D-Link PersonalAir DBT-120 Manuale utente
D-Link Personal
Air
Bluetooth USB Adapter
DBT-120DBT-120
DBT-120DBT-120
DBT-120
This product can be used with:This product can be used with:
This product can be used with:This product can be used with:
This product can be used with:
Windows XP, Me, 2000, 98se & 98Windows XP, Me, 2000, 98se & 98
Windows XP, Me, 2000, 98se & 98Windows XP, Me, 2000, 98se & 98
Windows XP, Me, 2000, 98se & 98
Macintosh OS X v10.1.4Macintosh OS X v10.1.4
Macintosh OS X v10.1.4Macintosh OS X v10.1.4
Macintosh OS X v10.1.4
CheckYourPackageContents
These are the items included with your purchase:
If any of the below items are missing, please contact your reseller.
™
BeforeYouBegin
You must have at least the following:
•Windows XP/Me/2000/98se/98 or Macintosh OS X v10.1.4
•One Available USB Port
•CD-ROM Drive
• DBT-120 Wireless USB Bluetooth Adapter
• CD-ROM (containing Drivers,
PDF Installation Guide, PDF Manual
and Warranty)
• USB Extension Cable
Contents:
•MicrosoftWindowsInstructions.....Next Page
•Macintosh OS X Instructions...........Last Page
Click Install
Bluetooth
Software
If the Autorun screen does not automatically start, click on Start > Run,
enter “D:\Autorun.exe” and click OK. “D” represents the letter of your CD-
ROM drive. Replace it if your CD-ROM drive is a different letter.
Click Next
Insert the D-Link CD-ROM
IntoYourComputer
Turn on the computer and Insert the D-link PersonalAir DBT-120 Driver
CD in the CD-ROM drive.
Do NOT install the DBT-120 USB Adapter into your PC
before installing the driver software on the D-Link CD!
Click Next
Click Next
Click Install
Type a name for this
device. Multiple installs
must use different names.
Select Desktop
or Laptop
Click Next
Windows XP & Windows 2000 Users
Only Windows XP and Windows
2000 users will see this screen.
Click OK to continue.
Click OK
Windows 98se/98 Users
Only Windows 98se/98 users will see these screens.
Insert your Windows 98 Installation
disk into your CD-ROM drive
Click Yes
Click OK
Click OK
Enter the location of the
Windows 98 setup files
(e.g. “D:/Win98”)
Installing The DBT-120 Wireless USB
BluetoothAdapterIntoYourComputer
Click Finish
Click Yes
With your computer on…
Connect the DBT-120 to an
available USB port on your USB
host adapter or USB hub.
(You may also use the USB exten-
sion cable for easy access.)
Wait for your computer to RestartRestart
RestartRestart
Restart
Follow these steps to complete installation under Windows XP for
each device that Windows prompts you to install. You will see each
of these screens twice.
Windows XP Users
CompletingTheDriverInstallation
Click Next
Click Finish
Click Continue Anyway
Windows 2000 Users
Under Windows 2000, you may see the screen below. Click “Finish” to
complete the installation. If you do not see this screen, then the
installation has completed automatically.
You may now continue to the next section.
Click Finish
Windows Me & 98SE/98 Users
Under Windows Me & 98SE/98, you may see the screen below.
Select “Browse” and locate the “Drivers” folder on the DBT-120
Driver CD and select “OK”. If you do not see this screen, then the
installation has completed automatically. You may now continue to the
next section.
Locate Driver Folder
Select OK
The Installation is Complete!
After you’ve completed the installation, the Bluetooth Configuration
Utility will automatically start and the utility icon will appear in the bottom
right hand corner of the desktop screen (systray).
Double-click the Bluetooth icon
to use the configuration utility.
Once properly installed, the DBT-120 Wireless Bluetooth USB Adapter
will be able to connect to other Bluetooth wireless adapters,
When you have completed the steps in this Quick Installation
Guide, your connected network should look similar to this:
For detailed explanations regarding the Bluetooth software for
Windows, please refer to the DBT-120 Manual on the CD included
with this product.
Technical Support
You can find the most recent software and user
documentation on the D-Link website.
D-Link provides free technical support for customers
within the United States for the duration of the warranty
period on this product.
U.S. customers can contact D-Link technical support
through our web site or by phone.
D-Link Technical Support over the Telephone:
(877) 45D-LINK
(877) 453-5465
24 hours a day, seven days a week
D-Link Technical Support over the Internet:
http://support.dlink.com
email: [email protected]
©2002 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of
their respective holders. Software and specifications subject to change without notice. DBT-120.08262002
Macintosh OS X v 10.1.4 Installation
1. Download and install the Bluetooth™
software from www.apple.com
2. Insert the D-Link DBT-120 Bluetooth™
USB Adapter into an available USB port
Notebook
Keyboard
