D-Link DHN-520 Manuale utente







 





6DHN520…02

Printed in Taiwan

RECYCLABLE

D-Link DHN-520 10Mb Home Phoneline Network Adapter for the PCI Bus

Introduction 1





Thank you for choosing the D-Link DHN-520. As a leading

network manufacturer, D-Link is dedicated to making the

best cost/performance adapter on the market. This

introduction will be useful if you are new to phoneline

networking and other new technologies featured in the

D-Link DHN-520. For more information on D-Link and

D-Link products go to <http://www.dlink.com>.



HomePNA 1.0 is a standard defined and ratified by the

Home Phoneline Networking Association (HomePNA).

Currently HomePNA 2.0 is scheduled to be ratified in the

fourth quarter of 1999. The DHN-520 was designed around

the proposed iLine10standard, which was accepted by

the HomePNA on July 27, 1999 as the basis for HomePNA

2.0. At the time of this manual’s printing HomePNA 2.0 has

not been officially ratified.

Home Phoneline Networking allows a home user to build a

network utilizing their standard home phonelines. It

removes the need to install separate hardware or specialty

cables as is required by other networking technologies.

With a full 10 megabits per second (Mbps) of bandwidth,

D-Link DHN-520 10Mb Home Phoneline Network Adapter for the PCI Bus

Introduction2

the data throughput speed is effectively 150-200 times

faster than a V.90 modem.

This technology will allow a Microsoft Windows 95 OSR2,

Windows 98 or Windows NT (and the future Windows 2000)

user to quickly share files and printers. Users can play

multi-player network games and share Internet access by

using additional software.

D-Link DHN-520 10Mb Home Phoneline Network Adapter for the PCI Bus

Introduction 3



Designed for versatility and performance, the D-Link

DHN-520 provides the following features:

• Backward compatibility with older 1-Mbps HomePNA

1.0 certified hardware

• Operates in a PCI Bus Master slot of a Pentium/

Pentium Pro/Pentium II computer, independent of CPU

speed.

• PCI Bus Master memory access, for high throughput

and low CPU demand.

• Plug-and-play installation.

• 10-Mbps throughput over standard home phonelines

• Three LED indicators: Link, Activity

• Drivers for Windows 95 OSR2, Windows 98, Windows

NT, and beta drivers for Windows 2000.

D-Link DHN-520 10Mb Home Phoneline Network Adapter for the PCI Bus

Installation4





Installation of a D-Link DHN-520 10-Mbps Home Phoneline

Network Adapter requires hardware installation first, then

software installation.



Under ordinary circumstances, your D-Link DHN-520

will not be affected by static charges such as may be

received through your body during handling of the

unit. In special circumstances where you might carry

an extraordinarily high static charge, it is good

practice to reduce the charge by touching a

grounded object before handling the adapter.

Open the shipping carton and carefully remove all items. In

addition to this user's guide, ascertain that you have:

• One DHN-520 home phoneline network adapter.

• One DHN-520 software CD.

• One phoneline cable.

• One D-Link DHN-520 User’s Guide (this manual)

D-Link DHN-520 10Mb Home Phoneline Network Adapter for the PCI Bus

Installation 5



1. Shut down the computer, unplug its power cord, and

remove the cover.

2. Insert the DHN-520’s board-edge contacts into any

available PCI Bus Master expansion slot. Press the

adapter firmly into the slot, making sure the contacts

are firmly seated.

3. Install the bracket screw that secures the card to the

computer chassis.

4. Replace the computer's cover.

5. Reconnect the computer's power cord and turn the

computer on. If your computer’s BIOS is plug-and-play

compliant, it will automatically configure the DHN-520

upon power-up.

          

       



         

         

       !   

      "

  # $% &    



D-Link DHN-520 10Mb Home Phoneline Network Adapter for the PCI Bus

Installation6



Standard phoneline cable can be used to either connect the

adapter to a phoneline wall jack, or to another adapter. It is

important to note that when two adapters are connected

directly, a second cable must be used to connect the

computers to an active phoneline. The adapter requires the

voltage running in an active phoneline to operate properly.



On account of the great variety of network environments for

which the DHN-520 may be used, and revisions of those

network systems, the instructions for software installation

are given as HELP files on the DHN-520 Software CD.

Review the root directory HELP for overview information,

and for full installation details, see the HELP and

referenced instruction files in the sub-directory appropriate

to your network operating system.

Additionally, on the Driver CD we have provided an HTML

manual designed for our DHN-910 10-Mbps Home

Phoneline Network in a Box. It is an HTML rendered copy

of the full Quick Starter Guide that accompanies the

network kit. Simply open the StartHere.htm file in the

/Manual subdirectory provided on the CD to launch and

view through your web browser.
