D-Link SHARECENTER PRO 1100 Manuale utente
This document will guide you through the basic installation
process for your new D-Link ShareCenter® Pro 1100.
DNS-1100-04
Quick Installation Guide
D-Link ShareCenter® Pro 1100
Documentation also available on
CD and via the D-Link Website
D-Link DNS-1100-04 Quick Installation Guide
2
DNS-1100-04 Quick Install Guide
This installation guide provides basic instructions for installing the DNS-1100-04 on your
network. For additional information about how to use the ShareCenter® Pro, please see the
User Manual which is available on the CD included in this package or from the D-Link support
website.
Installation Steps
1. Verify the package contents against the list below.
2. Hardware Overview
3. Hardware Installation
4. Conguration with Wizard
1. Package Contents
D-Link ShareCenter® Pro 1100
CD-ROM with Manual and Software
Quick Installation Guide
Power Cord
CAT5E Ethernet Cable
Front Panel Lock Key
Note: Using a power supply with a dierent voltage than the one included with the ShareCenter® Pro will
cause damage and void the warranty for this product.
Note: The ShareCenter® Pro 1100 should only be maintained by the authorized server manager or IT
administrator. The ShareCenter® Pro 1100 should be locked using the Front Panel Key. Only certied
sta who have the Key are allowed to unlock it.
If any of the above items are missing, please contact your reseller.
D-Link DNS-1100-04 Quick Installation Guide 3
2. Hardware Overview
Next Button
Use this button to display
the System Information,
HD Volume Information,
and Error Messages on the
OLED.
Press the button once to
alternate between the
dierent Status screens.
OLED Screen
This screen displays detailed
information about the following:
System Information, HD Volume
Information and Error Messages
Rear Panel
Front Panel
Front Panel Lock
Turn key to up position
to unlock. Turn key to left
position to lock.
Drive Trays
Use the screws to fasten
the SATA hard drives with
the trays and insert to the
ShareCenter.
Cooling Fan
The cooling fan is used to cool the hard
drives.
USB Connector
Two USB 2.0 (Type A) ports.
The USB Host ports are for printers,
USB memory disks or USB UPS
monitoring.
Reset Button
Press and hold this button for more than 5 seconds to
reset the unit to factory defaults.
Power Receptacle
Connect the supplied power
cord to the receptacle.
Gigabit Ethernet Port
Use the Gigabit Ethernet Port to
connect the ShareCenter® Pro to your
local network.
LED Indicators
This screen displays information
about the following: Hard Drive
Status (Green=operational), LAN 1
& 2 Status (Blue=operational)
Power Button
Use this button to switch the device on or
o. To turn on press the button once. To turn
o hold the button down for 5 seconds.
D-Link DNS-1100-04 Quick Installation Guide
4
Using the OLED
The ShareCenter® Pro 1100 features an OLED that enables the administrator to easily view
information about the ShareCenter® Pro. The OLED screen displays the system information,
hard drive volume information and error messages. The OLED has three dierent screens:
System Information- This screen shows the following information:
The hostname of the ShareCenter® Pro
The IP address of the ShareCenter® Pro
The hard drive slots information
Hard Drive Volume information- This screen shows the following information:
The percentage of space used on the hard drives.
Error Messages- This screen shows error messages when there is any system failure.
Press the button once to alternate between the dierent Status screens.
D-Link DNS-1100-04 Quick Installation Guide 5
3. Hardware Installation
Follow the instructions below to install a hard drive, connect to the network and power on
the ShareCenter. Open the shipping carton for the ShareCenter® Pro and carefully remove
and unwrap its contents. Follow the instructions below to setup the ShareCenter® Pro. If this is
the rst time using the ShareCenter® Pro or if a new hard disk is installed, use the Easy Search
utility located on the Installation CD and follow the instructions for setting up, conguring and
formatting the new drive.
To install ShareCenter® Pro on your local network, refer to the steps below:
2. Remove the HDD tray by pressing the green button.
1. Open the faceplate to access the drive bays.
3. Put a 3.5” SATA hard drive into a drive tray and use screws
to fasten the hard drive with the tray. There are four holes
for fastening the screws. Two holes are circled in red in
the image, and the other two holes are on the other side
of the drive tray.
D-Link DNS-1100-04 Quick Installation Guide
6
4. Reinsert the HDD tray into the ShareCenter® Pro and
depress the green button to lock it into place.
5. Connect an Ethernet cable to the available Ethernet
port. This cable should connect the ShareCenter® Pro to
your local network via a router or switch, or directly to a
computer for conguration.
6. Connect the supplied power adapter to the power
receptacle.
D-Link DNS-1100-04 Quick Installation Guide 7
4. Conguration with Wizard
When rst powered on, during the initial boot sequence, the ShareCenter® Pro will wait
to be assigned an IP address via DHCP. If it does not receive a DHCP assigned IP address, by
default it will have an auto-assigned IP address of 169.254.x.x (where "x" is dynamic). It is
recommended to use the included D-Link EZ Search Utility when accessing and conguring
the ShareCenter® Pro for the rst time. If you want to change the IP address before logging
in or are unable to connect to the ShareCenter® Pro IP address, you can use the EZ Search
Utility provided on the product CD to locate the device on your network and make any needed
changes.
EZ Search Utility
Network Storage
Device
Refresh
Conguration
LAN
Apply
iSCSI Drive Mapping
Connect
Management
Drive Mapping
Available Drive
Letters
About
Exit
The EZ Search Utility displays any ShareCenter® Pro devices it detects on the
network here.
Click Refresh to refresh the device list.
Click Conguration to access the Web based conguration of the ShareCenter®
Pro.
Congure the LAN Settings for the ShareCenter® Pro here.
Click Apply to save changes to the LAN Settings.
Displays the available iSCSI targets on ShareCenter® Pro.
Click Connect to connect to the iSCSI target.
Click Management to edit the information.
Volumes available for mapping are displayed here.
Select an available drive letter. Click Connect
to map the selected volume. Click Disconnect
to disconnect the selected mapped volume.
Click About to view the software version of
the EZ Search Utility.
Click Exit to close the utility.
D-Link DNS-1100-04 Quick Installation Guide
8
To run the EZ Search Utility, insert the ShareCenter® Pro CD into your CD-ROM drive:
Getting Started
Click EZ Search Utility.
Select the listed ShareCenter® Pro and click the
Conguration button. This will launch the computer’s
default web browser and direct it to the IP address
listed for the device. Make sure the browser is not
congured to use a proxy server.
Note: The computer used to access the ShareCenter® Pro
web-based conguration manager must be on the same
subnet as the ShareCenter® Pro. If your network is using a
DHCP server and the computer receives IP settings from DHCP
server, the ShareCenter® Pro will automatically be in the same
subnet.
The Login screen will appear:
Select System Administrator and leave the password
eld blank. Click Login to continue.
D-Link DNS-1100-04 Quick Installation Guide 9
Click Next to continue.
System Wizard
The Setup Wizard is the easiest and fastest way to setup your ShareCenter® Pro 1100. Once you have
entered your IP address into the browser, follow these few steps to get started:
Step 1: Close the Create Volume window.
Step 2: Click the System Wizard icon in the
Home page ( ) window to start the
Setup Wizard. When running the
ShareCenter® Pro System Wizard, the
welcome screen details the ve steps
of the wizard.
Close the Create
Volume Window
D-Link DNS-1100-04 Quick Installation Guide
10
System Wizard
Use this window to configure the LAN
1 settings.
Enter the host name of the ShareCenter® Pro.
Enter the primary and secondary DNS server
address in the elds.
Use the drop-down menu to select the LAN
interface.
Click Next to continue.
Click Next to continue.
Step 3:
Click Next to continue.
Step 4: Use this window to congure the LAN 2 settings.
Step 5:
