CURTMFG.COM •NEED ASSISTANCE? •877.287.8 634 •18118-INS-RA •PAGE 1

INSTALLATION MANUAL 18118

Level of Difﬁculty

Easy

Product Photo

Parts List

Qty Description #

4Rail clamp 1

2Cross bar tube 2

WARNING

To Prevent Serious Injury or Death: Inspect for signs of wear, rust

and damage before each use. Do not use if bent or deformed. Do not

use cross bars to transport people, animals, or flammable liquids.

Notes and Maintenance

Before you begin installation, read all instructions thoroughly.

Proper tools will improve the quality of installation and reduce the time required.

Mild automotive detergent may be used to clean the product. Do not use dish detergent, abrasive

cleaners, abrasive pads, wire brushes or other similar products that may damage the ﬁnish.

Make sure the cross bars are secured before every trip.

The cross bars must be periodically inspected for signs of wear,

corrosion and fatigue. Check at each stop to ensure the load is secure.

Remove your cross bars when not in use and before entering automatic car washes.

Always obey all posted speed limits and be aware of traffic conditions.

Adapt your speed to the conditions of the road and the load being carried.

Check local and state laws governing projection of objects beyond the perimeter of a vehicle.

Be aware of the width and height of your cargo in low clearance areas.

Do not use the cross bars for purposes other than those for which they were designed.

Do not attempt to modify the cross bars or any of the system components.

Product Registration

CURT Group stands behind our products

with industry leading warranties. You can

help us continue to improve our product

line and help us understand your needs

by registering your purchase by visiting:

warranty.curtgroup.com/surveys

At CURT Group, customer is king.

We value your feedback and we use

that information to make improvements

on our products. Please, take a minute

and let us know how we are doing.

Weight Capacity

Weight capacity 150 lbs. 68 kg

CURTMFG.COM •NEED ASSISTANCE? •877.287.8 634 •18118-INS-RA •PAGE 2

Step 1

Measure and clean the roof side-rails

on the vehicle. Close the sun roof or

moon roof if applicable.

Step 2

Adjust the rail clamps to the approximate

width of the vehicle side rails (dimension y).

Place the cross bars onto the vehicle

side rails. Ensure there is an equal overhang

(dimension x) on both sides of each cross bar.

Adjust to the desired distance

between the cross bars, maintaining

a minimum of 20" (50 cm).

Firmly tighten the rail clamp knobs to secure

the cross bars to the vehicle roof side-rails.

Note: One knob on each cross bar locks.

Turning the key one half turn clockwise

disengages the knob so that it moves

freely and no adjustment can be made.

Confirm the cross bars are secure

by giving each cross bar a push / pull.

X X

Max Height:

2.04"

Max Width:

1.76"

Min: 20"

(50cm)

Raised Side Rails

Vehicle Roof

Parts List

Qty Description #

4Rail clamp 1

2Cross bar tube 2

ASSEMBLY
