cimbali M32 Classic Manuale utente

Philips

Philips HL3844N Manuale utente

Bosch

Bosch TES 515 SERIES Manuale utente

Tekmatix

Tekmatix TMFM - 65 Manuale utente

Scarlett

Scarlett SC-CM33005 Manuale utente
