This document will guide you through the

basic installation process for your new

D-Link Unied Services Router.

DSR-250V2

Quick Installation Guide

Uniﬁed Services Router

2  D-Link Unied Services Router

ENGLISH

About This Guide

This guide gives step by step instructions for

setting up D-Link DSR-250V2 Services Router.

Please note that the model you have purchased

may appear slightly di󰀨erent from those shown in

the illustrations.

Item Feature Description

A LED

(Top to bottom)

Power LED: Indicates the Services

Router is powered on.

BUSB Port (1) It can support various USB 2.0, 3.0

devices below:

1.Flash Disk or Hard Disk for

network sharing.

2.Printer (It will be supported by

future rmware upgrade)

C Gigabit LAN port

(1-4)

Connect Ethernet devices, such as

computers, switches and hubs.

D Gigabit WAN

port (1)

One auto MDI/MDIX WAN ports

are the connection for the Ethernet

cable to the cable or DSL modem.

EConsole Port (1) Used to access Command Line

Interface (CLI) via RJ45-to-DB9

console Cable.

Table 1: DSR-250V2 Front Panel Descriptions

Device Status LEDs and Ethernet Port LEDs

The device LEDs show information about current

device status. When the device power up, the

POWER/STATUS LED will show solid orange

during power on process. Startup takes one minute

approximately to complete, the LED will change

to solid green. If you want to turn the device o󰀨

and on again, we recommend you wait a few

seconds between shutting it down and powering it

back. The Ethernet LEDs show the status of each

Ethernet port. Table 2 lists the name, color, status

and description of each device LED.

Figure 2. Ethernet RJ-45 Port LEDs

TX/RX

Status

Link

Speed

Unpacking the Product

Open the shipping carton and carefully unpack its

contents. Please consult the packing list located

in following information to make sure all items are

present and undamaged. If any item is missing

or damaged, please contact your local D-Link

reseller for replacement.

- One (1) DSR-250V2 Unied Services Router

Appliance

- One (1) 12V/1.5A Power Adapter

- One (1) Console Cable (RJ45-to-DB9 Cable)

- One (1) Ethernet (CAT5 UTP/Straight Through)

Cable

Product Overview

This chapter provides detailed descriptions of the

DSR-250V2 device and its components.

LED

Indicators

Color Status Description

Power /

Status

Orange/

Green

Solid

Orange

Device during power-on

process

Solid Green Completion of power on

Light O󰀨 The device is power-o󰀨

TX/RX

Status

Green Light O󰀨 No Link.

Solid Green Link present.

Blinking

Green

Port is sending or

receiving data.

LINK

Speed

Green/

Orange

Light O󰀨 Port is operating at

10Mbps.

Solid Green Port is operating at

100Mbps

Solid

Orange

Port is operating at

1000Mbps

Table 2: Device Status LED Descriptions

Front Panel

Figure 1. DSR-250V2 Front Panel

A C ED B

D-Link Unied Services Router  3

ENGLISH

Connecting Power and Turn the Device

On/O󰀨

Installing and Connecting the

Device

This chapter describes how to connect cables and

power to the device.

Before You Begin

Observe the following precautions to help prevent

shutdowns, equipment failures and injuries:

- Before installation, always check that the power

supply is disconnected

- Ensure that the room in which you operate the

device has adequate air circulation and that

the room temperature does Not exceed 40˚C

(104˚F)

- Allow 1 meter (3 feet) of clear space to the front

and back of the device.

- Do not place the device in an equipment rack

frame that blocks the air vents on the sides of

the chassis. Ensure that enclosed racks have

fans and louvered sides.

- Correct these hazardous conditions before

any installation: moist or wet oors, leaks,

ungrounded or frayed power cables, or missing

safety grounds.

The AC/DC Power Adapter shipped with the

device connects the device to earth ground when

plugged an AC grounding-type power outlet. The

device must be connected to earth ground during

normal operation.

To connect power to the device, plug the AC/DC

power adapter into the DC power phone jet on the

back panel of the device.

Note: We recommend using a surge protector for

the power connection.

To power on the DSR-250V2 device, press the DC

power switch on the rear panel to the on position.

To power o󰀨 the device, press the power switch to

the o󰀨 position.

DSR-250V2 Default Interface Settings

Ethernet

Interface

Type IP Address

Web-Based

Management

DHCP

Server

LAN(1-4) Static IP 192.168.10.1 Enabled Enabled

WAN DHCP

Client

0.0.0.0 Disabled Disabled

Table 3: Default Interface Settings

Note: D-Link Services Routers only allow Web

GUI access from LAN interfaces by default for

security reason.

Connecting the Device to a Network

This section provides basic information about

physically connecting the DSR-250V2 to a

network. To connect the necessary cables as

shown in Figure 3.

1. Connect an RJ-45 cable from the port labeled

WAN to the external router. The port WAN is

pre-allocated to the WAN network segment.

2. Connect an RJ-45 cable from the port labeled

LAN (1-4) to a switch in the LAN network

segment.

3. Connect an RJ45-to-DB9 cable from the

console port for CLI (Command Line Interface)

management access.

Figure 3. Basic Cabling Example

WAN

LAN Console

Internet

Switch

User

4  D-Link Unied Services Router

ENGLISH

The Services Router provides an serial port that

enables a connection to a computer or terminal

for monitoring and conguring the device. This

port is a RJ-45 connector, implemented as a

data communication terminal equipment (DCE)

connection.

To use the console port connection, you need the

following equipment:

1. A terminal or a computer with both a serial port

and the ability to emulate a terminal.

2. A RJ45-to-DB9 RS-232 with female connector.

(Already included in packing list)

3. If your Laptop or PC doesn’t have RS-232

connector, a converter is required.

Note: DSR-250V2 does not come with RS-232

converter and these must be purchased separately.

To establish a console connection:

1. Plug the RJ-45 connector of the supplied

RJ45-to-DB9 cable directly to the console port

on the Services Router.

2. Connect the other end of the cable to a terminal

or to the serial connector of a computer

running terminal emulation software. Set the

terminal emulation software as following:

Baud rate: 115200

Data bits: 8

Parity: None

Stop bits: 1

Flow control: None

3. When you have correctly set up the terminal,

having previously followed the instructions

in section “Connecting Power and Turn the

Device On/O󰀨” then switch on your device.

The boot sequence appears in the terminal.

4. Once the boot sequence completes, the

command prompt is displayed, the device is

ready to be congured.

Using a Console Connection

(RJ45-to-DB9 DCE)

To access the device with the WebUI:

1. Connect your workstation on the port labeled

LAN (1-4), which is pre-allocated to the LAN.

2. Ensure your workstation is DHCP Client

enabled or congured with a static IP address

in the 192.168.10.0/24 subnet.

3. Log on the Services Router Web Interface The

default log on information is:

Username: admin

Password: Admin$123

Initially Congure the Device

The services router software is preinstalled on the

DSR-250V2 device. When the device is powered

on, it is ready to be congured. While the device

has a default factory conguration that allow you

to initially connect to the device, you must perform

further conguration for your specic network

requirements.

Using the WebUI

To use the WebUI, the workstation from which you

are managing the device must initially be on the

same subnetwork as the device.

Figure 4. WebUI login

D-Link Unied Services Router  5

ENGLISH

Technical Support and Warranty Policy

http://www.dlink.com/support

http://www.dlink.com/warranty

6  D-Link Unied Services Router

Federal Communication Commission Interference Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital device,

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment o󰀨 and on, the user is encouraged to try to

correct the interference by one of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit di󰀨erent from that to which the receiver is

connected.

- Consult the dealer or an experienced radio/TV technician for help.

FCC Caution: Any changes or modications not expressly approved by the party responsible for

compliance could void the user's authority to operate this equipment.

Industry Canada statement

This device complies with ISED’s licence-exempt RSSs. Operation is subject to the following two

conditions: (1) This device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

Le présent appareil est conforme aux CNR d’ ISED applicables aux appareils radio exempts de licence.

L’exploitation est autorisée aux deux conditions suivantes : (1) le dispositif ne doit pas produire de

brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage

susceptible de provoquer un fonctionnement indésirable.

D-Link Unied Services Router 7

Ver. 1.00(WW)

2021/09/24

2907260025V2A10

Altri manuali per DSR-250V2

Indice

Altri manuali D-Link Router di rete

D-Link

D-Link DIR-842 Manuale utente

D-Link

D-Link DIR-865L Manuale utente

D-Link

D-Link DIR-640L Manuale utente

D-Link

D-Link DES-1024D Manuale utente

D-Link

D-Link DSL-2641B - Wireless G Router Manuale utente

D-Link

D-Link DIR-815 Manuale utente

D-Link

D-Link DFL-210 - NetDefend - Security Appliance Manuale utente

D-Link

D-Link DIR-605L Manuale utente

D-Link

D-Link DI-2621 Manuale utente

D-Link

D-Link DIR-853 Manuale utente

D-Link

D-Link AirPremier N DAP-2690 Manuale utente

D-Link

D-Link DIR-2150 Manuale utente

D-Link

D-Link DIR-619L Manuale di istruzioni

D-Link

D-Link DWR-961 Manuale utente

D-Link

D-Link EBR-2310 - EN Broadband Router Manuale utente

D-Link

D-Link DIR-615 - Wireless N Router Manuale utente

D-Link

D-Link DIR-615 - Wireless N Router Manuale utente

D-Link

D-Link xStack DES-3800 Series Manuale utente

D-Link

D-Link DIR-842 Manuale utente

D-Link

D-Link DIR-456U Manuale utente

D-Link

D-Link DES-3526 - Switch - Stackable Manuale utente

D-Link

D-Link DWR-910 Manuale utente

D-Link

D-Link DES-1048G Manuale utente

D-Link

D-Link DSL-2750U Manuale utente

Manuali Router di rete popolari di altre marche

Allnet

Allnet ALL0333AU Manuale utente

HomeSeer

HomeSeer HT-SEL Manuale utente

Sercomm

Sercomm Genesis OC3505D Manuale utente

Billion

Billion BIPAC 5102 Series Manuale utente

TP-Link

TP-Link TD-8817 Manuale utente

Motorola

Motorola MR1900 Manuale utente

Digi

Digi IX14 Manuale utente

Cisco

Cisco NCS 540 Manuale

XAVi

XAVi X8821e Manuale utente

BEC

BEC 6200WZL Manuale utente

MikroTik

MikroTik hAP ac3 Series Manuale utente

Korenix

Korenix JetNet 5428G Series Manuale utente

NETGEAR

NETGEAR FS526T - Switch Manuale utente

Korenix

Korenix JetNet 5710G Series Manuale utente

Automated Logic

Automated Logic ZN551 Manuale del proprietario

Cisco

Cisco ASR 1000 Series Manuale dell'operatore

EnGenius

EnGenius ESR-9710 Manuale utente

Cisco

Cisco 805 Series Istruzioni operative e di sicurezza
