D-Link DFM-562E - 56 Kbps Fax Manuale utente

If you purchased this Modem to make your Internet connection with PC, you must

have an established Internet account from an Internet Service Provider (ISP).

Check Your Package Contents

These are the items included with your D-Link 562E purchase:

If any of the above items are missing, please contact your reseller.

holders. Software and specifications subject to change without notice. D-Link DFM-562E External Modem

• D-Link DFM-562E External Modem

• CD-ROM (containing Manual and Q.I.G.)

• 9V AC, 0.8A Power Adapter

• Phone Cable

• RS-232 (9Pin) Cable

Using a powe

supply with a

different voltage rating

will damage and void

the warranty for this

product.

D-Link DFM-562E

External Modem

Before Your Begin

Hardware Installation

Please unplug the telephone Line and plug the telephone line into the socket on the

back of the modem marked LINE.

eaker Jack

MIC Jack

Power

Jack

Power

Switch

Tele

hone Line Socket

RS-232C Connect

Install Drivers

2.1 Windows 98/ME

Click Install Drivers

After system will

auto Install Modem.

Please click Close to

end the window

Click CLOSE

When the system was

complete, windows will

detect the modem

automatic, please click

Cancel. Then insert the

driver CD supplied

2.1 Windows 98/ME (continue)

Click Modems

Check Modem Model No. For

D-Link DFM-562E External

Modem.

If correct the installation is

complete then click OK to exit.

Click OK

2.2 Windows 2000

Click Install Drivers

Click

Click Yes ignore the

message.

After system will

auto Install Modem.

Please click Close to

end the window

Click CLOSE

Click Yes ignore the

message.

Click

2.2 Windows 2000(continue)

Please select Start /

Settings /

Control Panel and

double-click

on the Phone and

Modem Options icon.

Click Phone

and Modem

Options

Check Modem Model No.

For D-Link DFM-562E

External Modem.

If installation is complete

then click OK to exit.

Click OK

2.3 Windows XP

Click Install Drivers

Click Continue

Anyway

When the system was

complete, windows will

detect the modem

automatic, please click

Cancel. Then insert the

driver CD supplied

Click Continue

Anyway

Select the Install the

software automatically

[Recommended] then

click Next to search for the

driver.

Click Continue Anyway

to skip the warning

message.

Click Next

Install complete

Click Finish

Please click Close to

end the window

Click CLOSE
