Cuisinart WAF1U Manuale utente

Wafﬂe Maker

WAF1U

CPT445U

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should

always be followed, including the following:

1. The appliance is not intended to be operated by means of external

timer or separate remote-control system.

2. This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities, or lack

of experience and knowledge, unless they have been given supervision

or instruction concerning use of the appliance by a person responsible

for their safety. Children should always be supervised to ensure that

they do not play with this product.

3. Not for use by children. Keep out of reach of children during and

after use.

4. Once you have ﬁnished cooking, turn the selector control to the

‘OFF’ position, unplug the power cord from the mains and allow the

appliance to cool for at least 30 minutes before handling. The wafﬂe

plates can be washed by hand or in the dishwasher. Do not use metallic

objects such as knives when cleaning. This will damage the non stick

coating. Use wooden or heatproof plastic utensils only. The housing

base, cover and control knob can be wiped clean with a soft, dry cloth.

For tough stains dampen cloth. Never use an abrasive cleaner or harsh

pad.

5. The temperature of all surfaces marked with this symbol

will be very hot when the appliance is in use. DO NOT TOUCH

these surfaces as possible injury could occur. Allow to cool

completely before handling this appliance.

6. The outer surface may get hot when the appliance is in use.

7. Always inspect the appliance before use for noticeable signs of

damage. Do not use if damaged, or if the appliance has been dropped.

Do not use this appliance if the lead is damaged. In the event of

damage, or if the appliance develops a fault, contact the Cuisinart

Customer Care Line (refer to “UK After Sales Service section“ for

further information).

Congratulations on your purchase of the Cuisinart

Wafﬂe Maker.

For over 30 years Cuisinart’s aim has been to produce the

very ﬁnest kitchen equipment. All Cuisinart products are

engineered for exceptionally long life, and designed to be

easy to use as well as to give excellent performance day

after day.

To learn more about our products visit our website

www.cuisinart.co.uk

Contents

Product Description................................................................................... 5

Safety Cautions ......................................................................................... 6

Instructions For Use .................................................................................. 9

A Fitting &Removing The Plates........................................................................9

B Using The Wafﬂe Maker .................................................................................10

Hints &Tips.............................................................................................. 11

Cleaning &Maintenance ........................................................................12

UK Guarantee & After Sales Service .....................................................13

Recipes......................................................................................................14

Product Description

Lock Down Lid

Indicator Lights

Plate release button

Non Slip Rubber Feet

Plate release button

ON/OFF Dial

Removable Non-Stick Wafﬂe Plates

Safety Cautions

Carefully read all the instructions before using the appliance and keep

in a safe place for future reference

Always follow these safety cautions when using this appliance to avoid

personal injury or damage to the appliance. This appliance should be used

only as described within this instruction book.

nEnsure all packaging materials and any promotional labels or stickers

are removed from the Wafﬂe Maker before ﬁrst use.

nAlways inspect the appliance before use for noticeable signs of damage.

Do not use if damaged, or if the appliance has been dropped. In the

event of damage, or if the appliance develops a fault, contact the

Cuisinart Customer Care Line (refer to UK After Sales Service section for

further information).

nDo not use this appliance if the lead is damaged. In the event of lead

damage discontinue use immediately. If the lead is damaged it must

be replaced with a special lead available from the manufacturer or its

service agent. (See “UK After Sales Service”).

nWhilst in use the surfaces will become extremely hot. Do not touch hot

surfaces. Always use handles.

nUnplug from the mains when not in use and before cleaning. Allow to

cool before cleaning the appliance. To disconnect, turn the control to

‘OFF’ setting, and then remove the plug from the mains.

nThis appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience

and knowledge, unless they have been given supervision or instruction

concerning use of the appliance by a person responsible for their safety.

nChildren should always be supervised to ensure that they do not play

with this product.

nDo not use any accessories or attachments with this appliance other than

those recommended by Cuisinart.

nTo protect against ﬁre, electric shock or personal injury, do not immerse

cord, plug or unit in water or other liquids.

nDo not leave the lead hanging over the edge of a kitchen table or

worktop. Avoid contact between the lead and hot surfaces.

nFor indoor, domestic use only.

nThis appliance should be used only for preparation of food as described

within the instructions for use that accompany it. Please retain these

instructions for further use.

nAlways ensure that your hands are dry before removing the plug from

the mains socket. Never pull the plug out of the mains socket by its

lead.

nTo avoid injury or possible ﬁre, do not cover the appliance when in use.

nIf this appliance is used for re-heating foods, also ensure the food is

piping hot before eating.

nAllow to cool before putting on or taking off parts, and before cleaning

the appliance.

nExtreme caution must be used when moving an appliance containing

hot oil or other hot liquids.

nDo not connect this appliance to an external timer or remote control

system.

nThe appliance is not intended to be operated by means of external timer or

separate remote-control system.

nThis appliance complies with the basic requirements of Directives

2004/108/EC (Electromagnetic Compatibility) and 2006/95/EC (Safety

of domestic electrical appliances).

WARNING: Polythene bags over the product or packaging may

be dangerous. To avoid danger of suffocation, keep away from

babies and children. These bags are not toys.

The temperature of all surfaces marked with this symbol will be very

hot when the appliance is in use.

DO NOT TOUCH these surfaces as possible injury could occur.

Allow to cool completely before handling this appliance.

The symbol on the product or on its packaging indicates that this

product may not be treated as household waste. Instead it should be handed

over to an appropriate collection point for the recycling of electrical and

electronic equipment.

By ensuring this product is disposed of correctly, you will help prevent

potential negative consequences for the environment and human health,

which could otherwise be caused by inappropriate waste handling of this

product. For more detailed information about the recycling of this product,

please contact your local council ofﬁce or your household waste disposal

service.

UK Wiring Instructions

nYour Cuisinart Wafﬂe Maker includes a BS 13 amp moulded (fused)

mains plug on the supply cord.

nShould it be necessary at any stage to remove this moulded plug and

replace it with a re-wireable BS 13 amp mains plug, the re-wiring should

be completed as follows: (NB The moulded plug should be disposed of

safely)

Class I (1) Earthed Appliance

The wires in the mains cord are coloured in accordance with the following

code:

GREEN & YELLOW = EARTH

BLUE = NEUTRAL BROWN = LIVE

nThe wire which is coloured GREEN & YELLOW must be connected to the

terminal in the plug which is marked with the letter E or symbol.

nThe wire which is coloured BLUE must be connected to the terminal

which is marked with the letter N.

nThe wire which is coloured BROWN must be connected to the

terminal which is marked with the letter L.

With this appliance, if a 13 amp plug is used, a 13 amp fuse should be

ﬁtted. If any other type of plug is used, a 10 amp fuse must be ﬁtted at

the distribution board.

WARNING: A cut off plug inserted into a 13 amp socket is a serious

safety (shock) hazard. Ensure that the cut off plug is disposed of safely.

Instructions For Use

A Fitting &Removing The Plates

To ﬁt the plates:

nPlace the appliance in the open position with the controls directly in

front of you.

nEach plate is embossed with ‘Low’ or ‘Up’. Select the ‘Low’ plate, hold

it ﬂat with the positioning guides facing away from you and the ‘Low’

embossed sign facing up.

nAlign the two positioning guides to the back of the plate with the

brackets on the bottom of the appliance housing base. Tilt the back

of the plate and slide it underneath the brackets. Push down the front

end of the plate until it locks into place.

nSelect the ‘Up’ plate and with the ‘Up’ embossed sign facing up and

the two positioning guides facing away and down. Align the plate

with the brackets on the underside of the lid of the appliance and push

down the front to the locked position.

Positioning guides

To remove the plates:

nLocate the plate release buttons on the right side

of the unit’s upper and lower housing.

nPress the Upper release button ﬁrmly and the

“Up” plate will pop forward slightly from the lid.

Lift the plate up and slide out from under the

brackets in the centre.

nPress the button on the Lower housing and repeat

the above method to remove the “Low” plate.

N.B: Always allow the appliance to cool for at least 30 minutes

before removing the plates.

B Using The Wafﬂe Maker

nPlug the appliance into a suitable mains socket.

nTurn the control dial to ON.

nWhen the dial is in place a red light will illuminate on top of the

appliance to indicate that the power is on. Ensure lid is closed.

nOnce the appliance has reached the optimal temperature, the green light

will illuminate to indicate the appliance is ready to cook.

nSpray a little oil onto the plates. The plates are non-stick however a little

oil will help you to remove wafﬂes more easily.

nPour a ladleful (approx 90ml) into the centre of each, ensuring the batter

has spread to each corner.

N.B. Do not overﬁll, this may cause the batter to overﬂow

nClose the lid and lock the handle. It may take a few seconds for the green

light to switch off. This is normal.

nThe green light runs on a thermostat and indicates when the product is

up to temperature. As part of the cooking cycle the light will go on and

off during this process. You will need to assess if the wafﬂe is cooked by

lifting the lid.

ACTUAL SIZE SAMPLE:

For posiction 1:1

150%

CONTINENTAL CONAIR LIMITED

Customer:

Model No.

Description:

Prepared by:

Version:

Checked by:

Approved by:

Released on:

Vendor:

Printer:

Artwork No.:

CUISINART

GR-3

Knob Bezel sa

PETER 03/14/07

CH HO 03/19/07

Beth Lowe 03/19/07

03/19/07

TSANN KUEN

Scale 1 : 1

12345cm

Upper

Plate

Release

Button

Lower

Plate

Release

Button

Indice

Altri manuali Cuisinart Macchina per waffle

Cuisinart

Cuisinart WAF-F10P1 Manuale utente

Cuisinart

Cuisinart WAF-R - WAF-R Traditional Waffle Iron Manuale operativo

Cuisinart

Cuisinart WAF-100A Series Manuale utente

Cuisinart

Cuisinart WM-PZ2 Manuale di servizio

Cuisinart

Cuisinart Breakfast Central WAF-300 Series Manuale utente

Cuisinart

Cuisinart DIP-8 Manuale operativo

Cuisinart

Cuisinart WAF-F20 Series Manuale utente

Cuisinart

Cuisinart WAF-F40 Series Manuale di servizio

Cuisinart

Cuisinart Breakfast Express WAF-B50 Manuale utente

Cuisinart

Cuisinart WAF-200C SERIES Manuale di servizio

Cuisinart

Cuisinart WAF-F30 Series Manuale di servizio

Cuisinart

Cuisinart WMR-CA Series Manuale utente

Cuisinart

Cuisinart WAF-2B Manuale utente

Cuisinart

Cuisinart WAF6 - Traditional Waffle Maker Manuale utente

Cuisinart

Cuisinart WMK300E Manuale utente

Cuisinart

Cuisinart 4-Slice Belgian Waffle Maker WAF-100 Manuale utente

Cuisinart

Cuisinart WAF-2B Manuale operativo

Cuisinart

Cuisinart WAF-F20 Series Manuale di servizio

Cuisinart

Cuisinart WAF2U Manuale utente

Cuisinart

Cuisinart WAF-F30 Series Manuale utente

Cuisinart

Cuisinart WAF-F20 Series Manuale utente

Cuisinart

Cuisinart WAF-100 - Belgian Waffle Maker Manuale utente

Cuisinart

Cuisinart WAF-F15 Manuale utente

Cuisinart

Cuisinart WMB-4A Manuale utente

Manuali Macchina per waffle popolari di altre marche

Kenwood

Kenwood PG-2000 Manuale utente

BRAYER

BRAYER BR2300 Manuale utente

Ricardo

Ricardo Mini Waffle Maker Guida all'installazione

KYOWA

KYOWA KW-2616 Manuale utente

Herenthal

Herenthal EWM-1200 Manuale utente

MPM

MPM MGO-30M Manuale utente

Nostalgia

Nostalgia MyMini MWF5AQ Guida rapida

SEVERIN

SEVERIN WA 2101 - Guida utente

Trebs

Trebs Comfortbakery 99255 Manuale utente

Black & Decker

Black & Decker WMB505C Manuale utente

Wilfa

Wilfa WM-623BELL Manuale utente

SEVERIN

SEVERIN WA 2110 Guida utente

Villaware

Villaware UNO 2000 Manuale

Unold

Unold 48266 Manuale utente

Royal Catering

Royal Catering RCWM-1400-B Manuale utente

Curtis Stone

Curtis Stone CSWB100 Manuale utente

Trebs

Trebs Comfortbakery 99257 Manuale utente

Farberware

Farberware 201597 Manuale utente
